Mounting the camera

Posion on the license plate top screws for the best viewing angle. This should not be

directly next to or under a reverse/backup/license lamp as it may blind the camera at night.

Before drilling, determine the best way to run the power wires to the reverse lights

and the extension cable through the car. Insure that the route will not interfere with

any safety equipment, trunk release or other items in the vehicle. Look for wires,

sensors, double metal, anything that could cause a problem or damage.

The camera should lay ﬂat against the mounng surface for proper installaon.

1.Fix the camera to the appropriate posion on the license plate and adjust the angle .

2.Follow ONE of the following wiring opons.

OPTION 1: Connect camera power wire to the vehicle's reverse lamp:

a)Locate the reverse lamp in the tail light assembly.

b)Aach the red wire to the posive 12 volt wire from the reverse lamp.Use a crimp connector or soldering tool to ensure connecon

is secure. Once this connecon is complete,note that the red power wire that is located on either end of the video RCA cable will not

be needed. The bare wire at the end of each wire lead should be capped or taped oﬀ to prevent potenal power interrupon.

c)Aach the black wire to ground(-).

d)Run video cable to the locaon of the receiver or monor(not included).Connect one yellow RCA end of the video cable to the

camera and connect the other end of the yellow RCA cable to the video source(receiver/monitor).

e)Run audio cable to the locaon of the receiver or monor(not included).Connect one black RCA end of the audio cable to the

camera and connect the other end of the back RCA cable to the audio source(receiver/monitor).

OPTION 2: Connect camera power wire to receiver/monitor power:

a)From camera locaon,connect red power wire from power cable to red power wire from one end of the video cable.Use a crimp

connector or soldering tool to ensure connecon is secure.

b)Aach the black wire to ground.

c)Run video cable to the locaon of the receiver or monitor(not included).Connect not yellow RCA end of the video cable to the

camera and connect the other end of the yellow RCA cable to the video source(receiver/monitor).

d)From video source(receiver/monitor) locaon,connect red power wire from end of the video cable to the reverse wire lead located

on the video source(receiver/monitor).

e)Run audio cable to the locaon of the receiver or monitor(not included).Connect not black RCA end of the audio cable to the camera

and connect the other end of the black RCA cable to the audio source(receiver/monitor).

Camera Specifications

Image Sensor: CMOS,7440H

Power: 12V DC,Negave Ground

Power Consumpon: 1 Wa＜

Eﬀecve Pixels: 733H × 493V

Video Format: NTSC

Lux: 0.5＜

White Balance: Auto

Viewing Angle: 170 Degrees

IP Rang: IP67

Operang Temperature: -30 ~ +70℃ ℃

A license plate material: Stainless Steel SUS304

Camera Body: Plasc

Microphone Specifications

Audio input

of receiver

Camera input

of receiver

1.6 Ft.

BUCAM400AJ BUCAM400AJ License plate style camera with

built-in microphone.

Sensivity:-30±2 dB

Amplifying Power:0.2 W

S/N Rao(A weighted network):70(Min) dB

Direconal Characterisc:Omni-Direconal

Maximum Input Sound Pressure Level:100 dB

Waterproof Rang:IP67

Power Cable w/ Fuse, A/V Cable

Universal License Plate

Style Camera with Audio

Power/Ground Cables

Red (12V+) and Black (GND-)

(Recommended connection for 12V+ to

reverse light power wire.)
