Congratulations. You have just purchased one of the car audio world’s pre-

mier subwoofers. KICKER® Solo-Baric™ D-Series subwoofer’s unique design

delivers all the performance advantages of isobaric pair enclosure technolo-

gy in a single driver. The result is truly incredible levels of bass using enclo-

sures only half the size of traditional boxes.

SOLO-BARIC™

D-SERIES SUBWOOFERS

SOLO-BARIC FEATURES

Every element of the Solo-Baric’s design is optimized for accurate reproduction of bass

and sub-bass frequencies. The Solo-Baric has one of the most massive moving structures

in speaker design history, yet it still has the ultra-low distortion and lightning-fast transient

response essential for critical bass reproduction. New to the D-Series is the Solo-Baric

hemispherical cone, KICKER's most distortion-resistant cone technology to date. Voice coils

are made from ribbon copper wire, wound in multiple layers on black Kapton® formers for

superior heat-dissipation. The rest of the motor structure incorporates design/perform-

ance features that make Solo-Barics world-famous for performance and

durability...UniPlate™ construction, one-piece extended pole, deep-bump backplate,

stitched surround, heavy-duty terminals, high-power PVC-sleeved speaker leads, and more.

Additional Solo-Baric Performance Enhancements:

• Cast aluminum basket for superior support and great looks

• Flat progressive-roll spider for superior control and linearity

• Perimeter Venting to release pressures between spider and top plate

• Heavy-duty nickel-plated terminals for positive connections

POWER HANDLING

Power handling ratings on Solo-Baric subwoofers reflect the largest power amplifiers

suitable for use on each model. We feel this rating is more useful to you than misleading

“music power”, “continuous”, or other ratings often used.

The power ratings refer to the speaker’s ability to dissipate heat from the voice coil,

not the mechanical limits of cone excursion. Because the enclosure largely controls cone

travel, we have provided enclosure designs that will best prevent problems due to cone

over-excursion.

The minimum power rating suggests the least amount of RMS power per driver we

recommend when designing a system using Solo-Barics. Too little power can result in low

output and distorted sound. We recommend using as much power as possible, up to the

maximum power ratings listed in the Specifications section.

A Note on Power Handling Capability:

The S15d and S8d will handle full rated power in the recommended enclosure size.

However, the S12d and S10d have specific excursion limited (not thermal limited) power

ratings in their stock box sizes. For these models to handle their rated power they must be

used in smaller boxes.

The S10d will easily handle up to 350 watts in the .66 cubic enclosure; if more power (up

to 450 watts) is available, the box size should be reduced to .60 cubic feet.

The S12d will handle up to 425 watts in the .88 cubic enclosure; if more power (up to 600

watts) is available, the box size should be reduced to .66 cubic feet.

BUILDING YOUR ENCLOSURE

Your enclosure should be made of 3/4" wood, minimum. Avoid low density material such

as common particle board and low grades of plywood. The recommended materials are

MDF (medium density fiberboard), high density particle board or high quality void free 7 to

13 ply plywood such as marine plywood. Because of the extreme pressures which can

occur in the small enclosure your driver requires, use of material thinner than 3/4” may

result in panel vibration and should be avoided.

When assembling the box, include glue blocks to strengthen corners and add

cross-braces if you detect panel vibrations. Use a good grade of wood glue (such as

Elmer’s Professional or Titebond) on all joints. Do not use silicone, hot glue or caulk in

place of glue. When the glue has set, seal all the inside joints with a liberal application of

silicone sealer. This is important to ensure an airtight seal.

All the recommended enclosure specs require a 50% fill of polyester fiber. Commonly

called fiberfill, it is normally used as pillow stuffing.

The use of terminal cups is the preferred means for getting wires to the woofer. If cups

are not available drill a hole slightly larger than the wire used and carefully seal around the

wire with silicone sealer. This is also very important to maintain a perfect seal in the box.

Be sure to observe polarity when wiring up any speakers. Incorrect polarity will cause a

loss of sound quality and in the case of woofers it can decrease output dramatically.

If the woofer mounting hole is not cut exactly to specifications there is a good chance

that air can leak out through the screw holes. To remedy this problem you can use a

non-hardening sealer such as rope caulk or plumber’s putty. Do not use silicone products

to seal the woofer to the enclosure as this will void your warranty.

NOTE: DO NOT USE SOLO-BARIC DRIVERS IN THE FOLLOWING ENCLOSURE DESIGNS:

• Larger than recommended sealed enclosures

• Any vented or ported enclosure

• Free air or infinite baffle mounting

• “7th order” double-vented bandpass enclosures

• Passive radiator designs

Use of the Solo-Baric in enclosures with improper sealed volume can result in driver failure

that may not be covered under warranty.
