KEF.COM
Not all models / nishes are available in all markets. Contact your local dealer for specic range details.
KEF reserves the right, in line with continuing research and development, to amend or change specications. E&OE.
THX and the THX logo are trademarks of THX Ltd. which are registered in some jurisdictions. All rights reserved.
Ci specifications sheet
Extreme Theatre
Tall Rectangle
Model Ci5160REF-THX Ci3160REF-THX Ci5160RL-THX Ci3160RL-THX Ci4100QL-THX
Series Reference Series Reference Series R Series R Series Q Series
Nominal impedance 4Ω 4Ω 4Ω 4Ω 4Ω
Sensitivity (2.83V/1m) 90dB 90dB 90dB 90dB 89dB
Frequency response (±6dB)
open-backed 40Hz - 28kHz 40Hz - 28kHz 40Hz - 28kHz 45Hz - 28kHz 55Hz - 28kHz
Frequency range (-10dB) 35Hz - 45kHz 35Hz - 45kHz 35Hz - 45kHz 35Hz - 45kHz 40Hz - 30kHz
Nominal coverage (degrees) 150° 150° 150° 150°115°
Max SPL (dB) 116dB 110dB 111dB 106dB 104dB
Crossover frequency 400Hz, 2.8kHz 350Hz, 2.7kHz 300Hz, 2.4kHz 340Hz, 2.5kHz 2.2kHz
Drive units
LF 4 x 160 mm (6.5 in.) 2 x 160 mm (6.5 in.) 4 x 160 mm (6.5 in.) 2 x 160 mm (6.5 in.) 3 x 100 mm (4 in.)
MF 125 mm (5.25 in.) Uni-Q 125 mm (5.25 in.) Uni-Q 160 mm (6.5 in.) Uni-Q 160 mm (6.5 in.) Uni-Q 100 mm (4 in.) Uni-Q
HF 25 mm (1 in.) 25 mm (1 in.) 25 mm (1 in.) 25 mm (1 in.) 19 mm (0.75 in.)
Recommended amplier power 40 - 500 W 40 - 350 W 40 - 250 W 30 - 180 W 10 - 150 W
Recommended high-pass lter (Hz) 35Hz - 80Hz*40Hz*40Hz - 80Hz*40Hz - 80Hz*55Hz
Product external dimensions
(H x W x D)
1070 x 230 x 105.7 mm
(42.13 x 9.06 x 4.16 in.)
680 x 230 x 105.7 mm
(26.77 x 9.06 x 4.16 in.)
1070 x 230 x 105.7 mm
(42.13 x 9.06 x 4.16 in.)
680 x 230 x 105.7 mm
(26.77 x 9.06 x 4.16 in.)
490 x 128 x 81 mm
(19.29 x 5.04 x 3.19 in.)
Cut-out dimensions
(H x W)
1052 x 209 mm
(41.42 x 8.23 in.)
660 x 209 mm
(25.98 x 8.23 in.)
1052 x 209 mm
(41.42 x 8.23 in.)
660 x 209 mm
(25.98 x 8.23 in.)
476 x 114 mm
(18.74 x 4.49 in.)
Net weight 22.0 kg (48.5 lbs.) 13.4 kg (29.54 lbs.) 19 kg (41.89 lbs) 11.7 kg (25.79 lbs) 3 kg (6.61 lbs)
Mounting depth from surface 99 mm (3.9 in.) 99 mm (3.9 in.) 99 mm (3.9 in.) 99 mm (3.9 in.) 76 mm (3 in.)
Optional rough in frame RIF5160L RIF5160LRIF3160L RIF3160L RIF4100L
Ideal Rear Volume (L) 90L 90L60L 60L 15L
Minimum Rear Volume (L) 40L 40L30L 30L 7L
Certication THX ULTRA2 THX ULTRA THX ULTRA THX ULTRA2 THX SELECT2, IP64
* Recommended high-pass lter for THX spec: 80Hz
KEF.COM
Not all models / nishes are available in all markets. Contact your local dealer for specic range details.
KEF reserves the right, in line with continuing research and development, to amend or change specications. E&OE.
THX and the THX logo are trademarks of THX Ltd. which are registered in some jurisdictions. All rights reserved.
Ci specifications sheet
Model Ci200RS -THX Ci2 00RR-THX Ci160 RR-THX
Series R Series R Series R Series
Nominal impedance 4Ω 4Ω 4Ω
Sensitivity (2.83V/1m) 90dB 90dB 90dB
Frequency response (±6dB)
open-backed 33Hz - 28kHz 33Hz - 28kHz 52Hz - 24kHz
Frequency range (-10dB) 28Hz - 35kHz 28Hz - 45kHz 38Hz - 30kHz
Nominal coverage (degrees) 120° 120° 130°
Max SPL (dB) 106dB 106dB 105dB
Crossover frequency 2.2kHz 2.2kHz 2.1kHz
Drive units
LF 200 mm (8 in.) Uni-Q
200 mm (8 in.) Uni-Q 165 mm (6.5 in.) Uni-Q
HF 38 mm (1.5 in.)
38 mm (1.5 in.) 25 mm (1 in.)
Recommended amplier power 10 - 190 W
10 - 190 W 10 - 190 W
Recommended high-pass lter (Hz)
35Hz - 80Hz* 35Hz - 80Hz* 38Hz
Product external
dimensions
(H x W x D)
273 x 273 x 132.6 mm
(10.75 x 10.75 x 5.22 in.)
- -
Diameter Ø
-
290 mm (11.42 in.) 236 mm (9.24 in.)
Depth
-
132.6 mm (5.22 in.) 115 mm (4.53 in.)
Cut-out dimensions
(H x W)
240 x 240 mm
(9.45 x 9.45 in.)
- -
Diameter Ø
-
238 mm (9.37 in.) 196 mm (7.71 in.)
Net weight 3.6 kg (7.94 lbs.)
3.6 kg (7.94 lbs.) 2.94 kg (6.48 lbs.)
Mounting depth from surface
127 mm (5 in.)
126.5 mm (4.98 in.) 110 mm (4.33 in.)
Optional rough in frame RIF200S
RIF200R -
Ideal Rear Volume (L) 20L 20L 20L
Minimum Rear Volume (L) 10L 10L 10L
Certication THX ULTRA2, IP64 THX ULTRA2, IP64 THX ULTRA
Extreme Theatre
Square / Round
* Recommended high-pass lter for THX spec: 80Hz
