Side 1/21

Quick Start Guide

for Sound System Designers

JBL CBT Series

Constant Beamwidth Technology™ Column Loudspeakers

(Note: Some models shown with the included grilles removed to illustrate driver composition.)

Rev A3

CBT Quick Start Guide

CONTENTS

Introduction .................................................................................................................... 3

• Understanding the Charts

o SPL Maps

o Frequency Response Charts

• Room Sizes Shown

Example #1 – Flat Listening Plane

CBT 50LA ..................................................................................................................... 4

CBT 100LA in Broad Setting ........................................................................................... 5

CBT 100LA in Narrow Setting ........................................................................................ 6

CBT 70J in Broad Setting ............................................................................................... 7

CBT 70J in Narrow Setting .............................................................................................. 8

CBT 70J+70JE in Broad Setting .................................................................................... 9

CBT 70J+70JE in Narrow Setting .................................................................................. 10

Example #2 – Highly Raked Seating

CBT 100LA in Broad Setting .......................................................................................... 11

CBT 70J in Broad Setting .............................................................................................. 12

CBT 70J+70JE in Broad Setting .................................................................................... 13

Example #3 – Gentle Rake with Balcony

CBT 100LA in Broad Setting .......................................................................................... 14

CBT 70J in Broad Setting .............................................................................................. 15

CBT 70J+70JE in Broad Setting .................................................................................... 16

Example #4 – Three-Tiered, Raked, Large Room

CBT 100LA in Broad Setting .......................................................................................... 17

CBT 70J in Broad Setting .............................................................................................. 18

CBT 70J+70JE in Broad Setting .................................................................................... 19

Design Conclusions ...................................................................................................... 20

• Vertical Coverage Setting vs. Installation Height

• Single vs. Multiple CBT Columns

o For Width

o For Depth

• Front Fill

• How Far Each CBT Model “Throws”

Produkt Specifikationer

Mærke:	JBL
Kategori:	Højttaler
Model:	CBT 70J
Bredde:	170 mm
Dybde:	237 mm
Højde:	1388 mm
Vægt:	20400 g
Brugervejledning:	Ja
Produktfarve:	Sort
Udgangseffekt (RMS):	1000 W
Husmateriale:	Acrylonitrilbutadienstyren
Pakketype:	Kasse
Anbefalet brug:	Universel
Frekvensområde:	45 - 20000 Hz
Impedens:	4 ohm (Ω)
Forbindelsesteknologi:	Ledningsført
Højttaler, type:	2-vejs
Lyd-output kanaler:	- kanaler
Højttaler, placering:	Floor,Wall-mountable
Antal drivere:	24
Driver diameter:	130 mm
Peak Music-Udgangseffekt (PMPO):	4000 W
Sensitivitet:	98 dB
Plug and play:	Ja
Magnet-type:	Neodym
Signal/støjforhold:	125 dB
Monteringsbeslag inkluderet:	Ja
Højttalerplacering:	Center
Drivercylinder, materiale:	Aluminium
Klemskrue:	Ja
Højttalere RMS-effekt:	700 W
Magnetisk afskærmet:	Ja
