Table of Contents
Quick Setup Guide 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Application Example 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Connections, Buttons, and LEDs 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TCP/IP Commands 14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Specifications 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Important Product Warnings & Safety Instructions: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Contacting Key Digital 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warranty Information 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Always follow the instructions provided in this Operating Manual.
Please visit www.keydigital.com for the latest product documentation and software
downloads. Product features and specifications are subject to change without notice.
Introduction
KD-PS22UTx is an HDBaseT transmitter + presentation switcher + soft-codec enabling interface with
two HDMI inputs, as well as two USB-A connections, and one USB-B connection. The KD-PS22UTx also
includes a local pass-through output for an additional display. KD-PS22UTx is ideal for professional
video installations in conference rooms, classrooms, lecture halls, auditoriums, as well as audio return
/ ARC applications. KD-PS22UTx is natively received by KD-X100MRx black box HDBaseT Rx or by
KD-UPS52U Presentation Switcher. The KD-PS22UTx and both Rx options have audio de-embedding
for ease of integration with audio systems. Additional Key Digital Presentation Switchers also support
integration with KD-PS22UTx. KD-PS22UTx features push-button or TCP/IP switching selection of
the desired source and is KD-App Ready. KD-PS22UTx is HDCP 2.2 compliant and supports 4K/UHD
24/25/30/60 (4:4:4) resolutions with up to 18Gbps bandwidth. 4K/UHD signals are extended up to
100m / 328ft and 1080p up to 150m / 492ft via single CAT5e/6 cable. In addition to AV signals,
KD-PS22UTx extends USB 2.0, IR, RS-232, and LAN for controlling remotely located equipment.
Default IP Address: 192.168.1.239, 23Port
