An Internet connection is required for the use of the Red Bull MEDIA HOUSE PORTAL.

See “Network/Internet access” after ﬁ rst installation.

Operating Instructions Part 1 UFS 924

Connection and setup English

Safety instructions - important notes ............. 2

Items supplied .................................................. 5

Connection and setup ...................................... 6

Front/rear view of the receiver (front flap

open) ................................................................ 6

Inserting batteries into the remote control ........ 8

Connecting the receiver ................................... 9

TV connection .................................................. 9

Audio connection ............................................ 10

Digital .................................................................... 10

Analogue ............................................................... 10

Connecting up the video/DVD recorder ......... 10

Information about antenna connection and

loop-through mode ......................................... 11

First installation .............................................. 12

Network/Internet access ................................. 44

Common Interface (CI)/Smartcard reader ...... 46

Inserting the Smartcard and the CI Module ........... 46

Troubleshooting ............................................. 47

Service ............................................................. 48

Technical Appendix ........................................ 49

Advanced connection example ...................... 49

Technical data ................................................ 50

Sat IF connection examples ........................... 51

Individual reception systems ................................. 51

Community antenna network systems

(4 x Sat IF) ............................................................. 51

Community antenna systems (8 x Sat IF),

Multifeed ................................................................ 52

Community antenna systems (16 x Sat IF),

Multifeed ................................................................ 52

Single cable systems ............................................. 53

Connection Examples for the Network

Function ......................................................... 55

DHCP (Receiver): ON ........................................... 55

DHCP (Receiver): ON ........................................... 56

DHCP (Receiver): ON ........................................... 57

DHCP (Receiver): OFF.......................................... 58

DHCP (Receiver): OFF.......................................... 59

DHCP (Receiver): OFF.......................................... 60

For your notes ................................................ 61

If you do not know the conﬁ guration of your satellite reception system, contact your

specialist dealer for the ﬁ rst installation of your receiver.

Mains power cable

Make sure that the mains cable

(power supply cable) is not damaged.

Units with a damaged mains cable

must be disconnected from the mains

(unplug it at the socket) and repaired

by an electrical specialist before

setup. Only use the power supply unit

supplied (if available)!

Mortal danger due to electric shock!

Danger!

Cleaning

Disconnect the mains plug before

cleaning the unit. Use a dry cloth for

cleaning and only clean the outer

surface. Never open the casing of the

unit.

Touching the parts inside the unit

carries a risk of death due to electric

shock!

Playing children

Make sure that children do not push

any objects into the ventilation slots.

Mortal danger due to electric shock!

Earthing

The antenna system must be earthed

as speci ed or equipotentially f

bonded.

EN 60728/11 and any national

regulations must be complied with.

Risk of voltage surges due to lightning

strikes!

Power supply voltage

Only operate the unit at the speci f ed

mains voltage (indicated on the rear of

the unit or on the external power pack).

The unit may only be connected to the

mains and turned on once it has been

connected to the antenna and to the

TV set or the cable network and PC.

If the mains voltage is too high, there

is a risk of ﬁ re!

Moisture, direct sunlight, heat,

naked ﬂ ames

Protect the unit against moisture,

dripping and splashed water (do not

place any lled objects such as vases f

on top of the unit). Do not place the

unit close to a heater or expose it to

direct sunlight and do not operate it

in damp locations. Only use the unit

in a moderate climate, not in tropical

conditions! Do not place naked f ames

such as candles on top of the unit!

There is a risk of ﬁ re!

Ventilation

The heat generated in this unit is

adequately dissipated. However ,

the unit should never be installed

in a cupboard or on shelves with

inadequate ventilation. Never

cover the cooling slots on the

unit (e.g. with other equipment,

magazines, tablecloths, clothing or

curtains)!

Batteries

If your unit was supplied with batteries

(e.g. for the remote control), take care

that the batteries are not exposed

to excessively high temperatures,

direct sunlight or f re. Replace the

batteries only with types that are

identical or equivalent, otherwise

the batteries or the remote control

may be damaged. Also comply with

the safety instructions stated on

the batteries:

There is a risk of explosions!

Warning!

These two pages contain important information about the operation, installation location and connection of

the unit. Read these instructions carefully before setting up the unit.

Safety instructions - important notes

Do not

cover

Produkt Specifikationer

Mærke:	Kathrein
Kategori:	Digital dekoder
Model:	UFS 924sw
Vekselstrømsindgangsspænding:	230 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	435 mm
Dybde:	273 mm
Højde:	67 mm
Vægt:	3600 g
Brugervejledning:	Ja
Produktfarve:	Sort
Indbygget skærm:	Ja
Kompatible hukommelseskort:	SD
Wi-Fi:	Ingen
Understøttede videotilstande:	1080i,1080p,576p,720p
System for digitalt signalformat:	DVB-S,DVB-S2
Antal HDMI-porte:	1
Ethernet LAN-porte (RJ-45):	1
Antal USB 2.0-porte:	3
Digital akustisk og optisk udgang:	1
Antal SCART-porte:	2
Ethernet LAN:	Ja
Elektronisk programguide (EPG):	Ja
Skærmvisning (OSD):	Ja
OSD-sprog:	CZE,DEU,DUT,ENG,ESP,FRE,ITA,POL,RUS,TUR
Tekst-tv-funktioner:	Ja
Understøttede videoformater:	H.264,MPEG1,MPEG2
Understøttede lydformater:	AC3,HE-AAC,MP3
Strømforbrug (standby):	0.5 W
Strømforbrug (typisk):	22 W
Driftstemperatur (T-T):	5 - 40 °C
Ethernet LAN-datahastigheder:	10,100 Mbit/s
Skærm:	LCD
Kabler inkluderet:	AC,HDMI
Batterier inkluderet:	Ja
Fjernbetjening inkluderet:	Ja
Frekvensområde:	950 - 2150 Mhz
Lyd-output kanaler:	- kanaler
Indbygget kortlæser:	Ja
HDMI:	Ja
Indbygget HDD:	Ja
HDD kapacitet:	500 GB
S/PDIF-udgang:	Ja
Digital koaksial lydudgang:	1
Komponent video (YPbPr/YCbCr) udgang:	3
Tidsforskydning:	Ja
Antal tunere:	2 tuner(e)
Styring af digital satellit-udstyr (DiSEqC):	1.0,1.1,1.2
Signalkilde:	Ethernet (RJ-45),Satellite
HDD-optagelse:	Ja
