INSTRUCTION MANUAL

Cable Length Meter

ENGLISH

501-915

• MEASURES AND

DISPLAYS CABLE

LENGTH IN FEET OR

METERS

• USES TDR METHOD

TO MEASURE CABLE

LENGTH VIA ITS VOP

CONSTANT

• MEASURES MOST

TYPES OF COPPER

CABLE INCLUDING

DATA, VOICE, VIDEO,

LAMP WIRE, SIAMESE,

AND NM CABLES

• CAPABLE OF

MEASURING LENGTH

TO OPEN AND SHORT

FAULTS

• EXTRA-LARGE FULL

COLOR BACK-LIT LCD

SCREEN

• BUILT-IN TONE

GENERATOR WITH

SELECTABLE TONE

CADENCE TO EASILY

TRACE CABLES WITH AN

ANALOG TONE PROBE

(NOT INCLUDED)

• CONSERVES POWER

ADJUSTABLE AUTO

POWER OFF (APO)

07:30 55%

05/29/2020

Library

Type

Home

CAT4UT

VOP

68.3%

0.0 ft

Pair 1-2

Pair 3-6

Pair 4-5

Pair 7-8

FRANÇAIS p. 25

ESPAÑOL pg. 13

0 m IP00

2 m

GENERAL SPECIFICATIONS

The Klein Tools Cable Length Meter is a portable time domain

reflectometer (TDR) cable length meter. It measures cable length,

calibrates Velocity of Propagation (VoP) values, finds faults in cables,

and provides tone generation for cable tracing.

• Environment: Indoors

• Operating Altitude: 10000 ft. (3050 m)

• Relative Humidity: <90% non-condensing

• Operating Temperature: 32° to 122°F (0° to 50°C)

• Storage Temperature: -4° to 140°F (-20° to 60°C)

• Input Protection: 30V peak 50/60Hz AC or DC

• Common Cable Length Ranges: Coax: 0 to 2000' (0 to 610 m)

Data: 0 to 1500' (0 to 457 m) Electrical: 0 to 1000' (0 to 305 m)

• Measurement Method: Time Domain Reflectometry

• Measurement Units: Feet, meters

• VoP Range: 0 to 99.9%

• Accuracy: ± (2% + 3 ft. or 1 m) with known VoP and consistent

cable parameters

• Tone Generation: Constant: 1200Hz, Alternating: 1000/1500 Hz

• Batteries: 2× AA alkaline

• Battery Low Level: Approx. 2.2V

• Battery Life: Active: Approx. 15 hours Standby: Approx. 3 years

• Auto Power Off (APO)

Test Mode: 5 to 20 minutes (default = 10 min.)

Tone Mode: 60 minutes, not adjustable.

• Dimensions: 6.2" × 2.6" × 1.2" (15.7 × 6.6 × 3.0 cm)

• Weight: 12.0 oz. (340 grams) with batteries

Specifications subject to change.

WARNINGS

To ensure safe operation and service of the meter, follow these

instructions. Failure to observe these warnings can result in

severe injury or death.

• The Cable Length Meter should NOT be used on energized cabling systems.

• Internal components of the Cable Length Meter are protected up to 30V

peak AC or DC. Connecting the meter to voltages above this range may

pose a safety hazard to the user and the meter.

ENGLISH

SYMBOLS ON METER

Warning: Potential for personal injury.

Caution: Potential for damage or destruction to equipment.

Always wear approved

eye protection

Do NOT use on

energized circuits

Read

Instructions

Do not place equipment and its accessories in the trash. Items must

be properly disposed of in accordance with local regulations.

UKCA - United

Kingdom

Conformity

Assessment

Conformité Européenne.

Conforms with European

Economic Area directives.

Battery

type and

orientation
