Side 1/4

Quick Setup Guide

JBL OnBeat™

VenUe Lt

WeLcOme

Thank you for purchasing the JBL OnBeat

™ Venue LT speaker dock. This quick setup

guide will show you how to connect and set up your dock.

cOnnectIOnS

1. If you are going to use your OnBeat Venue LT with another audio source, plug one end of

a 3.5mm (1/8") stereo cable (not supplied) into the OnBeat Venue LT’s Aux In connector,

and plug the other end into the audio source’s audio out or headphone out connector.

2. Plug the OnBeat Venue LT’s power supply into the Power connector on the unit and into

a working AC power outlet. The OnBeat Venue LT will automatically turn on and go into

the Bluetooth pairing mode (the Bluetooth LED will be flashing blue).

Power

Connector

Aux

Input

PLACEMENT

Place OnBeat Venue LT on a shelf or table with the rear of its enclosure is at least 3"

(76mm) away from a wall or other surface to allow the bass ports to operate properly.

CONTROLS AND INDICATORS

Bass Boost

Button

Movie

Button

Aux Input

LED

Bluetooth

LED

Volume Up/Down

Buttons

Docking Slide (open)

LT Docking Connector

Power

Button

Dock Input

LED

Source

Button

Bass Boost button: Press this button to enhance the bass performance. The button’s

LED will illuminate when Bass Boost is on.

Movie button: Press this button to activate the Movie EQ mode, which creates an

extra-wide sound field to compliment films and other video media. The button’s LED will

illuminate when the Movie mode is on.

Source button: Press this button to cycle through the audio sources: , docked Bluetooth

device and Aux Input. The input LED for the active source will illuminate.

• If you begin to stream audio from a paired Bluetooth device or play audio from a device

connected to the dock while another source is playing, the OnBeat Venue LT will

automatically switch to the new source.

Aux Input LED: This LED illuminates when the Aux Input is the active source.

Dock Input LED: This LED illuminates when the docked device is the active source.

Bluetooth LED: This LED flashes blue when the OnBeat Venue LT is in the Bluetooth

pairing mode, and turns solid blue when it has successfully paired with a device.Bluetooth

Power button: When the OnBeat Venue LT is on, press the Power button to put it into the

standby mode. The button’s LED will illuminate solid amber when the unit is in standby.

When the OnBeat Venue LT is in standby, press the Power button to turn it on. The button’s

LED will illuminate solid white when the unit is on.

Produkt Specifikationer

Mærke:	JBL
Kategori:	Højttaler
Model:	OnBeat Venue LT
Vekselstrømsindgangsspænding:	100 - 240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	415 mm
Dybde:	138 mm
Højde:	130 mm
Brugervejledning:	Ja
Produktfarve:	Sort
Bluetooth:	Ja
FM radio:	Ingen
Udgangseffekt (RMS):	30 W
Strømforbrug (standby):	0.25 W
Strømforbrug (typisk):	24 W
Volumenkontrol:	Digital
Indikatorlampe:	Ja
Hurtig start guide:	Ja
Frekvensområde:	20 - 20000 Hz
Impedens:	8 ohm (Ω)
Lyd-output kanaler:	2.0 kanaler
DC-in-stik:	Ja
Strømkilde type:	Vekselstrøm
AC-adapter inkluderet:	Ja
AUX-indgang:	Ja
Kompatible produkter:	iPhone 5\r\niPad\r\niPad mini\r\niPod touch
Signal/støjforhold:	85 dB
Bas indstillinger:	Ja
Kampatibilitet med Apple-docking:	iPad, iPhone, iPod
Udgangseffekt beskrivelse:	12V, 2A
Indbygget oplader:	Ja
