Kimo MP 50 Manual

Kimo Måling MP 50

Læs gratis den danske manual til Kimo MP 50 (12 sider) i kategorien Måling. Denne vejledning er vurderet som hjælpsom af 3 personer og har en gennemsnitlig bedømmelse på 3.8 stjerner ud af 2 anmeldelser. Har du et spørgsmål om Kimo MP 50, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/12

CLASS 50 PORTABLES

Quick Start Guide

EN FR ES

CO 50, CT 50, HD 50, HM 50, LV 50, LX 50, MP 50, MP 51, MP 55, VT 50

sauermanngroup.com

Kimo, a Sauermann brand.

to conrm your warranty

and benet from the full

Sauermann range.

English

Quick Start Guide

Class 50 portables

2. Take a measurement

Switch on the instrument by pressing briey on “On/Off/Hold”.

The instrument displays its name then the measurement.

VT 50: before using the instrument with the

hotwire probe, please lower the protection

tube (1) of the sensing element.

VT 50: always use the hotwire probe with

the red point in front of ow.

CO 50: the instrument displays its name then a 5 second countdown. This count corresponds to the preheating

time of the sensor. At the end of the countdown, the measured value of CO is displayed.

MP 50, MP 51: the instrument displays its name then an autozero is performed. At the end of the autozero, the

measured value displays.

Press briey on “Select” to switch measurement parameter display.

MP 50, MP 51, MP 55: press briey and successively on “Select” to change the unit.

• Available units for MP 50: Pa, mmH

0, inWg, daPa.

• Available units for MP 51: mmH

0, kPa, in Wg, mbar, mmHg, daPa.

• Available units for MP 55: mbar, mmHg, hPa.

HM 50: press briey on “Select” to select a type of material.

Press the spikes in the material to be measured.

When a measurement is over-range, above the maximum range, the value ashes.

Below the minimum range, the value is no more measurable and the device indicates "---", it means that for:

• Wood type 1: the measurement is < than 10%

• Wood type 2: the measurement is < than 9%

• Plaster, brick and concrete: the measurement is < than 0.1%

1. Keys

Select

On/Off/Hold

Sensing

element

(temperature)

Sensing

element

(velocity)

Airow direction

Protection tube

of the sensing

element (1)

Redpoint: landmark

Bottom of the

hotwire probe

4. Hold the measurement

During measurement, press briey on “On/Off/Hold” to hold measurement: “Hold” appears on the screen and

measurements are xed.

During measurement:

Remove pressure tubes. Carry out a long press on “Select”.

The instrument makes an autozero then returns to the measurement display.

3. Carry out a manual autozero (MP 50, MP 51)

CO 50, HD 50, HM 50, LX 50, MP 55, VT 50: press briey on “Select” to move from one parameter to the other.

Press again briey on “On/Off/Hold” to exit the Hold function.

These portable instruments are used to measure the following parameters: temperature, relative humidity, CO, pressure,

air velocity and light.

1. Operating temperature, protection of the instruments and information about storage

Conditions of use (°C/%RH/m): from 0 to +50 °C. In non-condensing conditions. From 0 to 2000 m.

Protection: IP54

Storage temperature: HD 50, LX 50: from -20 to +70 °C. CT 50, CO 50, HM 50, LV 50, MP 50, MP 51, MP 55, VT 50: from -20 to +80 °C.

If the instrument is stored outside the operating temperature (for example in a van, a warehouse...), please wait for 10

minutes in its operating temperature before start using it.
