KEF.COM
Not all models / nishes are available in all markets. Contact your local dealer for specic range details.
KEF reserves the right, in line with continuing research and development, to amend or change specications. E&OE.
THX and the THX logo are trademarks of THX Ltd. which are registered in some jurisdictions. All rights reserved.
Ci specifications sheet
Extreme Theatre
Tall Rectangle
Model Ci5160REF-THX Ci5160RL-THX Ci3160RL-THX
Series Reference Series R Series R Series
Nominal impedance 4Ω 4Ω 4Ω
Sensitivity (2.83V/1m) 90dB 90dB 90dB
Frequency response (±6dB)
open-backed 40Hz - 28kHz 40Hz - 28kHz 45Hz - 28kHz
Frequency range (-10dB) 35Hz - 45kHz 35Hz - 45kHz 35Hz - 45kHz
Nominal coverage (degrees) 150° 150° 150°
Max SPL (dB) 116dB 111dB 106dB
Crossover frequency 400Hz, 2.8kHz 300Hz, 2.4kHz 340Hz, 2.5kHz
Drive units
LF 4 x 160 mm (6.5 in.) 4 x 160 mm (6.5 in.) 2 x 160 mm (6.5 in.)
MF 125 mm (5.25 in.) Uni-Q 160 mm (6.5 in.) Uni-Q 160 mm (6.5 in.) Uni-Q
HF 25 mm (1 in.) 25 mm (1 in.) 25 mm (1 in.)
Recommended amplier power 40 - 500 W 40 - 250 W 30 - 180 W
Recommended high-pass lter (Hz) 35Hz - 80Hz*40Hz - 80Hz*40Hz - 80Hz*
Product external dimensions
(H x W x D)
1070 x 230 x 105.7 mm
(42.13 x 9.06 x 4.16 in.)
1070 x 230 x 105.7 mm
(42.13 x 9.06 x 4.16 in.)
680 x 230 x 105.7 mm
(26.77 x 9.06 x 4.16 in.)
Cut-out dimensions
(H x W)
1052 x 209 mm
(41.42 x 8.23 in.)
1052 x 209 mm
(41.42 x 8.23 in.)
660 x 209 mm
(25.98 x 8.23 in.)
Net weight 22.0 kg (48.5 lbs.) 19 kg (41.89 lbs) 11.7 kg (25.79 lbs)
Mounting depth from surface 99 mm (3.9 in.) 99 mm (3.9 in.) 99 mm (3.9 in.)
Optional rough in frame RIF5160L RIF5160L RIF3160L
Ideal Rear Volume (L) 90L 90L 60L
Minimum Rear Volume (L) 40L 40L 30L
Certication THX ULTRA2 THX ULTRA2 THX ULTRA2
* Recommended high-pass lter for THX spec: 80Hz
Ci4100QL-THX
Q Series
4Ω
89dB
55Hz - 28kHz
40Hz - 30kHz
150°
104dB
2.2kHz
3 x 100 mm (4 in.)
100 mm (4 in.) Uni-Q
19 mm (0.75 in.)
10 - 150 W
55Hz
490 x 128 x 81 mm
(19.29 x 5.04 x 3.19 in.)
476 x 114 mm
(18.74 x 4.49 in.)
3 kg (6.61 lbs)
76 mm (3 in.)
RIF4100L
15L
7L
THX SELECT2, IP64
KEF.COM
Not all models / nishes are available in all markets. Contact your local dealer for specic range details.
KEF reserves the right, in line with continuing research and development, to amend or change specications. E&OE.
THX and the THX logo are trademarks of THX Ltd. which are registered in some jurisdictions. All rights reserved.
Ci specifications sheet
Model Ci200R R-TH X Ci20 0R S-TH X
Series R Series R Series
Nominal impedance 4Ω 4Ω
Sensitivity (2.83V/1m) 90dB 90dB
Frequency response (±6dB)
open-backed 33Hz - 28kHz 33Hz - 28kHz
Frequency range (-10dB) 28Hz - 45kHz 28Hz - 35kHz
Nominal coverage (degrees) 120° 120°
Max SPL (dB) 106dB 106dB
Crossover frequency 2.2kHz 2.2kHz
Drive units
LF
200 mm (8 in.) Uni-Q
200 mm (8 in.) Uni-Q
HF
38 mm (1.5 in.)
38 mm (1.5 in.)
Recommended amplier power
10 - 190 W
10 - 190 W
Recommended high-pass lter (Hz)
35Hz - 80Hz* 35Hz - 80Hz*
Product external
dimensions
(H x W x D) -
273 x 273 x 132.6 mm
(10.75 x 10.75 x 5.22 in.)
Diameter Ø 290 mm (11.42 in.)
-
Depth 132.6 mm (5.22 in.)
-
Cut-out dimensions
(H x W) -
240 x 240 mm
(9.45 x 9.45 in.)
Diameter Ø 238 mm (9.37 in.)
-
Net weight
3.6 kg (7.94 lbs.)
3.6 kg (7.94 lbs.)
Mounting depth from surface 126.5 mm (4.98 in.)
127 mm (5 in.)
Optional rough in frame
RIF200R
RIF200S
Ideal Rear Volume (L) 20L 20L
Minimum Rear Volume (L) 10L 10L
Certication THX ULTRA2, IP64 THX ULTRA2, IP64
Extreme Theatre
Round / Square
* Recommended high-pass lter for THX spec: 80Hz
