Side 1/7

Quick Start Guide

CLASS 110 PORTABLES

AQ 110, CO 110, CT 110, HD 110, LV 110-111-117, LV 130,

MP 110-111-115-112, MP 120, MP 130, VT 110-115

www.sauermanngroup.com

EN FR ES DE ZH

English

Quick Start Guide

Class 110 portables

3. Take a measurement

Switch on the instrument by pressing briey on “On/Off/Esc”.

The instrument displays its name then the measurement.

VT 110: before using the instrument with the hotwire probe, please lower the protection tube (1) of the

sensing element.

VT 110: always use the hotwire probe with the red point (VT 110) or white point (VT 115) in front of ow.

CO 110 and AQ 110: the instrument displays its name then a 5 s (CO 110) or 10 s (AQ 110) countdown. This

count corresponds to the preheating time of the sensor. At the end of the countdown, the measured value of CO

and CO

is displayed.

MP 110, MP 120 and MP 130: the instrument displays its name then an autozero is performed. At the end of

the autozero, the measured value displays.

2. Keys

9. Batteries replacement

The instrument is OFF.

Remove the front part at the back of the instrument.

Replace used batteries by new batteries AAA LR03 1.5 V.

Replace the front.

These portable instruments are used to measure the following parameters: temperature, relative humidity, pressure,

airow and air velocity, CO and CO

1. Operating temperature, protection of the instruments and information about storage

Conditions of use (°C/%RH/m): from 0 to +50 °C / 32 to +122 °F (AQ 110 / CO 110 / CT 110 / LV 110-111-117 / LV 130 /

MP 110-111-115-112 / MP 120 / MP 130 / VT 110-115); from -10 to 50 °C / 14 to +122 °F (HD 110).

In non-condensing conditions. From 0 to 2000 m / 0 to 2188 yd.

Protection: IP54

Storage temperature: from -20 to +80 °C / -4 to +176 °F.

If the instrument is stored outside the operating temperature (for example in a van, a warehouse...), please wait for 10

minutes in its operating temperature before start using it.

To ensure safety, replace batteries with the same type.

Not doing so might lead to explosion. Dispose of used batteries according to instructions.

8. Activate or deactivate the keys beep

The device is on and displays the measurements.

Press "Select" until "BEEP" blinks on the screen and follow the instructions above:

7. Set the auto-off

The device is on and displays the measurements.

Press “Select“ until “AUTO OFF“ blinks on the screen and follow the instructions above:

6. Display minimum and maximum values

When measurements are hold:

Press “On/Off/Esc”: maximum value measured since the last questioning is displayed on the top of the screen and

minimum value measured since the last questioning is displayed on the bottom of the screen.

KEY FUNCTION

ON-OFF/Esc. Turn the instrument on/off and allow to back to previous selection.

OK key. Conrm selection

Select key. Navigate throught the menu

HOLD/min/max key. Hold value, and display minimum and maximum values

Backlight key. Activate/Deactivate the backlight

5. Hold the measurement

During measurement, press briey on “Hold/min/max” to hold measurement: “Hold” appears on the screen and

measurements are xed.

Press again briey “On/Off/Hold” to exit the Hold function.

During measurement:

Remove pressure tubes and press “OK”.

The instrument makes an autozero then returns to the measurement display.

4. Carry out a manual autozero (MP 110, MP 120, MP 130)

Sensing

element

(temperature)

Sensing

element

(velocity)

Airow direction

Protection tube

of the sensing

element (1)

Redpoint: landmark

Bottom of the

hotwire probe

Sensing

element

(temperature)

Sensing

element

(velocity)

Airow direction

Protection tube

of the sensing

element (1)

White point:

landmark

Bottom of the

hotwire probe

VT 110 VT 115

Switch on the instrument by pressing briey on “On/Off/Esc”.

During start-up, carry out a long press simultaneously on ”On/Off/Esc” and “Select“.

Select the required language (English, French) with “Select“ key. Validate pressing “OK”.

3. Select the language of the device
