Side 1/107
B5A-2061-00 (K)© 2017 JVC KENWOOD Corporation
DNX694S
DNX574S
GPS NAVIGATION SYSTEM
INSTRUCTION MANUAL
Take the time to read through this instruction manual.
Familiarity with installation and operation procedures will help you obtain the best performance from your new
GPS Navigation System.
For your records
Record the serial number, found on the back of the unit, in the spaces designated on the warranty card, and in the space
provided below. Refer to the model and serial numbers whenever you call upon your KENWOOD dealer for information or
service on the product.
Model DNX694S/ DNX574S Serial number
US Reside nce Only
Register Online
Register your KENWOOD product at www.kenwood. com/usa/
• Updated information (the latest Instruction Manual, system updates, new
functions, etc.) is available from
<http://www.kenwood.com/cs/ce/>.
• The Instruction manual is subject to change for modification of
specifications and so forth. Be sure to download the latest edition of the
Instruction manual for reference.
<http://manual.kenwood.com/edition/im393/>
2
Contents
Before Use 4
Precautions ................................................................... 4
Safety Precautions
and Important Information ................................. 5
How to read this manual ......................................... 6
Basic Operations 7
Functions of the Buttons on the Front Panel ... 7
Turning on the Unit ................................................... 8
Initial Settings .............................................................. 9
Adjusting the volume .............................................10
Touch screen operations .......................................10
HOME screen descriptions ....................................11
Source selection screen descriptions ................11
Source control screen descriptions ...................13
Popup menu ..............................................................14
List screen ...................................................................15
Navigation Operation .............................................16
Disc 20
Playing a disc .............................................................20
DVD/ VCD Basic Operation ....................................20
Music CD/ Disc media Basic Operation ............22
Search Operation ......................................................23
DVD Disc Menu Operation ....................................24
DVD Setup ...................................................................25
USB/microSD 26
Connecting a USB device ......................................26
Inserting the microSD .............................................26
USB/microSD Basic Operation .............................27
Search Operation ......................................................28
iPod/iPhone 29
Preparation .................................................................29
iPod/iPhone Basic Operation ...............................30
Search Operation ......................................................31
APPS—Android Auto™/
Apple CarPlay 32
Apple CarPlay Operation .......................................32
Android Auto™ Operation .....................................33
Pandora® Operation ................................................35
Spotify Operation .....................................................37
HD Radio™ Tuner 39
HD Radio Tuner Basic Operation .........................39
Receive Mode ............................................................41
Memory Operation ..................................................41
Selecting Operation ................................................42
Bookmark ....................................................................43
Alert Message ............................................................45
SiriusXM® 46
SiriusXM® Basic Operation ....................................46
Storing Channels in Preset Memory ..................48
Preset select ...............................................................48
Direct search ..............................................................49
Category/Channel search ......................................49
Replay ...........................................................................50
TuneMix™ ....................................................................50
SmartFavorites, TuneStart™ ..................................50
TuneScan™ ..................................................................51
Traffic & Weather Now™ .........................................51
Content Alerts............................................................52
SportsFlash™ ..............................................................52
SiriusXM Setup ..........................................................53
3English
Bluetooth Control 58
Information for using Bluetooth® devices .......58
Register from the Bluetooth device ...................59
Bluetooth Setup ........................................................60
Playing Bluetooth Audio Device .........................62
Using Hands-Free Unit ............................................64
Hands-Free Setup .....................................................68
Other External Components 69
View Camera ..............................................................69
Use Dashboard Camera..........................................70
External audio/video players—AV-IN ...............71
OEM Features Operation .......................................71
Setting Up 72
Monitor Screen Setup .............................................72
System Setup .............................................................72
User Interface Setup ................................................72
Special Setup .............................................................74
Display Setup .............................................................74
AV Setup ......................................................................76
Controlling Audio 77
Speaker/ X’over setup .............................................77
Controlling General Audio ....................................78
Equalizer Control ......................................................79
Volume Offset ............................................................80
Zone Control ..............................................................80
Sound Effect ...............................................................81
Listening Position/ DTA ..........................................82
Remote control 84
Battery Installation ...................................................84
Functions of the Remote control Buttons .......85
Connection/Installation 88
Before Installation ....................................................88
Installing the unit .....................................................90
Troubleshooting 96
Problems and Solutions .........................................96
Error Messages ..........................................................96
Appendix 98
Playable Media and Files........................................98
Region Codes in the World ................................ 100
DVD Language Codes .......................................... 101
Specifications .......................................................... 102
About this Unit ....................................................... 105
Before Use
4
Before Use
Precautions
# WARNINGS
Ñ To prevent injury or fire, take
the following precautions:
• To prevent a short circuit, never put or leave
any metallic objects (such as coins or metal
tools) inside the unit.
• Do not watch or fix your eyes on the unit’s
display when you are driving for any extended
period.
• If you experience problems during installation,
consult your KENWOOD dealer.
Ñ Precautions on using this unit
• When you purchase optional accessories,
check with your KENWOOD dealer to make
sure that they work with your model and in
your area.
• You can select language to display menus,
audio file tags, etc. See User Interface Setup
(P.72).
• The Radio Data System or Radio Broadcast
Data System feature won’t work where the
service is not supported by any broadcasting
station.
• The unit may not function properly if the
connectors between the unit and front panel
are dirty. Detach the front panel and clean the
connector with a cotton swab gently, being
careful not to damage the connector.
Ñ Protecting the monitor
• To protect the monitor from damage, do not
operate the monitor using a ball point pen or
similar tool with the sharp tip.
Ñ Cleaning the unit
• If the faceplate of this unit is stained, wipe it
with a dry soft cloth such as a silicon cloth. If
the faceplate is stained badly, wipe the stain
off with a cloth moistened with neutral cleaner,
then wipe it again with a clean soft dry cloth.
NOTE
• Applying spray cleaner directly to the unit may
affect its mechanical parts. Wiping the faceplate
with a hard cloth or using a volatile liquid such
as thinner or alcohol may scratch the surface or
erase screened print.
Ñ Lens fogging
When you turn on the car heater in cold
weather, dew or condensation may form on
the lens in the disc player of the unit. Called
lens fogging, this condensation on the lens
may not allow discs to play. In such a situation,
remove the disc and wait for the condensation
to evaporate. If the unit still does not operate
normally after a while, consult your KENWOOD
dealer.
Ñ Precautions on handling discs
• Do not touch the recording surface of the disc.
• Do not stick tape etc. on the disc, or use a disc
with tape stuck on it.
• Do not use disc type accessories.
• Clean from the center of the disc and move
outward.
• When removing discs from this unit, pull them
out horizontally.
• If the disc center hole or outside rim has burrs,
use the disc only after removing the burrs with
a ballpoint pen etc.
• Discs that are not round cannot be used.
• 8-cm (3 inch) discs cannot be used.
• Discs with coloring on the recording surface or
discs that are dirty cannot be used.
• This unit can only play the CDs with
.
• This unit may not correctly play discs which do
not have the mark.
• You cannot play a disc that has not been
finalized. (For the finalization process see your
Before Use
5English
writing software, and your recorder instruction
manual.)
Ñ Acquiring GPS signal
The first time you turn on this unit, you must
wait while the system acquires satellite signals
for the first time. This process could take up
to several minutes. Make sure your vehicle
is outdoors in an open area away from tall
buildings and trees for fastest acquisition.
After the system acquires satellites for the first
time, it will acquire satellites quickly each time
thereafter.
Ñ Caution for Smartphone Users
Simultaneously running multiple applications
on your smartphone while screen sharing places
heavy demand on the microprocessor of the
phone, potentially affecting communication and
performance.
For best results while pairing with your Kenwood
receiver, please be sure to close any unused
applications by performing the following steps:
Android operating system example:
• Turn off WiFi in phone settings menu.
• Close all open applications before connecting
for in-car use. Hold the <Home> key and select
<Close all> to close all open applications.
• Clear RAM Memory of the Android phone
before connecting for in-car use. Hold the
<Home> key and select <Task Manager> then
select <RAM> then select <Clear memory> to
clear current memory processes.
<Home> Key
Safety Precautions and
Important Information
Read this information carefully before starting to
operate the KENWOOD Car Navigation System
and follow the instructions in this manual.
Neither KENWOOD nor Garmin shall be liable for
problems or accidents resulting from failure to
observe the instructions in this manual.
# WARNING
Failure to avoid the following potentially
hazardous situations could result in an
accident or collision resulting in death or
serious injury.
When navigating, carefully compare information
displayed on the navigation system to all
available navigation sources, including
information from street signs, visual sightings,
and maps. For safety, always resolve any
discrepancies or questions before continuing
navigation.
Always operate the vehicle in a safe manner.
Do not become distracted by the navigation
system while driving, and always be fully aware
of all driving conditions. Minimize the amount of
time spent viewing the screen of the navigation
system while driving, and use voice prompts
when possible.
Do not enter destinations, change settings, or
access any functions requiring prolonged use
of the navigation system controls while driving.
Stop your vehicle in a safe and legal manner
before attempting such operations.
Keep the system volume at a low enough level
to be able to hear outside noises while driving.
If you can no longer hear outside noises, you
may be unable to react adequately to the traffic
situation. This may cause accidents.
The navigation system will not display the
correct current position of the vehicle the first
time it is used after purchase, or if the vehicle
battery is disconnected. GPS satellite signals
will soon be received, however, and the correct
position will be displayed.
Be careful of the ambient temperature. Using the
navigation system at extreme temperatures can
lead to malfunction or damage. Also note that
the unit can be damaged by strong vibration,
by metal objects, or by water getting inside the
unit.
Before Use
6
# CAUTION
Failure to avoid the following potentially
hazardous situations may result in injury or
property damage.
The navigation system is designed to provide
you with route suggestions. It does not reflect
road closures or road conditions, weather
conditions, or other factors that may affect safety
or timing while driving.
Use the navigation system only as a navigational
aid. Do not attempt to use the navigation system
for any purpose requiring precise measurement
of direction, distance, location, or topography.
The Global Positioning System (GPS) is operated
by the United States government, which is solely
responsible for its accuracy and maintenance.
The government system is subject to changes
that could affect the accuracy and performance
of all GPS equipment, including the navigation
system. Although the navigation system is a
precision navigation device, any navigation
device can be misused or misinterpreted and,
therefore, become unsafe.
Ñ IMPORTANT INFORMATION
Vehicle Battery Preservation
This navigation system can be used when the
ignition key is turned to ON or ACC. To preserve
the battery, however, it should be used with
the engine running whenever possible. Using
the navigation system for a long time with the
engine switched off can cause the battery to run
down.
Map Data Information
One of the goals of Garmin is to provide
customers with the most complete and
accurate cartography that is available to us at
a reasonable cost. We use a combination of
governmental and private data sources, which
we identify in product literature and copyright
messages displayed to the consumer. Virtually
all data sources contain some inaccurate or
incomplete data. In some countries, complete
and accurate map information is either not
available or is prohibitively expensive.
How to read this manual
• The screens and panels shown in this manual are
examples used to provide clear explanations of the
operations.
For this reason, they may be different from the actual
screens or panels used, or some display patterns may
be different.
• : English indications are used Indication language
for the purpose of explanation. You can select the
indication language from the menu. See [ ]SETUP
User Interface Setup (P.72).
Basic Operations
7English
Basic Operations
Functions of the Buttons on the Front Panel
23 1
5
4
6
7
8
NOTE
• The panels shown in this guide are examples used to provide clear explanations of the operations. For this reason,
they may be different from the actual panels.
Number Name Motion
1
Remote
Sensor
• Receives the remote control signal.
2
Disc insert
slot
• A slot to insert a disc media.
3
microSD
slot
• A slot to insert a microSD.
• You can play audio/visual file in the card. *
• A microSD slot for upgrading the map. For how to upgrade the map, refer to the
instruction manual of the navigation system.
* If the map update file remains in the microSD, you cannot play audio/visual file.
* Do not pull out the MAP SD while "Loading Maps" is being displayed.
4
• Displays the HOME screen (P.11).
• essing for 1 second turns the power off. *Pr
• When the power off, turns the power on.
* The function of the button when held varies depending on the "Manual Power OFF"
setting. (P.74)
5
S R,
(Volume)
• Adjusts volume.
The volume will go up until 15 when you keep pressing .R
6
• Displays the navigation screen. Pressing this switch each time toggles between
current source screen and navigation screen.
7
• Displays the popup menu screen.
• essing for 1 second switches attenuation of the volume on/off.Pr
8
• Displays the APP (CarPlay/ Android Auto) screen. Pressing this switch each time
toggles between current source screen and APP screen.
• essing for 1 second displays the Voice Recognition screen Pr (P.65).
Basic Operations
8
Turning on the Unit
The method of turning on is different depending on the model.
1
Press the button.[ ]
h The unit is turned on.
● To turn off the unit:
1
Press the button for 1 second.[ ]
NOTE
• If it is your first time turning the unit on after installation, it will be necessary to perform Initial setup (P.9).
• The function of the button when held varies depending on the "Manual Power OFF" setting. (P.74)
Basic Operations
10
Calendar/clock settings
1
Press the button.[ ]
h Popup menu appears.
2
Touch .[ ]SETUP
h SETUP Menu screen appears.
3
Touch [User Interface].
h User Interface screen appears.
4
Set each item as follows.
Scroll the page to show the item.
■ Clock
NAV-SYNC (Default): Synchronizes the clock
time with navigation.
Manual: Sets the clock manually.
■ Time Zone
If you have selected for Clock, [ ]Manual
select the time zone.
■ Clock Adjust
If you select for Clock, adjust the [ ]Manual
date and time manually. (P.73)
Adjusting the volume
To adjust the volume (0 to 40),
Press to increase, and press to decrease.[ ]R [ ]S
Holding increases the volume continuously [ ]R
to level 15.
Touch screen operations
To perform operations on the screen, you need
to touch, touch and hold, flick or swipe to
select an item, display setting menu screen or
to change the page, etc.
● Touch
Touch the screen gently to
select an item on the screen.
● Touch and hold
Touch the screen and keep
your finger in place until
the display changes or a
message is displayed.
● Flick
Slide your finger quickly
to the left or right on the
screen to change the page.
You can scroll the list screen
by flicking the screen up/
down.
● Swipe
Slide your finger up or down
on the screen to scroll the
screen.
Basic Operations
11English
HOME screen descriptions
Most functions can be performed from the
HOME screen.
5
4
6 7
1 2 3
1
• Displays the control screen of current source.
• The artwork is displayed if available from
current content.
2
• Widget
– You can change the widget by touching
[] [ ]/ or flicking left or right on the
widget area.
– Touch the widget to display the detailed
screen.
3
• Page indication for widgets
4
• Current source information
5
• Displays the source selection screen. (P.12)
6
• Short-cut playback source icons (P.12)
7
• Displays the Hands Free screen. (P.64)
• When connecting as Apple CarPlay or
Android Auto, it works as a phone provided
in Apple CarPlay or Android Auto.
Display the HOME
1
Press the button.[ ]
h HOME screen appears.
Source selection screen
descriptions
You can display all playback sources and
options on the source selection screen.
3 5
2
4
1
1
• Changes the playback source.
For playback sources, see .P.12
2
• Changes the page. (Touch / .)[ ] [ ]
You can also change the page by flicking left
or right on the screen.
3
• Returns to previous screen.
4
• Page indication
5
• Displays the SETUP Menu screen. (P.72)
Basic Operations
12
Select the playback source
1
Touch on the HOME screen.[ ]
From the screen, you can select the
following sources and functions.
• Displays the navigation screen. (P.16)
• Switches to the Android Auto/ Apple
CarPlay screen from the connected iPod
touch/iPhone/Android device.*1 (P.32)
• Switches to the HD Radio broadcast.
( 39)P.
• Switches to the SiriusXM® satellite radio
broadcast. (P.46)
• Plays a Bluetooth audio player. (P.58)
• Plays a disc. (P.20)
• Plays an iPod/iPhone. (P.29)
• Plays files on a USB device. (P.26)
• Plays files on a microSD. (P.26)
• Switches to the Pandora. (P.35)
• Switches to the Spotify. (P.37)
• Switches to an external component
connected to the AV-IN input terminal.
(P.71)
• Displays the Audio screen. (P.77)
• Puts the unit in standby. (P.13)
*
1 When iPhone compatible with CarPlay is
connected, [Apple CarPlay] is displayed.
When an Android device compatible with
Android Auto is connected, [Android Auto] is
displayed.
• For sources and information displayed when
an ADS adapter is connected, see OEM
Features Operation (P.71).
To select the playback source on the
HOME screen
The 3 items displayed on the source selection
screen as the large icons are shown on the
HOME screen.
You can change items displayed on this area
by customizing the source selection screen.
(P.13)
To select the playback source on the
source control screen
Display source selection buttons by touching
[ ] [ ]/ or flicking left or right on the source
control screen, then select a playback source.
Basic Operations
13English
Put the unit in standby
1
Touch on the HOME screen.[ ]
2
Touch [STANDBY].
Customize Short-cut buttons on
HOME screen
You can arrange the position of the source
icons as you like.
1
Touch on the HOME screen.[ ]
2
Touch and hold the icon which you want
to move to go into the customizing
mode.
3
Drag it where you want to move.
Changes the page
Source control screen
descriptions
There are some functions which can be
operated from most screens.
Indicators
1
2 3 4
Navigation information
Short-cut buttons
1
Connected Bluetooth device information.
• : Lights up when quick charging battery
of the connected iPod/ iPhone/ Smartphone.
2
All sources icon
Displays all sources.
Basic Operations
14
3
Secondary screen
• [ ] [ ]/ : The Secondary screen changes every
time you touch it. You can also change the
Secondary screen by flicking left or right on
the screen.
• Indicators: Displays the current source
condition and so on.
– : The attenuator is active.AT T
– : The dual zone function is on.DUAL
– : The mute function is active.MUTE
– LOUD: The loudness control function is on.
• Navigation information: Displays the current
location and the direction. The screen changes
to the navigation screen when you touch here.
• Short-cut buttons: The source changes to the
one you have set as a short-cut. For the short-
cut setting, refer to Customize Short-cut
buttons on HOME screen (P.13).
4
[ ]Û
Touch to display the Hands Free screen. (P.64)
When connecting as Apple CarPlay or Android
Auto, it works as a phone provided in Apple
CarPlay or Android Auto.
Popup menu
1
Press the button.[ ]
h Popup menu appears.
2
Touch to display the popup menu.
6
The contents of the menu are as follows.
• Displays the Screen Adjustment screen.
( 72)P.
• Turns the display off. (P.15)
• Displays the view camera. (P.69)
• Displays the SETUP Menu screen.
( 72)P.
• Displays the Audio Control Menu screen.
( 77)P.
• Displays the control screen of current
source. Icon feature differs depending on
the source.
• Close the popup menu.
6
• See HOME screen descriptions
( 11)P. .
• Ejects the disc.
• To forcibly eject the disc, press it for
2 seconds and touch after the [ ]Yes
message is displayed.
Basic Operations
18
Control audio from the navigation
screen
You can control audio sources while the
navigation screen is displayed.
Also, you can view the navigation information
while the source control screen is displayed.
(P.13)
1
While playing the audio, touch / [ ] [
] [ ]/ in the navigation screen.
Each time you touch the icon, the screen
switches as follows.
Displays the navigation and control keys of
the current source.
Displays the navigation and current video
playback display.
NOTE
• The screen switches between playback screen
and view camera each time the viewing area
is touched.
Returns to the full navigation screen.
NOTE
• For details on control keys, refer to the
instructions in each section.
• [ ] : It does not appear if the control keys like
AV-IN, etc. are not exist.
• Touching the source icon in the bottom of the
screen displays the full audio screen.
Basic Operations
19English
Navigation Setup
1
Press the button.[ ]
h Popup menu appears.
2
Touch .[ ]SETUP
h SETUP Menu screen appears.
3
Touch .[ ]Navigation
h Navigation SETUP screen appears.
4
Set each item as follows.
■ NAV Mute
Mutes the volume of rear speakers during
voice guidance of the navigation system.
Default is “ON”.
■ NAV Interrupt Speaker
Selects speakers used for voice guidance of
the navigation system.
• : Uses the front left side speaker for Front L
voice guidance.
• : Uses the front right side speaker Front R
for voice guidance.
• (Default): Uses both front Front All
speakers for voice guidance.
■ NAV Voice Volume
Adjusts the volume for voice guidance of the
navigation system. Default is “24”.
KENWOOD Traffic Powered By
INRIX
You can receive INRIX traffic information and
weather forecast by connecting your iPhone or
Android smartphone in which the “KENWOOD
Traffic Powered By INRIX” application is
installed to this unit.
Preparation
• Install the latest version of the KENWOOD Traffic
Powered By INRIX application on your iPhone or
Android.
– iPhone: Search for "KENWOOD Traffic Powered
By INRIX" in the Apple App Store to find and
install the most current version.
– Android: Search for "KENWOOD Traffic Powered
By INRIX" in Google play to find and install the
most current version.
• For details, see “KENWOOD Traffic Powered By
INRIX” application.
1
Register the Smartphone.
To connect a smartphone via Bluetooth,
register it as the Bluetooth device and
do the App (SPP) profile setting of the
connection beforehand. See Register
from the Bluetooth device (P.59) and
Connect the Bluetooth device (P.61).
2
Press the button.[ ]
h Navigation screen appears.
Touch on the Main Menu screen [ ]Apps
and then an icon of your desired content
For details, see Navigation system
manual.
Disc
20
Disc
Playing a disc
Ñ Insert a disc
1 Insert the disc into the slot.
h The unit loads the disc and playback
starts.
Ñ Eject a disc
1 Press the button.[ ]
2 Touch .[ ]G
When removing a disc, pull it horizontally.
NOTE
• This is not displayed on the popup menu screen
of Apple CarPlay or Android Auto source. Change
Apple CarPlay or Android Auto source to other
one to display the popup menu screen.
DVD/ VCD Basic Operation
Most functions can be controlled from the
source control screen and playback screen.
NOTE
• Set the remote control mode switch to DVD
mode before starting operation for DVD and VCD,
see Switch the operation mode (P.85).
• The screen shot below is for DVD. It may be
different from the one for VCD.
1 When the operation buttons are not
displayed on the screen, touch the
7
area.
Control screen
1
2
3
4
5
Video screen
7
6
8
6
1
Information display
Displays the following information.
• , : DVD title and chapter Title # Chapter #
number display
• / VCD track or scene number Track # Scene #:
display. Scene # is displayed only when
Playback control (PBC) is on.
• : Audio formatLinear PCM, etc.
• : Hides the control screen.[ ]Hide
Disc
21English
• : Repeats the current content. Each time [ ]
you touch the key, repeat mode switches in
the following sequence;
DVD: Title repeat ( ), Chapter repeat
( ), Repeat off ( )
VCD (PBC On): Does not repeat
VCD (PBC Off): Track repeat ( ), Repeat off
( )
2
Function panel
Touch on the left side of the screen to display
the function panel. Touch again to close the
panel. For details on the keys, see Function
panel (P.21).
3
Play mode indicator/ Playing time
• , , , etc.: Current play mode indicatorD B I
The meanings of each icon are as follows; D
(play), (fast forward), (fast backward), B A
I (stop), R (resume stop), (pause), (slow H
playback), (slow reverse playback).
4
Function bar
• : Searches the previous/next [ ]E [ ]F
content.
Touch and hold to fast forward or fast
backward.
• : Plays or pauses.[ ]DH
• [ ] : Displays the Graphic Equalizer screen.
(P.79)
5
Indicator Items
• : A disc is inserted.IN
White: A Disc is inside the unit.
Orange: Error at the disc player
VCD
• : Identifies the left audio output 1chLL/2chLL
of channel 1 or 2.
• : Identifies the monaural audio 1chLR/2chLR
output of channel 1 or 2.
• : Identifies the right audio 1chRR/2chRR
output of channel 1 or 2.
• : Identifies the stereo audio 1chST/2chST
output of channel 1 or 2.
• : Identifies the left audio output.LL
• : Identifies the monaural audio output.LR
• : Identifies the right audio output.RR
• : Identifies the stereo audio output.ST
• : The PBC function is on.PBC
• : The VCD version is 1.VER1
• : The VCD version is 2.VER2
6
Searching area
Touch to search the next/previous content.
7
Key display area
Touch to display the control screen.
[
8
MENU CTRL] (DVD only)
Touch to display the DVD-VIDEO disc menu
control screen. See DVD Disc Menu Operation
(P.24).
NOTE
• The control screen disappears when no operation
is done for 5 seconds.
• If you use a remote control, you can jump directly
to the desired image with entering the chapter
number, scene number, play time, etc. (P.85).
Ñ Function panel
1 Touch on the left side of the screen.
DVD VCD
The functions of each key are as follows.
[ ]I
Stops playback. When touched twice, the disc is
played from the beginning when you play it the
next time.
[] [ ]
Fast forward or fast backward. Each time you
touch the key, the speed changes; 2 times, 8
times.
[] [ ] or (DVD only)
Plays in slow motion forward or backward.
[ ]SETUP (DVD only)
Touch to display the DVD SETUP screen. See
DVD Setup (P.25).
[ ]MENU CTRL (DVD only)
Touch to display the DVD-VIDEO disc menu
control screen. See DVD Disc Menu Operation
(P.24).
Disc
22
[ ]PBC (VCD only)
Turn Playback control (PBC) on or off.
Audio] (VCD only)
Change the audio output channel.
Music CD/ Disc media Basic
Operation
Most functions can be controlled from the
source control screen and playback screen.
NOTE
• Set the remote controller mode switch to AUD
mode before starting operation for Music CD
and audio files, see Switch the operation mode
(P.85).
• In this manual, “Music CD” will be referred to as
the general CDs which include music tracks in.
“Disc media” will be referred to as CD/DVD disc
which includes audio or video files.
• The screen shot below is for disc media. It may be
different from the one for CD.
Control screen
4
3
5
2
6
1
7
Content list panel
8
4
1
/ [ ] [ ]
• [ ] : Repeats the current track/folder. Each
time you touch the key, repeat mode switches
in the following sequence;
Track/ File repeat ( ), Folder repeat ( )
(Disc media only), Repeat all ( )
• [ ] : Randomly plays all tracks in current
folder/disc. Each time you touch the key,
random mode switches in the following
sequence;
Track random ( ) (Music CD only), Folder
random ( ) (Disc media only), Random off
( )
2
Track information
Displays the information of the current track/ file.
Only a file name and a folder name are displayed
if there is no tag information. (Disc media only)
3
Function bar
• (Disc media only) : Searches file. For details [ ]1
on search operation, see File search (P.23).
• : Searches the previous/next [ ]E [ ]F
content.
Touch and hold to fast forward or fast
backward.
• : Plays or pauses.[ ]DH
• [ ] : Displays the Graphic Equalizer screen.
(P.79)
4
Function panel (Disc media only)
Touch on the left side of the screen to display
the function panel. Touch again to close the
panel.
• [ ] [ ] : Searches previous/next folder.
5
Content list
Touch on the right side of the screen to display
the Content list. Touch again to close the list.
6
Indicator Items
• : A disc is inserted.IN
White: A Disc is inside the unit.
Orange: Error at the disc player
• : Identifies the video file.VIDEO
• : Identifies the music file.MUSIC
7
Artwork (Disc media only)
/Play mode indicator/ Playing time
The jacket of the currently playing file is
displayed.
D B, , etc.: Current play mode indicator
• The meanings of each icon are as follows; D
(play), (fast forward), (fast backward), B A
H (pause).
8
Content list panel
Displays the playing list. When you touch a track/
file name on the list, playback will start.
Disc
23English
Video screen
10
99
9
Searching file area (Video file only)
Touch to search the next/previous file.
10
Key display area (Video file only)
Touch to display the control screen.
Search Operation (Disc media
only)
You can search music or video files by the
following operations.
NOTE
• If you use a remote control, you can jump directly
to the desired track with entering the track
number. For details, see Direct search mode
(P.85).
Ñ File search
You can search a file according to hierarchy.
1 Touch .[ ]1
h Folder List screen appears.
2 Touch the desired folder.
h When you touch a folder its contents are
displayed.
3 Touch desired item from the content list.
h Playback starts.
NOTE
• For operations in the list screen, see List screen
( 15)P. .
Disc
24
DVD Disc Menu Operation
You can set up some items in the DVD-VIDEO
disc menu.
1 Touch illustrated area during playback.
h Menu Control screen appears.
2 Perform desired operation as follows.
■ Displays the top menu
Touch .*[ ]TOP
■ Displays the menu
Touch .*[ ]MENU
■ Displays the previous menu
Touch .*[ ]Return
■ Enters selected item
Touch .[ ]Enter
■ Enables direct operation
Touch to enter the highlight [ ]Highlight
control mode (P.24).
■ Moves the cursor
Touch , , , .[ ]R [ ]S [ ]C [ ]D
■ Switches the subtitle language
Touch . Each time you touch this [ ]Subtitle
key, language is switched.
■ Switches the audio language
Touch . Each time you touch this key, [ ]Audio
language is switched.
■ Switches the picture angle
Touch . Each time you touch this key, [ ]Angle
picture angle is switched.
* These keys may not function depending on
the disc.
Ñ Highlight control
Highlight control lets you control the DVD
menu by touching the menu key directly on
the screen.
1 Touch in the Menu Control [ ]Highlight
screen.
2 Touch desired item on the screen.
NOTE
• The highlight control is cleared automatically if
you do not operate for a constant time.
Disc
25English
DVD Setup
You can set up the DVD playback functions.
1 Touch illustrated area during playback.
2 Touch on the left side of the screen.
Touch .[ ]SETUP
h DVD SETUP screen appears.
3 Set each item as follows.
■ [
Menu Language Subtitle Language] [ / ]
/ [ ]Audio Language
See Language setup (P.25).
■ Dynamic Range Control
Sets the dynamic range.
Wide: The dynamic range is wide.
Normal: The dynamic range is normal.
Dialog (Default): Makes the total sound
volume larger than other modes. This is
effective only when you are using Dolby
Digital software.
■ Screen Ratio
Sets the screen display mode.
16:9 (Default): Displays wide pictures.
4:3 LB: Displays wide pictures in the Letter
Box format (having black stripes at the top
and bottom of screen).
4:3 PS: Displays wide pictures in the Pan &
Scan format (showing pictures cut at the
right and left ends).
Ñ Language setup
This setting is for the language used in the
menu, subtitle, and voice.
1 Touch the desired item;
[ ] [ ]Menu Language , Subtitle Language ,
[ ]Audio Language .
h Language Set screen appears.
2 Select a language.
For language code, refer to DVD Language
Codes (P.101).
Sets the entered language and returns to
the DVD Setting screen.
NOTE
• To set the DVD’s original language for audio
language, touch .[ ]Original
USB/microSD
26
USB/microSD
Connecting a USB device
1 Connect the USB device with the USB
cable. (P.94)
2 Press the button.[ ]
3 Touch .
4 Touch . [ ]USB (P.12)
Ñ Disconnect the USB device
1 Press the button.[ ]
2 Touch a source other than . [ ]USB
3 Detach the USB device.
Ñ Usable USB device
You can use a mass-storage-class USB device on
this unit.
The word “USB device” appearing in this manual
indicates a flash memory device.
● About file system
The file system should be the one of the
following.
• T16 • T32 • exFAFA FA T • NTFS
NOTE
• Install the USB device in the place where it will
not affect safe driving.
• You cannot connect a USB device via a USB hub
and Multi Card Reader.
• Take backups of the audio files used with this
unit. The files can be erased depending on the
operating conditions of the USB device.
We shall have no compensation for any damage
arising from any erased data.
Inserting the microSD
1 Insert the microSD into the slot until it
clicks.
2 Press the button.[ ]
3 Touch .
4 Touch . [ ]SD (P.12)
Ñ Remove the microSD
1 Push the microSD until it clicks and then
remove your finger from the card. The
card pops up so that you can pull it out
with your fingers.
Ñ Usable SD card.
The unit is capable of playback of microSD/
microSDHC/ microSDXC memory cards
complying with the SD, SDHC or SDXC standard.
USB/microSD
28
Search Operation
You can search music or video files by the
following operations.
1 Touch .[ ]1
2 Touch .[ ]S
3 Select the list type.
NOTE
• For operations in the list screen, see List screen
( 15)P. .
Ñ Category search
You can search a file by selecting category.
1 Touch .[ ]Category List
2 Select whether you search by audio files
or video files .
3 Touch the desired category.
h The list corresponding to your selection
appears.
4 Touch to select desired item in the list.
Repeat this step until you find the desired
file.
Ñ Link search
You can search a file of same artist/album/
genre as the current track.
1 Touch .[ ]Link Search
2 Touch the desired tag type. You can select
from artist, album and genre.
h The list corresponding to your selection
appears.
3 Touch desired item from the content list.
Ñ Folder search
You can search a file according to hierarchy.
1 Touch .[ ]Folder List
2 Touch the desired folder.
When you touch a folder its contents are
displayed.
3 Touch to select desired item in the list.
Repeat this step until you find the desired
file.
iPod/iPhone
30
iPod/iPhone Basic Operation
NOTE
• Set the remote controller mode switch to AUD
mode before starting operation, see Switch the
operation mode (P.85).
Control screen
3
4
2
5
Content list panel
1
7
6
1
/ [ ] [ ]
• [ ] : Repeats the current track/album. Each
time you touch the key, repeat mode switches
in the following sequence;
Song repeat ( ), All songs repeat ( )
• [ ] : Randomly plays all tracks in current
album. Each time you touch the key, random
mode switches in the following sequence;
Song random ( ), Album random ( ),
Random off ( )
2
Track information
• Displays the information of the current file.
• Touch to display the category list screen. See
Category search (P.31).
3
Function bar[
• : Searches track/file. For details on search 1]
operation, see Search Operation (P.31).
• : Searches the previous/next track/E] [ ]F
file. Touch and hold to fast forward or fast
backward.
• : Plays or pauses.[ ]DH
• [ ] : Displays the Graphic Equalizer screen.
(P.79)
4
Content list
Touch on the right side of the screen to display
the Content list. Touch again to close the list.
5
Indicator Items
• : Identifies the music file.MUSIC
6
Artwork/ Play mode indicator/ Playing
time
The jacket of the currently playing file is
displayed.
• , , etc.: Current play mode indicatorD B
The meanings of each icon are as follows;
D B A (play), (fast forward), (fast
backward), (pause).H
7
Content list panel
Displays the playing list. When you touch a track/
file name on the list, playback will start.
iPod/iPhone
31English
Search Operation
You can search music files by the following
operations.
1 Touch .[ ]1
2 Touch .[ ]S
3 Select the list type.
NOTE
• For operations in the list screen, see List screen
( 15)P. .
Ñ Category search
You can search a file by selecting category.
1 Touch .[ ]Category List
2 Touch the desired category.
h The list corresponding to your selection
appears.
3 Touch to select desired item in the list.
Repeat this step until you find the desired
file.
Ñ Link search
You can search a file of same artist/album/
genre/composer as the current track.
1 Touch .[ ]Link Search
2 Touch the desired tag type. You can select
from artist, album, genre and composer.
h The list corresponding to your selection
appears.
3 Touch desired item from the content list.
APPS—Android Auto™/Apple CarPlay
32
APPS—Android Auto™/Apple CarPlay
Apple CarPlay Operation
CarPlay is a smarter, safer way to use your
iPhone in the car. CarPlay takes the things
you want to do with iPhone while driving and
displays them on the screen of the product.
You can get directions, make calls, send and
receive messages, and listen to the music
from iPhone while driving. You can also use
Siri voice control to make it easier to operate
iPhone.
For details about CarPlay, visit https://ssl.
apple.com/ios/carplay/.
Compatible iPhone devices
You can use CarPlay with the following iPhone
models.
• iPhone 6s Plus
• iPhone 6s
• iPhone 6 Plus
• iPhone 6
• iPhone 5s
• iPhone 5c
• iPhone 5
Ñ Preparation
1 Connect iPhone using KCA-iP103 via USB
(Black) terminal. (P.95)
When iPhone compatible with CarPlay is
connected to the USB (Black) terminal, the
Bluetooth smartphone currently connected
is disconnected.
2 Unlock your iPhone.
Ñ Operation buttons and
available Apps on the home
screen of CarPlay
You can use the Apps of the connected iPhone.
The items displayed and the language used
on the screen differ among the connected
devices.
To enter CarPlay mode, touch [Apple CarPlay]
icon in the source selection screen. (P.12)
3
1
2
1
[ ]
• Displays the home screen of CarPlay.
• Touch and hold to activates Siri.
2
Application buttons
Starts the application.
3
[ ]HOME
Exits the CarPlay screen and displays the Home
screen.
To exit the CarPlay screen
1 Press the button.[ ]
APPS—Android Auto™/Apple CarPlay
33English
Ñ Use Siri
You can activate Siri.
1 Press the button for 1 second.[ ]
Press for 1 second
2 Talk to Siri.
To deactivate
1 Press the button.[ ]
Ñ Switch to the Apple CarPlay
screen while listening to
another source
1 Press the button.[ ]
NOTE
• If sound is output using Apple CarPlay when the
Apple CarPlay screen is displayed, the source is
switched to Apple CarPlay.
Android Auto™ Operation
Android Auto enables you to use functions of
your Android device convenient for driving.
You can easily access route guidance, make
calls, listen to music, and access convenient
functions on the Android device while driving.
For details about Android Auto, visit https://
www.android.com/auto/ https://support. and
google.com/androidauto.
Compatible Android devices
You can use Android Auto with Android
devices of Android version 5.0 (Lollipop) or
later.
NOTE
• Android Auto may not be available on all devices
and is not available in all countries or regions.
Ñ Preparation
1 Connect an Android device via USB
terminal. (P.95)
To use the hands-free function, connect the
Android device via Bluetooth.
When an Android device compatible
with Android Auto is connected to the
USB terminal, the device is connected via
Bluetooth automatically, and the Bluetooth
smartphone currently connected is
disconnected.
2 Unlock your Android device.
APPS—Android Auto™/Apple CarPlay
35English
Pandora® Operation
You can listen to the Pandora® on this unit
by controlling the application installed in the
iPhone or Bluetooth device.
To enter Pandora source, touch [Pandora] icon
in the source selection screen. (P.12)
Preparation
• Install the latest version of the Pandora®
application on your iPhone, Android or BlackBerry.
iPhone: Search for "Pandora" in the Apple App
Store to find and install the most current version.
Android: Visit the Google play and search for
Pandora to install.
BlackBerry: Visit www.pandora.com from the
built in browser to download the Pandora
application.
• iPhones are connected on either USB or
Bluetooth.
• Android or BlackBerry devices are connected on
Bluetooth.
• To connect a smartphone via Bluetooth, register
it as the Bluetooth device and do the App (SPP)
profile setting of the connection beforehand. See
Register from the Bluetooth device (P.59)
and Connect the Bluetooth device (P.61).
3
1
2
1
Artwork/ Playing time
• The picture data is displayed if available from
current content.
• For confirmation of play time.
2
Function bar
• [ ] : Searches for a station. For details on
searching, see Station list screen (P.35).
• [ ] (Thumbs down) : Thumbs down to the
current contents and skip to the next contents.
• [ ] (Thumbs up) : Registers the current
contents as favorite content.
• , : Plays or pauses the content of the [ ]D[ ]H
current station.
• : Skips the current song. [ ]F
(Note this function is disabled when the
Pandora skip limitation is exceeded.)
• [ ] (Bookmark Song) : Bookmarks a song in
the current contents.
• [ ] : Creates a new station. See Creates a
new station (P.36).
• [ ] : Displays the Graphic Equalizer screen.
(P.79)
3
Content information
Displays the information of the current content
being played.
Ñ Station list screen
You can perform the following functions from
this screen.
1 Touch .[ ]
h Station List screen appears.
■Selects the station
Touch the station name in the list.
■Sort the list by registered date
Touch . The list is sorted to begin [ ]By Recent
with the last registered station.
■Sort the list in alphabetical order
Touch . You can select the desired [ ]By Name
letter from the list which corresponds to the
station name to help narrow the search.
NOTE
• You can operate Pandora by using the remote
control. However, only playing, pausing, and
skipping are available.
APPS—Android Auto™/Apple CarPlay
36
Ñ Creates a new station
1 Touch .[ ]
2 Touch desired item.
■Create station from artist
Creates a new station based on an artist
being played.
■Create station from track
Creates a new station based on a song being
played.
■Create station from genre
Displays the genre list screen.
Genre list screen
1 Touch [Create station from genre].
2 The selected genre is created as a new
station.
About Pandora®
iPhone or iPod touch
• Install the latest version of the Pandora
application on your iPhone or iPod touch. (Search
for “Pandora” in the Apple App Store to find and
install the most recent version.)
Android™
• Visit the Google play and search for Pandora to
install.
BlackBerry®
• Visit www.pandora.com from the built in browser
to download the Pandora application.
• Bluetooth must be built in and the following
profiles must be supported.
- SPP (Serial Port Profile)
- A2DP (Advanced Audio Distribution Profile)
NOTE
• In the application on your device, log in and
create an account with Pandora.
(If you are not already a registered user, an
account can also be created at www.pandora.
com.)
• Establish an Internet connection.
• Pandora is only available in certain countries.
Please visit http://www.pandora.com/legal for
more information.
• Because Pandora® is a third-party service, the
specifications are subject to change without
prior notice. Accordingly, compatibility may
be impaired or some or all of the services may
become unavailable.
• Some functions of Pandora® cannot be operated
from this unit.
• For issues using the application, please contact
Pandora® at pandora-support@pandora.com.
APPS—Android Auto™/Apple CarPlay
38
About Spotify®
iPhone or iPod touch
• Install the latest version of the Spotify application
on your iPhone or iPod touch. (Search for “Spotify”
in the Apple App Store to find and install the
most recent version.)
Android™
• Visit Google play and search for “Spotify” to install.
Note
• Ensure you are logged in to your smartphone
application. If you do not have an Spotify account,
you can create one for free from your smartphone
or at www.spotify.com.
• Because Spotify is a third-party service, the
specifications are subject to change without
prior notice. Accordingly, compatibility may
be impaired or some or all of the services may
become unavailable.
• Some functions of Spotify cannot be operated
from this unit.
• For issues using the application, contact Spotify at
www.spotify.com.
• Establish an Internet connection.
HD Radio™ Tuner
39English
HD Radio™ Tuner
HD Radio Tuner Basic
Operation
Most functions can be controlled from the
source control screen.
To enter HD Radio source, touch [ ]HD Radio
icon in the source selection screen. (P.12)
NOTE
• Set the remote control mode switch to AUD
mode before starting operation, see Switch the
operation mode (P.85).
• HD Radio broadcasting is for North American
sales area only.
• The screen shot below is for tuner. It may be
different from the one for HD Radio broadcasting.
Control screen
3
6
4
5
2
Preset list screen
7
1
9
8
10
1
Indicator display
While receiving an HD Radio station, it lights
with orange when the audio is digital and lights
with gray when it is analog. While receiving an
analog station, it is off.
2
Information display
Displays the information of the current station:
Frequency and Channel
Touching [ ] allows you to switch between
Content A, Content B and Content C.
Content A: Station name, Song Title, Artist Name
Content B: Station Message, Radio Text
Content C: PTY Genre, Album Name
3
[AUTO1 AUTO2 MANUAL] [ / ] [ / ]
Switches the seek mode in the following
sequence; [AUTO1 AUTO2 MANUAL] [, ] [, ].
• [AUTO1]: Tunes in a station with good
reception automatically.
• [AUTO2]: Tunes in stations in memory one
after another.
• [MANUAL]: Switches to the next frequency
manually.
4
Function bar
• : Tunes in a station. The method of [ ]E[ ]F
frequency switching can be changed (see 3
in table).
• : Selects a channel.[ ]CHS[ ]CHR
• : Display the Channel List screen. See [ ]1
Channel search (P.42).
• [ ] : Display a list of registered bookmarks.
See Bookmark list (P.44).
• [ ] : Displays the Graphic Equalizer screen.
(P.79)
5
Preset key
Recalls the memorized station or channel.
• Touch on the right side of the screen to display
the Preset list. Touch again to close the list.
6
Function panel
Touch on the left side of the screen to display
the function panel. Touch again to close the
panel. For details on the keys, see Function
panel (P.40).
7
The picture data or station Logo data is
displayed if available from current content.
8
[ ]FM [ ]AM
Switches the band.
HD Radio™ Tuner
41English
Receive Mode
You can set the radio broadcasts receive mode.
1 Touch on the left side of the screen.
Touch .[ ]RCV
2 Select a receive mode.
■[ ]Auto
Switch between digital and analog audio
automatically.
■[ ]Digital
Select this to tune to digital audio only.
■[ ]Analog
Select this to tune to analog audio only.
Memory Operation
Ñ Auto memory
You can store stations with good reception in
memory automatically.
1 Touch desired band key.
2 Touch on the left side of the screen.
Touch .[ ]AME
3 Touch [Yes].
h Auto memory starts.
Ñ Manual memory
You can store the current receiving station or
channel in memory.
1 Select a station or channel you wish to
store in memory.
2 Touch (#:1-15) or (#:1-5) [ ]FM# [ ]AM#
in which you want to store the station
or channel for 2 seconds until a beep
sounds.
HD Radio™ Tuner
42
Selecting Operation
Ñ Preset select
You can list and select memorized station or
channel.
1 Touch on the right side of the screen.
Select a station or channel from the list.
Ñ Direct search
You can tune in by entering the desired
frequency or channel number.
1 Touch on the left side of the screen.
Touch [10key Direct].
2 Select the search method.
3 Enter the frequency or channel number.
4 Touch .[ ]Enter
NOTE
• To clear the number you entered, touch .[ ]BS
Ñ Channel search
You can specify the desired channel.
1 Touch .[ ]1
2 Select the desired content from the list.
NOTE
• Touch in the channel list. Select [ ]Info Change
the sequence of the list (Song title, artist name,
album name).
HD Radio™ Tuner
43English
Ñ Search by program type
(FM only)
You can tune to a station with a specific
program type when listening to FM.
1 Touch on the left side of the screen.
Touch .[ ]PTY
h TUNER PTY Mode screen appears.
2 Select a program type from the list.
3 Touch .[ ]Search
You can search a station of the selected
program type.
Bookmark
Stores tag information (title, artist, album,
URL, and description) about the song you are
listening to now.
Detailed information and QR codes can
be displayed according to the stored tag
information.
Ñ Bookmark registration
1 Touch on the left side of the screen.
Touch [ ].
h Registers a bookmark.
NOTE
• Up to 100 bookmarks can be registered to this
unit.
HD Radio™ Tuner
44
Ñ Bookmark list
Displaying a list of registered bookmarks and
detailed information and QR code of the song.
1 Touch .[ ]
2 Select the desired bookmark from the list.
h The bookmark information appears.
■ [ ] Delete
Deletes the bookmarks being displayed.
Bookmark delete
Deleting a bookmark.
1 Touch .[ ]Delete
2 Select the bookmark to delete from the
list.
■ [ ]; All
Select all bookmarks.
■ [ ] All
Erases all check marks.
3 Touch .[ ]Delete
h Confirmation message appears.
4 Touch [Yes].
h Deletes all the selected bookmark(s).
HD Radio™ Tuner
45English
Alert Message
This function is to receive alert messages. First,
you need to turn on the “Emergency Alerts”.
(P.40)
Ñ When an Alert Message comes
[ ]Snooze
The alert message is erased. Same alert message
cannot be displayed for next 10 minutes.
[ ]Ignore
The alert message is erased. Same alert message
cannot be displayed for next 12 hours.
Ñ Display of the received Alert
Message
You can read the received alert message
afterward.
1 Touch on the left side of the screen.
Touch .[ ]Alert Message Log
2 Select the desired Alert Message from
the list.
h The Alert Message appears.
3 Touch .[ ]Close
SiriusXM®
46
SiriusXM®
SiriusXM® Basic Operation
Only SiriusXM® brings you more of what you
love to listen to, all in one place. Get over 140
channels, including commercial-free music
plus the best sports, news, talk, comedy
and entertainment. Welcome to the world
of satellite radio. A SiriusXM Vehicle Tuner
and Subscription are required. For more
information, visit www.siriusxm.com.
To enter SiriusXM source, touch [ ]SiriusXM
icon in the source selection screen. (P.12)
Activating subscription
• Check your Radio ID.
The SiriusXM Satellite Radio ID is required for
activation and can be found by tuning to Channel
0 as well as on the label found on the SiriusXM
Connect tuner and its packaging.
The Radio ID does not include the letters I, O, S
or F.
• tivate the SiriusXM Connect Vehicle Tuner Ac
using one of the two methods below:
– For users in the U.S.A.
Online: Visit www.siriusxm.com/activatenow
Phone: Call SiriusXM Listener Care at 1-866-
635-2349
– For users in Canada:
Online: Visit www.siriusxm.ca/activatexm
Phone: Call XM customer Care at 1-877-438-
9677
NOTE
• Set the remote control mode switch to AUD
mode before starting operation, see Switch the
operation mode (P.85).
• To use SiriusXM® Satellite Radio, the optional
accessory is necessary.
Control screen
3
6
4
2
5
Preset list screen
1
8
7
1
Indicator display
Displays the “Mix” (TuneMix™), “Scan”
(TuneScan™), (Traffic&Weather),
(SportsFlash™) indicator and the received
signal strength of the SiriusXM tuner.
2
Information display
Displays the information of the current channel:
Channel Name
Touching [ ] allows you to switch between
Content A and Content B.
Content A: Artist Name, Song Title, Content Info
Content B: Category Name, Channel Description,
Similar Channels
[ ] : Touch for 2 seconds to registers the artist
of the current song as a Content Alert.
[ ] : Touch for 2 seconds to registers the
current song as a Content Alert.
For details, see Content Alerts (P.52).
3
[ ]SEEK
Switches the seek mode in the following
sequence; , .[ ]SEEK1 [ ]SEEK2
SEEK1: Tunes channels one after the other.
SEEK2: Selects channels in preset (memory) one
after the other.
SiriusXM®
47English
4
Function bar
• : Display the Category search screen. For [ ]1
details on search operation, see Category/
Channel search (P.49).
• : Plays or pauses. See DH] Replay (P.50).
• : Selects a channel.[ ]CHS [ ]CHR
• [ ] : Displays the Graphic Equalizer screen.
(P.79)
5
Preset key
Recalls the memorized channel.
Touch on the right side of the screen to display
the Preset list. Touch again to close the list.
6
Function panel
Touch on the left side of the screen to display
the function panel. Touch again to close the
panel. For details on the keys, see Function
panel (P.47).
7
Information display
Displays the following information.
SXM#: Band display
P#: Preset number
#CH: Channel display
Logo: Display album artwork for most SiriusXM
music channels
8
Preset list[
Recalls the memorized channel.
When touched for 2 seconds, stores the current
receiving channel in memory.
Ñ Function panel
1 Touch on the left side of the screen.
The functions of each key are as follows.
[ ]Direct Channel
Touch and enter the desired number. For
details, see Direct search (P.49).
[ ]SETUP
Touch to display the SiriusXM SETUP screen.
For details, see SiriusXM Setup (P.53).
[ ]Band
Switches the band. (SXM1/ SXM2/ SXM3/
SXM4)
[ ] [ ]Replay / Live
Turns the replay mode on or off. See Replay
(P.50).
[Traffic & Weather]
For SXV300 *
1
Traffic & Weather Now™ allows you to access
the latest report whenever you want to hear
it. Select your city at the set up menu Select
a City for Traffic & Weather (P.57) and
press the [Traffic & Weather] button to
check the latest report. It will start from the
beginning.
• (White) : Played already.
• (Green) : New information arrived.
• (Purple) : Playing.
• (Gray) : No information.
For SXV200 or SXV100 *
2
Turns the Traffic & Weather Jump function
on or off.
• (White) : Function on.
• (Purple) : Playing.
• (Gray) : Function off.
SiriusXM®
48
[TuneScan]*3
Hear a few seconds of the songs from each
of the SmartFavorite music channels on
the current preset band. See TuneScan™
(P.51).
[TuneMix]*
4
When you turn it ON, the preset channels
on P1-P6 are shuffled to provide a playback
which is a blend of songs from your favorite
channels. See TuneMix™ (P.50).
[ ]SportsFlash * 4
Displays during SportFlash™. To cancel
the SportFlash interruption and return
to the previous channel, touch it. See
SportsFlash™ (P.52) SportsFlash™ and
setup (P.56).
*
1 Compatible with SXV300 or later tuner
models. It may take a few minutes after power
on to get the first full report for your city.
Traffic channels are not available in Canada.
*
2 When SXV200 or SXV100 is connected with
this unit.
*
3 Compatible with SXV200 or later tuner models.
*
4 Compatible with SXV300 or later tuner models.
Storing Channels in Preset
Memory
You can store the current channel in memory.
1 Tune to a channel you wish to store in
memory.
2 Touch on the right side of the screen.
3 Touch and hold for 2 seconds (until you
hear a beep) the preset number [SXM(1-
4) P(1-6)] in which you want to store the
channel.
Preset select
You can list and select memorized station or
channel.
To select from the preset list
1 Touch on the right side of the screen.
Select a channel from the list.
SiriusXM®
49English
Direct search
You can tune to a channel directly.
1 Touch on the left side of the screen.
Touch .[ ]Direct Channel
2 Enter the channel number and touch
[ ]Enter .
NOTE
• To clear the number you entered, touch .[ ]BS
Category/Channel search
You can specify the desired category and
select a channel.
1 Touch .[ ]1
2 Select a category.
h Channel list appears.
3 Select the desired content from the list.
NOTE
• All the channels in the selected category appear.
• Touching displays all the [ ]All-Channels
channels.
• Touch in the channel list. Select [ ]Info Change
the sequence of list as follows;
Channel name, artist name, song title, category
name, content info
• Categories which have the prefix “Featured - “ are
Featured Favorites.
• Featured Favorites are groups of channels that
are created by the SiriusXM Programming
department allowing you to discover new
channels. Featured Favorite channels are dynamic
and can change often, allowing you to discover
new channels.
SiriusXM®
50
Replay
You can replay the last 60 minutes of the
current channel.
1 Touch or on the function [ ]L [ ]Replay
panel.
■ [ ] [ ]E F
Press to skip to the previous/next track.
Press and hold to rewind or fast forward.
■ [ ]DH
Plays or pauses.
■ [ ] [ ]CHS CHR
Tune in a channel.
■ Replay time bar/ Play mode indicator
Display recorded capacity and playback
position.
D B, , etc.: Current play mode indicator
■ [ ]1
Display a list of recorded data on a program
basis.
2 Touch to display an Instant Replay list.[ ]1
■ Instant Replay List
Touching this plays back the displayed
program.
■ [ ]Info Change
Touch . Select the sequence of [ ]Info Change
the list as follows;
Artist name, Song title, Category name,
Content info, and Channel name
To return to live music/content
1 Touch on the left side of the screen.
2 Touch .[ ]Live
TuneMix™
TuneMix™ plays a unique blend of songs from
your Preset music channels from the current
SiriusXM Preset Band, allowing you to build a
custom channel from as few as two to as many
as 6 music channels. You can even skip songs
you don’t want to hear.
Touch on the left side of the screen.
1 Touch on the left side of the screen.
Touch [TuneMix] to set ON or OFF.
NOTE
• Compatible with SXV300 or later tuner models.
SmartFavorites, TuneStart™
Preset channels 1 through 6 of the current
band are SmartFavorites channels.
The SiriusXM Vehicle Tuner automatically
buffers the broadcast audio content of the
SmartFavorites channels in the background.
You can rewind and replay up to 30 minutes of
any of the missed news, talk, sports or music
content when you tune to a SmartFavorites
channel. (see Replay (P.50))
When tuning from a SmartFavorites channel,
songs will play from the beginning of each
track (TuneStart™). You can enable/disable
TuneStart. (see TuneStart™ (P.57))
NOTE
• Compatible with SXV200 or later tuner models.
SiriusXM®
51English
TuneScan™
TuneScan™ is a feature that plays samples
from the starts of multiple buffered songs
from each of the SmartFavorites channels that
predominantly play music selections.
You have easy access to a large sampling of
music content and can enjoy hearing a full
song when stopping the scan on a song of
interest.
1 Touch on the left side of the screen.
2 Touch [TuneScan] to begin scanning your
SmartFavorites channels.
You will hear a few seconds of the songs
from each of the SmartFavorite channels.
3 Touch [TuneScan] again while your
favorite song is being played to start
listening to that song.
h Scan finishes and continues playing the
song.
NOTE
• To cancel TuneScan™, Touch on the left side of the
screen. Touch [TuneScan].
• Touch and hold [TuneScan] to cancel TuneScan,
the channel before starting TuneScan will be
played.
• Compatible with SXV200 or later tuner models.
Traffic & Weather Now™
Traffic & Weather Now™ allows you to access
the latest report whenever you want to hear
it. Select your city at the set up menu Select a
City for Traffic & Weather (P.57).
1 Touch on the left side of the screen.
2 Touch [Traffic & Weather].
The report starts from the beginning. To stop
and return to the previous channel, touch it
again.
Indicator display
• (White) : Played already.
• (Green) : New information arrived.
• (Purple) : Playing.
• (Gray) : No information.
NOTE
• Compatible with SXV300 or later tuner models.
SiriusXM®
52
Content Alerts
When a broadcast program related to the
registered artist, song or team starts, a
message appears to allow you to switch the
current channel to the relevant channel.
1 When the broadcast of the registered
content starts, an Alert screen appears.
■ [ ]Jump
Touch to display the Alert Content List
screen.
■ [ ]Ignore
Touch to cancel the Content Alerts.
2 Select a content from the list.
NOTE
• Touch . Select the sequence of the [ ]Info Change
channel list as follows;
Artist Alert, Song Alert, GameAlert™
• To learn how to register artists and songs the
Team alert function, see 2. Information display of
SiriusXM® Basic Operation (P.46).
• To learn how to set up the Content Alerts
function, see Content Alerts setup (P.55).
SportsFlash™
SportsFlash™ will notify you when a big play
happens during a game with one of your
favorite sports teams. Choose to tune in and
hear the play unfold like it was live. Continue
listening to the game, or you can return to
your previous channel.
1 When a big play happens during one of
the games, an Alert screen appears.
■ [ ]Jump
Touch to tune to that channel and play back
the big play.
■ [ ]Ignore
Touch to cancel this specific Sports Flash
Alert. Touching will ignore this [ ]Ignore
specific alert but will allow future alerts for
this game.
■ [ ]Cancel
Touch to cancel the SportsFlash alert. No
alerts from this game will be displayed
afterward.
NOTE
• Compatible with SXV300 or later tuner models.
• To learn how to set up the SportsFlash alert
function, see SportsFlash™ setup (P.56).
SiriusXM®
53English
SiriusXM Setup
1 Touch on the left side of the screen.
Touch .[ ]SETUP
h SiriusXM SETUP screen appears.
See the following section for each
setting.
• Set up the parental code (P.53)
• Set up the Parental Control (P.54)
• Set up the skip channel select (P.54)
• Set up the Content Alerts (P.55)
• Set up the team for SportsFlash™ (P.56)
• Select the city for Traffic & Weather Jump
or Traffic & Weather Now™ (P.57)
• Set up the TuneStart™ (P.57)
• Reset to the default settings (P.57)
Ñ Parental code
You can set a SiriusXM parental code for
Parental Control.
1 Touch [Parental Code] in the SiriusXM
SETUP screen.
h Parental Pass Check screen appears.
NOTE
• The code number is set to “0000” as default.
2 Enter the current code number and touch
[ ]Enter .
h Parental Pass 1st entering screen
appears.
3 Enter the new code number and touch
[ ]Enter .
h Parental Pass 2nd entering screen
appears.
4 Enter the same code number as you input
in step 2 and touch .[ ]Enter
h The code number is confirmed and
SiriusXM parental code is now set.
SiriusXM®
54
Ñ Parental Control
Parental Control is a feature that provides the
user with the ability to prevent unauthorized
access to mature content and user selected
channels.
1 Touch [Parental Control] in the SiriusXM
SETUP screen.
2 Touch , [ ]Mature [User OFF] [ or ].
■[ ]OFF
Deactivates the parental mature and user
locks.
■[ ]Mature
Locks channels classified as “mature” only.
■[ ]User
Locks only the selected channels.
3 Enter the parental code you originally
input in Parental code (P.53) and touch
[ ]Enter .
When selecting [ ]User
This allows you to limit access to any SiriusXM
channel (Parental Lock Channel).
1 Touch [Parental Lock Channel Selection]
in the SiriusXM SETUP screen.
h Parental Pass Check screen appears.
NOTE
• You need to set up a Parental code (P.53)
beforehand.
2 Enter the parental code you originally
input in Parental code (P.53) and touch
[ ]Enter .
h Parental Lock Category Select screen
appears.
3 Touch the desired category from the list.
h Displays all the channels in the selected
category.
NOTE
• Touch to display all the [ ]All-Channels
channels.
• To delete the parental lock channel setting,
touch and then touch on [ ]Disable All [ ]YES
the confirmation screen.
4 Touch each channel on the list and set to
ON or OFF.
On: If you wish to set the lock.
Off: If you wish to unlock the channel.
NOTE
• Touch . Select the sequence of the [ ]Info Change
channel list as follows;
• Channel name, Artist name, Song title, Category
name, Content information.
Ñ Skip channel select
You can set the undesired channels to skip.
1 Touch .[ ]Skip Channel Select
h Skip Category Select screen appears.
2 Touch the desired category from the list.
h Displays all the channels in the selected
category.
SiriusXM®
55English
3 Touch each channel on the list and set to
ON or OFF.
NOTE
• To delete the skip channel setting, touch
[ ] [ ]Disable All and then touch YES on the
confirmation screen.
• Touch . Select the sequence of the [ ]Info Change
channel list as follows;
Channel name, Artist name, Song title, Category
name, Content information.
Ñ Content Alerts setup
Activating content alert
1 Touch [Content Alerts] in the SiriusXM
SETUP screen.
h The Content Alerts is turned on or off.
Default is “ON”.
Selecting the content for the content
alert
1 Touch [Content Alerts Contents Set] in
the SiriusXM SETUP screen.
2 Select the content you want to set up.
NOTE
• To set all the content Alerts off, touch
[ ] [ ]Disable All and then touch YES on the
confirmation screen.
3 Touch each content list and set ON or OFF.
NOTE
• You can select “ON” up to 60 items of Artist and
Song.
●To delete the Artist and Song
1 Touch .[ ]Delete
2 Touch each content list.
3 Touch and then touch [ ]Delete [YES] on the
confirmation screen.
SiriusXM®
56
To select a Team
Get alerted when your favorite sports team
is playing on another SiriusXM channel with
GameAlert™
1 Touch .[ ]My Games
2 Touch the desired league from the list.
3 Touch each team list and set ON or OFF.
NOTE
• You can select “ON” up to 30 items of Team.
Ñ SportsFlash™ setup
Activating SportsFlash
1 Touch in the SiriusXM [ ]SportsFlash
SETUP screen.
h The SportsFlash is turned on or off.
Default is “ON”.
Selecting the team for SportsFlash
1 Touch [SportsFlash Team Set] in the
SiriusXM SETUP screen.
h Team Set screen appears.
2 Touch .[ ]Edit
3 Touch the desired league from the list.
4 Touch each team list and set ON or OFF.
5 Touch twice.[ ]
SiriusXM®
57English
■ [ ]Edit
Sets and removes teams.
■ [ ]Priority
Sets the priority of a team to be posted.
■ [ ]Clear
Removes all teams that have been set.
Touch [Clear]. When the confirmation screen
appears, touch [YES].
NOTE
• SportsFlash™ is available on SXV300 or later tuner
models.
• Up to 50 teams can be added.
Set the SportsFlash™ Team Priority
1 Touch .[ ]Priority
2 Set the priority of a team.
Each time you touch Team, the priority is
set and reset.
3 Touch .[ ]Done
NOTE
• Priority can be set on up to 5 teams.
Ñ Select a City for Traffic &
Weather
You can select a city for which you wish to
receive SiriusXM Traffic & Weather broadcasts
and hear them from the beginning.
1 Touch [Traffic & Weather City Select] in
the SiriusXM SETUP screen.
2 Touch and to select a city.[ ]T [ ]U
Ñ TuneStart™
1 Touch [Tune Start] in the SiriusXM SETUP
screen.
The TuneStart is turned on or off.
Default is “ON”.
Ñ Reset
1 Touch in the SiriusXM [ ]SiriusXM Reset
SETUP screen.
h Confirmation screen appears.
2 Touch .[ ]YES
h All SiriusXM settings return to default.
Bluetooth Control
58
Bluetooth Control
Using the Bluetooth function, various
functions can be used: listening to the audio
file, making/receiving a call.
Information for using
Bluetooth® devices
Bluetooth is a short-range wireless radio
communication technology for mobile devices
such as mobile phones, portable PCs, and
other devices.
Bluetooth devices can be connected without
cables and communicate with each other.
NOTE
• While driving, do not perform complicated
operations such as dialing numbers, using the
phone book, etc. When you perform these
operations, stop your car in a safe place.
• Some Bluetooth devices may not connect to this
unit depending on the Bluetooth version of the
device.
• This unit may not work for some Bluetooth
devices.
• Connecting conditions may vary depending on
your environment.
• For some Bluetooth devices, the device is
disconnected when the unit is turned off.
Ñ About the cell-phone and
Bluetooth audio player
This unit conforms to the following Bluetooth
specifications:
Version
Bluetooth Ver. 3.0
Profile
Cell-phone:
HFP (V1.6) (Hands Free Profile)
SPP (Serial Port Profile)
PBAP (Phonebook Access Profile)
Audio player:
A2DP (Advanced Audio Distribution Profile)
AVRCP (V1.5) (Audio/Video Remote Control
Profile)
Sound codec
SBC, AAC
NOTE
• For the cell-phones verified for compatibility,
access the following URL:
http://www.kenwood.com/cs/ce/bt/.
• The units supporting the Bluetooth function have
been certified for conformity with the Bluetooth
Standard following the procedure prescribed by
Bluetooth SIG.
• However, it may be impossible for such units to
communicate with your cell-phone depending
on its type.
Bluetooth Control
59English
Register from the Bluetooth
device
It is necessary to register the Bluetooth audio
player or cell-phone to this unit before using
the Bluetooth function.
You can register up to 10 Bluetooth devices.
NOTE
• Up to 10 Bluetooth devices can be registered. If
an attempt is made to register the 11th Bluetooth
device, the Bluetooth device connected on the
earliest date will be deleted to register the 11th
one.
• This unit is compatible with the Apple Easy
Pairing function. When an iPod touch or iPhone is
connected to this unit, an authentication dialog
appears. Performing operation for authentication
on this unit or iOS smartphone registers the
smartphone as a Bluetooth device.
Follow the step 1, 2 and 3 for registration.
Step 1: Registration from the Bluetooth
device
1 Search the unit (“DNX****”) from your
smartphone/cell-phone.
2 Input the PIN code in your smartphone/
cell-phone.
PIN code is set to “0000” as the default.
● SSP (Secure Simple Pairing of Bluetooth
2.1 or later)
1 Search the unit (“DNX****”) from your
smartphone/cell-phone.
2 Confirm the request both on the
smartphone/cell-phone and the unit.
Step 2: Connection settings
• When the HFP profile is supported, Hands Free
1 or 2 is automatically selected for connection,
proceeding to the next step.
• When the A2DP or SPP profile is supported,
the cell-phone or audio player is automatically
connected, proceeding to the next step.
If cell-phones and/or audio players have already
been connected, a selection screen appears.
1 Select the hands-free number to connect.
A name of a smartphone is displayed when
it has hands-free connection with the unit.
2 Select if you want to use the audio player
app in your smartphone over A2DP, and
the other apps in your smartphone over
SPP.
This message appears if the device
supports BT audio (A2DP) or smartphone
link (SPP).
Bluetooth Control
60
Step 3: Phonebook transfer
1 Select if you want to transfer your
phonebook data.
This message appears if the device
supports PBAP.
The phonebook data transmission starts.
Some smartphones may request
permission to access the data. The
data transmission will start with your
permission.
When the data transmission and
connection have completed, the Bluetooth
connection icon appears on the screen.
Bluetooth Setup
1 Press the button.[ ]
h Popup menu appears.
2 Touch .[ ]SETUP
h SETUP Menu screen appears.
3 Touch .[ ]Bluetooth
h Bluetooth SETUP screen appears.
See the following section for each
setting.
• Connect the Bluetooth device (P.61)
• Change the PIN code (P.62)
• Change the device name (P.62)
Bluetooth Control
61English
Ñ Connect the Bluetooth device
1 Touch in the Bluetooth [ ]Select Device
SETUP screen.
2 Touch the device name you want to
connect.
h Profile select screen appears.
NOTE
• If the icon is lighted, it means that the unit will
use that device.
3 Set each profile as follows.
■ TEL (HFP) 1, TEL (HFP) 2
The device is connected with the unit as
hands-free phone 1 or 2.
■ Audio (A2DP)/App (SPP)
Set to interwork with an application installed
in a smartphone or to use as an audio player.
4 Touch .[ ]Close
To delete the registered Bluetooth
device
1 Touch .[ ]Delete
2 Touch the device name to check.
■ [ ]; All
Select all Bluetooth device.
■ [ ] All
Erases all check marks.
3 Touch .[ ]Delete
h Confirmation message appears.
4 Touch [Yes].
Bluetooth Control
63English
4
Function panel
Touch on the left side of the screen to display
the function panel. Touch again to close the
panel.
• BT DEVICE CHANGE] : Selects the device to
connect via Bluetooth audio (A2DP) or APP
(SPP). See Connect the Bluetooth audio
(P.63).
5
Play mode indicator/ Playing time
D H, : Current play mode indicator
The meanings of each icon are as follows;
D B A (play), (fast forward), (fast backward),
H I (pause), (stop).
* These items appear only when the audio player
which supports AVRCP profile is connected.
NOTE
• If the operation keys do not appear, operate from
the player.
• Depending on your cell-phone or audio player,
audio may be heard and controlled but text
information may not appear.
• If the volume is too low, raise it on your cell-
phone or audio player.
Ñ Connect the Bluetooth audio
Selects the device to connect via Bluetooth
audio (A2DP) or APP (SPP).
1 Touch on the left side of the screen.
Touch [BT DEVICE CHANGE].
2 Touch the device name you want to
connect.
3 Touch .[ ]Close
Ñ File search
1 Touch .[ ]1
2 Touch the desired file or folder.
When you touch a folder its contents are
displayed.
3 Touch desired item from the content list.
h Playback starts.
NOTE
• For operations in the list screen, see List screen
( 15)P. .
Bluetooth Control
64
Using Hands-Free Unit
You can use telephone function by connecting
the Bluetooth telephone to this unit.
NOTE
• While Apple CarPlay or Android Auto is being
connected, Bluetooth Hands-Free function and
two Bluetooth devices connections cannot be
used. Only Apple CarPlay or Android Auto Hands-
Free function can be used.
Ñ Make a call
1 Touch .[ ]Û
h Hands Free screen appears.
NOTE
• If your mobile phone supports PBAP, you can
display the phone book and call lists on the
touch panel screen when the mobile phone is
connected.
– Phone book: up to 1000 entries
– Up to 50 entries including dialed calls, received
calls, and missed calls
2 Select a dialing method.
• : Call using call records[ ]
• [ ]: Call using the phonebook
• [ ]: Call using the preset number
• [ ]: Call by entering a phone number
• [ ]: Voice Recognition (P.65)
● Select the cell-phone to use
When you connect two cell-phones
1) Touch [ ] to select the phone
you want to use.
● Bluetooth SETUP
1) Touch [ ].
Bluetooth SETUP screen appears.
NOTE
• The status icons such as battery and antenna
displayed may differ from those displayed on the
cell-phone.
• Setting the cell-phone in the private mode can
disable the hands-free function.
Call using call records
1 Touch . [ ]
2 Select the phone number from the list.
Call by entering a phone number
1 Touch .[ ]
2 Enter a phone number with number keys.
3 Touch .[ ]
Other External Components
69English
Other External Components
View Camera
NOTE
• To connect a camera, see .P. 94
• To use a rear view camera, a REVERSE lead
connection is required. (P.93)
• The view of the front view camera or dashboard
camera varies depending on the setting of
[Dashboard Camera /Front Camera].
• If [R-CAM Interruption] is set to on, the camera
screen is displayed when you shift the gear to the
reverse (R) position.
Ñ Display the camera screen
1 Press the button.[ ]
h Popup menu appears.
2 Touch .[ ]Camera
h View camera screen appears.
3 Adjust each item as follows.
2
34
1
1
Switching the View Camera
Touch to change the front view camera or
dashboard camera and rear view camera.
2
Camera off
Touch to exit the camera screen.
3
Switching the Guideline
Touching each time turns on or off the
guideline. Available when [Dashboard
Camera /Front Camera , Rear Camera] [ ] is
set to .[ ]CMOS 3-Series Camera
4
Switching the Angle
Touching each time changes camera angles:
Available when [Dashboard Camera /
Front Camera , Rear Camera] [ ] is set to
[ ]CMOS 3-Series Camera .
Ñ Camera Setup
1 Press the button.[ ]
h Popup menu appears.
2 Touch .[ ]SETUP
h SETUP Menu screen appears.
3 Touch .[ ]Camera
h Camera screen appears.
4 Set each item as follows.
■ Rear Camera
CMOS 3-Series Camera: Select this when
the CMOS-3xx series with ID 1 set is
connected.
Other (Default): Select this when the other
camera is connected.
■ R-CAM Interruption
ON: Displays the picture from the rear view
camera when you shift the gear to the
reverse (R) position.
OFF (Default): Select this when no camera is
connected.
■ R-CAM Settings
If you select for [ ]CMOS 3-Series Camera
[ ]Rear Camera , adjusts the CMOS-3xx series
with ID 1 set. For details, see the instruction
manual of your camera.
■ Parking Guidelines
You can display parking guidelines to enable
easier parking when you shift the gear to the
reverse (R) position.
Default is “ON”.
■ Guidelines SETUP
If you select for , [ ]ON [ ]Parking Guidelines
adjust the parking guidelines. See To adjust
the parking guidelines (P.70).
Produkt Specifikationer
| Mærke: | Kenwood |
| Kategori: | Navigator |
| Model: | DNX574S |
Har du brug for hjælp?
Hvis du har brug for hjælp til Kenwood DNX574S stil et spørgsmål nedenfor, og andre brugere vil svare dig
Navigator Kenwood Manualer
16 August 2024
5 August 2024
5 August 2024
4 August 2024
3 August 2024
3 August 2024
2 August 2024
1 August 2024
27 Juli 2024
27 Juli 2024
Navigator Manualer
- Navigator Chrysler
- Navigator Insignia
- Navigator Packard Bell
- Navigator TELE System
- Navigator Izzo
- Navigator Midland
- Navigator Soundstream
- Navigator Dynavin
- Navigator LXNAV
- Navigator IZZO Golf
- Navigator SilverCrest
- Navigator Toyota
- Navigator Magellan
- Navigator Harman Kardon
- Navigator V7
Nyeste Navigator Manualer
7 Juni 2025
6 Juni 2025
6 Juni 2025
3 Juni 2025
3 Juni 2025
2 Juni 2025
2 Juni 2025
2 Juni 2025
2 Juni 2025
2 Juni 2025
