Mounting the camera

Look for a locaon that will give you the best view behind the vehicle.This should not be

directly next to or under a reverse/backup lamp as it may blind the camera at night.Avoid

license plate lamps as well as they may blind the camera at night. Before drilling,

determine the best way to run the power wires to the reverse lights & the extension cable

through the car.Insure that your route will not interfere with any safety equipment,trunk

release or other items in the vehicle.Look for wires, sensors,double metal,anything that

could cause a problem or damage.The camera should lay ﬂat against the mounng surface

for proper installaon.

1.Use the included hardware to secure the camera to the vehicle.DO NOT OVERTIGHTEN the hardware.

2.Follow ONE of the following wiring opons.

Oprion 1: Connect camera power wire to the vehicle's reverse lamp:

a)Locate the reverse lamp in the tail light assembly.

b)Aach the red wire to the posive 12 volt wire from the reverse lamp.Use a crimp connector or soldering tool to ensure connecon

is secure. Once this connecon is complete,note that the red power wire that is located on either end of the video RCA cable will not

be needed. The bare wire at the end of each wire lead should be capped or taped oﬀ to prevent potenal power interrupon.

c)Aach the black wire to ground(-).

d)Run video cable to the locaon of the receiver or monor(not included).Connect one yellow RCA end of the video cable to the

camera and connect the other end of the yellow RCA cable to the video source(receiver/monitor).

e)Run audio cable to the locaon of the receiver or monor(not included).Connect one black RCA end of the audio cable to the

camera and connect the other end of the back RCA cable to the audio source(receiver/monitor).

Opon 2: Connect camera power wire to receiver/monitor power:

a)From camera locaon,connect red power wire from power cable to red power wire from one end of the video cable.Use a crimp

connector or soldering tool to ensure connecon is secure.

b)Aach the black wire to ground.

c)Run video cable to the locaon of the receiver or monitor(not included).Connect not yellow RCA end of the video cable to the

camera and connect the other end of the yellow RCA cable to the video source(receiver/monitor).

d)From video source(receiver/monitor) locaon,connect red power wire from end of the video cable to the reverse wire lead located

on the video source(receiver/monitor).

e)Run audio cable to the locaon of the receiver or monitor(not included).Connect not black RCA end of the audio cable to the camera

and connect the other end of the black RCA cable to the audio source(receiver/monitor).

Camera Specifications

Image Sensor: CMOS,7440H

Power: 12V DC,Negave Ground

Power Consumpon: 1 Wa＜

Eﬀecve Pixels: 733H × 493V

Video Format: NTSC

Lux: 0.5＜

White Balance: Auto

Viewing Angle: 170 Degrees

IP Rang: IP67

Operang Temperature: -30 ~ +70℃ ℃

Camera Body: Zinc Alloy

Microphone Specifications

Audio input

of receiver

Camera input

of receiver

1.6 Ft.

Sensivity: -30±2 dB

Amplifying Power: 0.2 W

S/N Rao(A weighted network): 70(Min) dB

Direconal Characterisc Omni-Direconal：

Maximum Input Sound Pressure Level: 100 dB

Waterproof Rang: IP67
