Side 1/18
EN
Pg 1 of 11
4305P OM | Part No: 950-0597-001 | Rev 1.0
© 2022 HARMAN International Industries, Incorporated. All rights reserved.
4305P Powered Studio Monitor
Owner's Manual
Thank you for choosing JBL
For more than 75 years, JBL has been providing audio equipment for concert halls, recording studios, and movie theaters around
the world and has become the trusted choice of leading recording artists and sound engineers. The 4305P system is a new compact
powered bookshelf/monitor joining the JBL Studio Monitor family designed for home use. To get the best performance from you new
system, please read these instructions thoroughly.
1. Verify Box Contents
• 1 x Primary 4305P Speaker
• 1 x Secondary 4305P Speaker
• 1 x Safety Sheet
• 1 x Remote Control
• 4 x AC Power cords (quantity and type of plugs vary by regions)
• 1 x 10 feet CAT5e Shielded Cable
• 8 x Rubber bump-on feet
2. Front Panel Overview
VOL/MUTE SRC/PAIR
B C
A
D E
Primary Speaker
A
Source LED Indicators & Source Icons
(Left to Right: Streaming, Bluetooth, USB Audio, Toslink/
Optical, Balanced, Analog)
DSource Select + Bluetooth Pairing
(Rotary Encoder + Push Switch)
B Power Indicator E NET Status LED
CVolume Control / Mute
(Rotary encoder + Push Switch)
F
Secondary Speaker
F Power and Status LED
www.jbl.com/specialtyaudio
EN
Pg 2 of 11
4305P OM | Part No: 950-0597-001 | Rev 1.0
© 2022 HARMAN International Industries, Incorporated. All rights reserved.
3. Back Panel Overview
-10dB
+4dB
BALA NCED IN
SYNC
SERVICE
LEFT
ETHERNET
RIGHT
AUX
IN
INPUT
SENSITIVITY
DIGITAL
IN
USB
IN
BASS
CONTOUR L/R
ASSIGN
DIGITAL
LINK
SUB
OUT
-3dB
0dB
RE ET
POWER
4305P
XXXXXX
R-R-SEC-JBL 4305P CMIIT ID : xxxxxxxx
XXX-XXXXXX
USB
5V 350 mA
---
L
R
STUDIO MONITOR
输入/Input : 100-240V 50/60Hz 125W～
209-J00136
FCC ID: APIJBL4305P / IC: 6132A-JBL4305P.
Contains Transmitter Module FCC ID: UA9800 Contains ，
Transmitter Module IC 9129A-800：
.
Harman International Ind ustries, Inc. 制造商
8500 Balboa Blvd, Nort hridge, CA 91329, UNITED STATES
European Representative: Harm an Int ernational Industries, Inc.
UK business address: Ground Floo r, Westside 2, London Road,
Apsley, Heme l Hempst ead, Hert fordshire, HP3 9TD, United Kingdom.
Designed and Engineered in USA
Made In China / Сделано в Кит ай / 中国制造
approved by the party respo nsible f or compliance could vo id
the user’s authority to ope rate t he equipment.
The terms HDMI,HDMI High-Defunition Multime dia Interface，
and the HDMI Logo are trademarks or registe red trademarks of
HDMI Licensing Adiministrator,inc.
This device complies with Part 15 of t he FCC rules.
Operation is subject to the following two conditions: (1) this
device may not cause harm ful interf erence, and (2 ) this devic e
must accept any interfe rence received, includ ing interfere nc e
that may cause und esired operat ion.
POWER
DIGITAL
LINK
SYNC
输入/Input :100- 240V 50/60Hz 125W～
4305P
XXXXXX
R-R-SEC-JBL 4305P CMIIT ID : xxxxxxxx
STUDIO MONITOR
Contains Transmitter Module FCC ID: UA9800 C ontains ，
Transmitter Module IC 912 9A-800：
.
Harman International Ind ustries, Inc. 制造商
8500 Balboa Blvd, Nort hridge, CA 91329, UNITED STATES
European Representative: Harm an Int ernational Industries, Inc.
UK business address: Ground Floo r, Westside 2, London Road,
Apsley, Heme l Hempst ead, Hert fordshire, HP3 9TD, United Kingdom.
Designed and Engineered in USA
Made In China / Сделано в Кит ай / 中国制造
approved by the party responsible for
compliance c ould void
the user’s authority to operate the equipme
nt.
The terms HDMI,HDMI High-Defunition Multime dia Interface，
and the HDMI Logo are trademarks or registe red trademarks of
HDMI Licensing Adiministrator,inc.
This device complies with Part 15 of t he FCC rules.
Operation is subject to the following two conditions: (1) this
device may not cause harm ful interf erence, and (2 ) this devic e
must accept any interfe rence received, includ ing interfere nc e
that may cause und esired operat ion.
209-J00135
Primary Secondary
AH
B
I
C
J
D
K
E
L
F
M
N
O S
GR
P
Q
A
XLR / ¼" Balanced Input Sensitivity Selection – Select
either; -10dB (High sensitivity mode) or +4dB (Low
sensitivity / protects input front-end from overload)
KBass Contour switch:
For boundary compensation adjustment
B Left & Right XLR / ¼" Balanced Inputs L Sub-Woofer Output: When utilized, an 80Hz high-pass
filter is activated for system
CEthernet: Connect to available port on router for wired
streaming M
Primary Speaker Digital Link: To create wired connection
between Primary and Secondary speaker via CAT5e or
higher cable (Max length 6m)
DUSB-A + Service button: For service / firmware updates
ONLY (Not for Audio or USB Charging) NL/R Assign Selector: Select L or R depending on the
intended position for the Primary speaker
EReset: Factory Reset – press and hold until lights on
the front panel begin to flash O Primary Speaker Main Power switch -
FPrima ry Spe a ker Sync Button : Use to connect
wirelessly to Secondary speaker PSecondary Speaker Sync Button: Use to connect
wirelessly to Primary speaker
G
Primary Speaker IEC Power connection – a universal
power supply is incorporated allowing these to be used
domestically and internationally.
Q
Secondary Speaker Digital Link: To create wired
connection between Primary and Secondary speaker via
CAT5e or higher cable (Max length 6m)
H 3.5mm analog stereo input R
Secondary Speaker IEC Power connection - a universal
power supply is incorporated allowing these to be used
domestically and internationally.
I Toslink / Optical digital input S Secondary Speaker Main Power switch
J USB-B Digital Direct PCM input
