Side 1/6
Check for damage: We know you will be eager to install your new Speakers, however, please rstly inspect
your units for any damage. If you nd a problem please contact us immediately at info@bdimports.com.au
Elite-101
Elite-202
Elite- 303
Break in Period:
Premium grade parts and materials are used in these Elite-101/202/303 products so maximum performance can be obtained in
damp and dusty environments such as wall and ceiling cavity. aer which me Bass Break In period is appx 10-20 playing hours
will improve. There is no need to limit playback volume at all during this me.
Wall cut tool
Supplied
Template
Philips screw driver
Stud Finder
Wall Cavity
Depth required:
Elite-101 85mm
Elite-202 62mm
Elite-303 75mm
Elite- 606
See separate manual
Glass
The -Wall / In-Ceiling Speakers Ulmate In
Step 1: Advanced Planning
Decide the placement for your speakers. Advance planning in regards to the placement of your
speakers is crical. It is imperave that the wall or ceiling cavity be free from debris, moisture,
insulaon, and any materials that are easily combusble. The mounng locaon must also be void of wall studs
or bracing in the locaon for the cutout. Adequate Wall Cavity depth (see above to allow speakers to t ush to )
the wall or ceiling surface is important. If you are unsure of the contents of the wall in which you wish to mount
the speakers, Electronic Stud Finders work very well (see FIG 1), otherwise professional installer can assist here. a
Stud Finder
FIG 1.
Congratulaons for buying the best on the planet ! In-Wall Speakers
Please read this manual carefully understanding that advanced planning is essenal.
FIG 2.
Step 4 Cung the Wall / Ceiling :
Using the appropriate wall-cung tool, blade or Stanley knife, accurately cut the hole in the wall material,
based on the correct cut-out dimension (see FIG 3) .
Step 5: Installing Speaker Leads
For Elite-101 and 202, from your Receiver run one speaker cable thru the wall/ceiling to each Le and Right speaker (see FIG 4). For
Elite- TWO303, run speaker cables thru the wall/ceiling to each Elite-303 as this model has inbuilt Centre/Le and Centre/Right
speakers as well as Le and Right. (See FIG 5 and FIG 7). In both cases, leave enough slack in wire so that it can hang out of hole.
Step 3: Template:
Use the supplied template and mark the cut-out on the wall or ceiling. To mark, simply trace with a pencil,
along perforated line (see FIG 2 Ensure your markings are level.).
Step 2: Fing Glass Grills
Fit Elite-101 grills squarely and certain 4 magnets grab and not just 2 or 3 align all 8 pins then gently press be ALL . For Elite-202/303,
Glass panel into rubber bushes. When removing, pull a lile from top, then from boom to remove evenly.
Step 7: Mounng Speakers Insert the enre speaker into the hole. Move Speaker wire away
from back of cone to avoid a possible rale. Using a Phillips head screwdriver, ghten the screws aached to
the dog clamps unl you feel Dog Clamps take grip (9~10 FULL TURNS). At this point you can see the gap
between Speaker Frame and wall/ceiling close fully. Then, See FIG 6. NIP THESE UP - DO NOT OVERTIGHTEN.
Note: If you are unable to install these speakers yourself, please contact an authorized electrician or
installaon contractor.
Matching Subwoofer : Elite- 606:
140 Was RMS, Heavy-Duty driver with 40oz magnet is perfectly matched “monster” and 2”Voice Coil
to ALL Speakers. Available in stunning -Gloss White or Black. See separate Info Manual. JENSEN Hi
Step 6: Red- -Red & Black to Black to
Connect the speaker wire from the posive (RED+) terminal on the receiver to the posive (RED+) terminal on the speaker. Connect
the negave (BLACK-) the same way to the negaves. Note: If you inadvertently reverse one of the connecons (i.e. RED to BLACK)
you will noce a severe lack of Bass from your system. This is called wiring your system “Out of Phase”. If this occurs, check the wiring
and reconnect as necessary.
Sound Sengs
Boost switch. Adjust Elite 202 / 303 Treble switches to suit your sound preference -.
If using a Subwoofer set to (+) to fully maximize performance. Note: Elite-101 has no switches but is
factory preset to Max Boost (+).
Eyeball Tweeters. You can adjust the angle of the Tweeter slightly in order to compensate for poor
mounng locaons. Do this by adjusng Tweeter casing. in any way as DO NOT touch the Tweeter
permanent damage may occur.
FIG 3.
Elite-101, 202 & 303
Once nal mounng posions are
determined, pencil and use
template (supplied) to mark the
wall and cut-out.
Template
Boost switches.
Eyeball Tweeters
Elite
606
Elite-101
Elite-202
Elite-303
JENSEN
