Control Contractor 50 Series
Control 50S/T and Control 52
Surface-Mount
Subwoofer-Satellite
Loudspeaker System
Key Features:
䉴
Stylish, unobtrusive design fits
into a wide variety of decors
䉴
High fidelity sound
䉴
Selectable 70V/100V for
distributed lines, or low
impedance
䉴
Versatility for either two or four
satellite speakers per system
䉴
Ability to mix and match with
Control Contractor40 Series in-
ceiling models
䉴
Wall-mount brackets included
䉴
Available in black or white
The Control 50 Series
subwoofer-satellite loudspeaker
system provides high fidelity
sound in restaurants, retail stores,
music cafes, health clubs, theme
bars, leisure venues, or any
location where full-range high
fidelity foreground/background
music is required from surface-
mount system.
Control 52 Satellite Speaker
The stylish Control 52 satellite
loudspeaker produces superb
high fidelity sound via a low-
distortion 60 mm (2 in) driver,½
which features a secondary
bucking magnet for high
efficiency, rubber half roll
surround for enhanced bass
performance, 19 mm (0.75 in)
copper clad aluminum wire voice
coil on a vented Nomex®former
for high fidelity and reliability,
and a copper-capped pole piece
for more consistent impedance
and extended high frequency
response. The wall bracket allows
each speaker to be angled up to
45° off-axis.
Control 50 Subwoofer
The 150 Watt (600 Watt peak) Control 50S/T subwoofer contains a
high-power, long-excursion, 200 mm (8 inch) driver which features
an extremely robust high-mass cone for extended low frequency
response, a 38 mm (1.5 in) 4-layer copper voice coil for high motor
strength, an aluminum former for good transient response, and a
rubber half roll surround for enhanced bass performance. The
Control 50S/T’s included two-piece easy-mount wall-bracket installs
quickly: The multi-point wall portion of the bracket attached to the
wall and the self-guiding speaker-mounted bracket drops into place
for a secure attachment. A cover over the Control 50S/T terminal cup
keeps wiring neat. The Control 50S/T is mono. The crossover
network built into the subwoofer provides proper signal routing and
four satellite output connectors allow connection of the wires for the
four Control 52 satellite loudspeakers. A Loop Out connector is also
provided on the subwoofer for looping the full-range input signal to
other loudspeakers or to other subwoofer/satellite systems.
System Configuration
Available as packaged system or as separate items, the Control 50
Series is extremely versatile system. The C50PACK system contains
four Control 52 satellite speakers and one Control 50S/T subwoofer
as an easy predesigned system. For smaller floor spaces, the Control
50S/T subwoofer can be utilized with two Control 52 satellite
speakers. The Control 50 system is mono. Both the Control 50S/T
and Control 52 can be intermixed in systems along with the Control
40 Series in-ceiling models – Control 40CS/T subwoofer and Control
42 satellite speaker – to match the form factor requirements of a
wide variety of applications.
Professional Series
䉴Control 50S/T and Control 52 Surface-Mount Subwoofer-Satellite Loudspeaker System
Control 50 Subwoofer-Satellite System Specifications
Frequency Range (-10 dB)1 : 32 Hz – 20 kHz
Frequency Response (±3 dB)1 : 50 Hz – 17 kHz
Power Capacity2 : 200 Watts Continuous Program Power (100 hrs)
100 Watts Continuous Pink Noise (100 hrs)
Nominal Sensitivity (2.83V, 1m)1 : 87 dB with 4 satellites
85 dB with 2 satellites
(subwoofer center of wall, higher sensitivity depending on subwoofer boundary loading, see application note)
Nominal Impedance: 4 ohms (in bypass/thru mode) with 4 satellites
8 ohms (in bypass/thru mode) with 2 satellites
Transformer Taps: 80W, 40W, 20W, (& 10W @ 70V), plus bypass/thru (listed as 8⍀on switch to indicate subwoofer impedance)
Control 50S/T Specifications
Frequency Range (-10 dB)1 : 32 Hz – 200 Hz
Frequency Response (±3 dB)1 : 50 Hz – 150 Hz
Power Capacity2 : 300 Watts Continuous Program Power (2 hrs)
150 Watts Continuous Pink Noise (2 hrs)
200 Watts Continuous Program Power (100 hrs)
100 Watts Continuous Pink Noise (100 hrs)
Nominal Sensitivity (2.83V, 1m)1 : 95 dB (near corner), 89 dB (center of wall)
Rated Maximum SPL (1m): 115 dB average, 121 dB peak (near corner)
109 dB average, 115 dB peak (center of wall)
Nominal Impedance: 8 ohms (in bypass/thru mode)
Transformer Taps: 80W, 40W, 20W, (& 10W @ 70V), 8 ohm bypass/thru
Transducer:
Driver: 200 mm (8 in) with polypropylene cone, butyl rubber surround, 38 mm (1.5 in) 4-layer copper-clad coil, vented aluminum
former
Enclosure:
Input Connectors: Six removable locking 2-pin connectors with screw-down terminals. Max wire 12 AWG (2.5 mm
2)
Material: Top, bottom, front & bottom: Structural plywood. Port & terminal panels: MDF. Grille: Painted zinc-plated metal.
Dimensions (H x W x D): Cabinet: 356 x 391 x 203 mm (14.0 x 15.4 x 8.0 in)
Wall Bracket: 15 mm (0.6 in) deep
Wall Bracket: 2.3 mm (0.9 in) thick zinc-plated and painted cold-rolled steel
Net Weight: 9.0 kg (20 lbs)
Shipping Weight: 10.2 kg (23 lbs)
Included Accessories: Wall bracket (both speaker and wall parts) with 4 pcs M6 screws to attach to speaker, terminal cover, 6 pcs 2-pin locking
connectors, M6 screw for safety lanyard attachment.
Control 52 Specifications
Frequency Range (-10 dB)1 : 140 Hz – 20 kHz
Frequency Response (±3 dB)1 : 180 Hz – 17 kHz
Power Capacity2 : 50 Watts Continuous Program Power (2 hrs)
25 Watts Continuous Pink Noise (2 hrs)
30 Watts Continuous Program Power (100 hrs)
15 Watts Continuous Pink Noise (100 hrs)
Nominal Sensitivity1 : 85 dB (4.0V/1m = 1W)
82 dB (2.83V, 1m)
Nominal Coverage Angle
3 : 150° x 150° (omnidirectional)
Rated Maximum SPL (1m): 94 dB average, 100 dB peak
Nominal Impedance: 16 ohms
Transducer:
Driver: 60 mm (2.5 in) with polypropylene cone, butyl rubber surround, 19 mm (0.75 in) copper-clad coil, vented Nomex
®former,
secondary bucking magnet, and copper sleeved pole piece for high frequency extension.
Enclosure:
Input Connector: Removable locking 2-pin connector with screw-down terminals. Max wire 12 AWG (2.5 mm
2)
Material: High impact polystyrene, painted zinc-plated metal grille.
Dimensions (H x W x D): Cabinet: 115 x 84 x 96 mm (4.5 x 3.3 x 3.75 in)
Wall bracket: 51 mm (2.0 in)
Net Weight: 0.7 kg (1.5 lbs)
Shipping Weight: 0.8 kg (1.8 lbs)
Included Accessories: Wall bracket (both speaker and wall parts), 2-pin locking connector.
1Half-space (mounted on wall).
2Continuous Pink noise rating is IEC-shaped pink noise with a 6 dB crest factor for 100 hours continuously. Continuous Program Power is a conservative expression of the system’s ability to
handle normal speech and music program material, and is defined as 3 dB above the Continuous Pink Noise rating.
3Half-space, average 1 kHz – 4 kHz
JBL continually engages in research related to product improvement. Changes introduced into existing products without notice are an expression of that philosophy.
Control 52 Dimensions:
Dimensions shown in mm (in)
84 [3.3]
115 [4.5]
51 [2.0]
96 [3.75]
146 [5.8]
57 [2.25]
72 [2.9]
32 [1.25]
52 [2.1]
Control 50S/T Dimensions:
(Shown with wall bracket)
Dimensions shown in mm (in)
217 [8.6]
203 [8.0]
15 [0.6]
13 [0.5]
378 [14.9]
6 mm insert
for secondary
safety cable
115 [4.5]
76 [3.0]
76 [3.0] 356 [14.0]
Control 50S/T On-Wall Bracket Dimensions:
151 [6.0]
147 [5.8]
43 [1.7] 43 [1.7]33 [1.3]
64 [2.5]
58 [2.3]
10 [0.4]
6.4[0.25] dia (x5)
116 [4.5]
SS Control 50
CRP
06/09
䉴Control 50S/T and 52 Surface-Mount Subwoofer-Satellite Loudspeaker System
Subwoofer-Satellite Input / Output Termination:
+ -
Loop
Thru
+ -
IN
+-
Sat 1
+-
Sat 2
+ -
Sat 3
+ -
Sat 4
+
+
+-
-
-
Using Two Control 52
Satellite Loudspeakers
From
Power
Amp
+ -
Loop
Thru
Loop
Thru
+ -
ININ
+ -
Sat 1
+ -
Sat 2
+ -
Sat 3
+ -
Sat 4
+
+
+-
-
-
++
-
-
Using Four Control 52
Satellite Loudspeakers
From
Power
Amp
JBL Professional
8500 Balboa Boulevard, P.O. Box 2200
Northridge, California 91329 U.S.A.
© Copyright 2009 JBL Professional
www.jblpro.com
A Harman International Company
Application Notes:
Subwoofer Placement for Tonal Balance – The location of the subwoofer in relation to wall, floor or ceiling affects the
tonal balance of the system. In systems having two satellite speakers, proper balance of sound is usually best attained
by installing the subwoofer via its wall-mount bracket at the center of a wall (instead of mounting it at a 2-boundary
area such as a wall-floor junction). For systems with four satellite speakers – such as the Control 50PACK System –
mounting the subwoofer in the center of a wall produces good basic bass levels. Locating the subwoofer at a two-
boundary junction, such as a wall-floor or wall-wall junction, provides stronger bass. A corner location provides the
strongest bass for maximum bass impact. In addition to subwoofer placement, external electronics equalization such
as from tone controls or DSP can be utilized to adjust the tonal balance further.
Port Clearance – Do not block the port of the Control 50S/T subwoofer by mounting too close to a side wall. Leave a
minimum of 50 cm (2 feet) of clearance between the port and an adjacent wall surface.
Using Control 52 without Control 50S/T Subwoofer – The Control 52 can be damaged if driven with frequencies
below 140 Hz. The subwoofer provides the proper high-pass filter. For using Control 52 by itself (not driven from the
Control 50S/T’s satellite output), the signal must be high-passed, either via a passive high-pass built into another
subwoofer such as the JBL Control 40CS/T in-ceiling subwoofer, or via an electronic high-pass, electronic crossover, or
DSP (140 Hz, 24 dB/oct recommended). Failing to high-pass the Control 52 can result in damage to the speaker.
Wall Bracket Orientation – Install the wall bracket so that the subwoofer drops down into the bracket. The bracket
clicks into place. Do not install the bracket sideways or on a ceiling. See the Control 50S/T Installation Guide.
To remove the subwoofer, release clip by pushing clip toward the wall with a long screwdriver (or similar)
from the top side of bracket.
Secondary Safety Cable – When installing subwoofer,
always utilize a secondary safety cable attached to the
separate 6 mm insert located on the back/wall side
of the subwoofer.
Frequency Response:
Half-Space (2 , subwoofer & satellites mounted on wall)
Response of each model shown separately.
