QUICKSTART GUIDE

UNBOX IT

OPTIONAL SETUPS

1. Open the top of the box.

2. Lay box on its side.

3. Turn box upside down, then

lif t box up to reveal speaker.

1. Floor Standing

2. Monitor

3. Pole Mounted

4. Sub Mounted

5. Suspended

6. Subs with 3-way splayed

1 2 3

1 2 5 63 4

Please visit jblpro.com for complete documentation.

JBL Professional 8500 Balboa Blvd. Northridge, CA 91329 USA © 201 HARMAN International Industries, Incorporated7

PART NUMBER: 5069055-B

PLUG IN THE INPUTS

1. Turn the Gain control knobs all the way to

the lef t. It’s a good idea to turn the inputs

down all the way before plugging in.

2. Connect XLR or TRS cable from audio

source to the inputs.

SET OUTPUT LEVEL

1. Set the gain level for each input using the

Gain controls.

WI-FI CONTROL

1. This device allows for additional control

and conﬁguration features via a WI-FI

application.

Please visit www.jblpro.com for the

application and instructions.

BACK PANEL

POWER IT ON

1. Connect the supplied power cord to the

IEC inlet on the rear of the speaker.

2. Connect the power cord to an available

power outlet.

3. Press the Power switch. The LED power

light will turn blue when powered.

PRX815XLF / PRX818XLF

XLR / ∂” INPUTS

SIGNAL LEDS

GAIN CONTROL

LIMIT LED

FRONT LED

POLARITY SELECT

POLARITY LED

POWER

INPUT/SWITCH

POWER LED

REMOTE EQ LED

THRU CONNECTORS

HI-PASS SELECT

HI-PASS LED

WI-FI CONNECT

WI-FI LINK LED

a. NORMAL/BOOST ( PRX825 & ) PRX835 only

BOOST position when LED is ON

b. MAIN/MONITOR (PRX812 and 815 only)

MONITOR position when LED is ON

SYSTEM EQ LED

PRX812 / PRX815 /

PRX825 / PRX835

SYSTEM EQ*

WI-FI LINK LED

WI-FI CONNECT

POWER

INPUT/SWITCH

POWER LED

REMOTE EQ LED

MIX OUT

50/50 MIX SELECT

50/50 MIX LED

LIMIT LED

GAIN CONTROLS

MIC LED

MIC SELECT

SIGNAL LEDS

XLR / ∂” INPUTS

RCA SIGNAL LED

RCA INPUTS

FRONT LED

Produkt Specifikationer

Mærke:	JBL
Kategori:	Højttaler
Model:	PRX818XLF
