PSG 9080
Programmable signal generator
1. TABLE OF CONTENTS
1. General information
2. Safety instructions
3. Overview front and rear side
4. Function keys
5. Screen overview
6. Basic first steps
7. Modulation mode
8. Measuring mode
9. Sweep mode
10. Voltage Control Mode (VCO)
11. Programming mode
12. System settings
13. Troubleshooting
14. Additional information
15. Support
1. GENERAL INFORMATION
Dear customer,
thank you very much for choosing our product.
In the following, we will introduce you to what to observe while starting up
and using this product.
Should you encounter any unexpected problems during use, please do not
hesitate to contact us.
The PSG9080 function/arbitrary waveform generator can output basic
waveforms (sine wave, square wave, triangle wave, pulse wave and custom
waveforms) from one of the channels individually or both channels simul-
taneously. At start up, the two channels are configured to output a sine -
waveform with a frequency of 10kHz and an amplitude of 5Vpp by default.
Users can configure the unit to output dierent basic waveforms.
The PSG9080 has these functions: Amplitude, frequency, phase modulati-
on, amplitude shi keying, frequency shi keying, phase shi keying, pulse -
width modulation and burst function. It can measure the frequency, period
and length of input signals and count the periods. It also has a sampling
mode and a voltage control mode.
The button layout and 3.5" colour LCD are intuitive and easy to use. You
can save several settings in groups so you can load them quickly. The
menu can be set in German, English and French.
