KD-IRKIT300 Operating Instructions
Key Digital
®
, led by digital video pioneer Mike Tsinberg,
develops and manufactures high quality, cutting-edge
technology solutions for virtually all applications where
high quality video imaging is important. Key Digital
®
is at the forefront of the video industry for Home
Theater Retailers, Custom Installers, System Integrators,
Broadcasters, Manufacturers and Consumers. We
provide
total video system solutions because we know
and help drive the technology, the industry, the business
and all the latest up-and-coming standards. Most of
all, we know exactly what you need for your unique
application - the right solution.
Rev 0 – Nov. 2008
The KD-IRKIT300 is the central control and amplifi cation unit for your IR system. The KD-
IRKIT300 device connects IR receivers and emitters, extending the IR system interface to
audio/video components and is capable of supporting two (2) IR receivers and up to four
(4) IR emitters with the ability of expansion by connecting multiple units together.
Operating Instructions
KD-IRKIT300
IR System Central Control and Amplifi cation Unit
KD-IRKIT300_Manual.indd Spread 1 of 6 - Pages(10, 1)
KD-IRKIT300_Manual.indd Spread 1 of 6 - Pages(10, 1)
KD-IRKIT300_Manual.indd Spread 1 of 6 - Pages(10, 1)
KD-IRKIT300_Manual.indd Spread 1 of 6 - Pages(10, 1)KD-IRKIT300_Manual.indd Spread 1 of 6 - Pages(10, 1) 12/5/08 4:26 PM
12/5/08 4:26 PM
12/5/08 4:26 PM
12/5/08 4:26 PM12/5/08 4:26 PM
KD-IRKIT300 Operating Instructions
Page 2
Quick Setup Guide
Your KD-IRKIT300 includes the following pieces:
❯4 – KD-IRE3501F IR Emitters
❯1 – KD-IRC3099D IR Receiver
❯1 – KD-PS1212 Power Supply
❯1 – KD-IRCB204 IR Amplifi cation Block
Directions:
❯As shown in the following diagram, connect KD-IRC3099D IR Receiver(s), KD-IRE3501F
Emitter(s), and KD-PS1212 12V DC In Power Supply to proper inputs, then connect power.
❯Position IR Receiver(s) and Emitter(s) in appropriate locations (for tips on fi nding best locations,
see “Installation Instructions”).
❯For additional installation instructions, please refer to “Installation Instructions” section.
KD-IRCB204 Repeater
(IR connecting box)
IR Receiver 2
(not included
KD-PS1212
DC12V 1.2A
DC12V 200mA
(not included)
KD-IRE3501F
Emitters
Emitter
Blasters
Switch
KD-IRC3099D
IR Receiver 1
+12V
GND
ST OUT
IR IN
IR IN
GND
+12V
KD-IRCB204
EM ON BL ON
EM ON BL ON
NET OFF NET ON
+12V
GND
ST OUT
IR IN
IR
R
ece
i
ve
r
2
(
not included
D
C1
2
V
00
A
(
not included
)
I
R
I
N
G
N
D
+
1
2
V
