2
Know your product
1. Front Safety Grill
2. Rear Safety Grill
3. Fan Blade
4. 3 Speed Switch
5. Oscillation Cam Block
6. Oscillation Bar Grub Screw
7. Locking Knob
8. Fan Fixing Bar
9. Hanging Bracket
10. Fan Grill Securing Hole
2
1
4
5
6
7
8
9
10
3
Table of Contents
Know Your Product ................................................................................................................2
Fan Safety Instructions ......................................................................................................... 3
Fan Assembly ......................................................................................................................... 4
Fan Operation ........................................................................................................................ 5
Warranty ................................................................................................................................. 5
SPECIFICATION
Model No: ........................................................................................................................................... KP1006
Voltage: ............................................................................................................................................... 220-240 V ~ 50 Hz
Wattage: .............................................................................................................................................. 230W
Rated Speed: ...................................................................................................................................... 1300 - 1400/rpm
Air Volume: ......................................................................................................................................... 280 - 300m3/min
Blade Type: ......................................................................................................................................... Aluminium
Approvals: .......................................................................................................................................... Climate Class T
Protection Class: ............................................................................................................................... Double Insulated
Net Weight: ......................................................................................................................................... 11.7kg
