ENGLISH
Português pg. 29
Español pg. 15
Français pg. 43
VDV501-090
•
MEASURES
CABLE LENGTH
•
CABLE FAULT
FINDER
•
TONE GENERATOR
•
INSTRUCTION MANUAL
Ranger
TDR
2
ENGLISH
FEATURES
The Klein Tools Ranger™ TDR is a portable time domain reflectometer
(TDR) and voice-data-video cable tester. It measures cable length,
calibrates Nominal Velocity of Propagation (NVP) values, finds faults in
cables, and provides built-in tone generation for cable tracing
•
± (1% + 3 ft. / 1 m) length accuracy.
•
Stores up to two NVP values.
•
Displays length reading in feet or meters
•
Extra large seven-segment, back-lit LCD screen.
•
Tests most types of copper cable including data, voice, video, lamp
wire, siamese, and NM cables.
•
Discovers NVP values for cables with known length
•
Automatic pre-test voltage checks.
•
Identifies cable faults.
•
Tone generator with selectable tone cadence to easily trace cables
with an analog tone probe (not included).
•
Conserves power and supports long battery life with auto power off
GENERAL SPECIFICATIONS
•
Dimensions:
6.8" x 3.15" x 1.3" (17.3 x 8.0 x 3.3 cm)
•
Weight:
12.0 oz. (340 grams) with batteries
•
Operating Temperature
32° to 122°F (0° to 50°C)
•
Storage Temperature
-4°F to 140°F (-20° to 60°C)
•
Humidity:
10% to 90%, non-condensing
•
Altitude:
10000 ft. (3050 m) maximum
•
Input Protection:
400V peak 50/60Hz AC or DC
•
Voltage Warning:
At maximum of Safety Extra Low Voltage limits
(60V peak AC or DC). Measurement continues while warning
is displayed.
•
Battery Low Level
Approximately 4V
•
Battery Life:
4 AA alkaline batteries
•
Standby:
4 years
•
Active:
15 hours (average)
•
Measurement Method:
Spread Spectrum Time Domain Reflectometry
•
NVP (VOP) Range
20 to 99.9%
•
NVP Accuracy Range:
± (1% + 3 ft. / 1 m)
with known NVP and
consistent cable parameters
•
Common Cable Length Ranges:
•
Coaxial:
0 to 2000 ft. (0 to 610 m)
•
Data:
0 to 1500 ft. (0 to 457 m)
•
Electrical:
0 to 1000 ft. (0 to 305 m)
•
Tone Generation:
Constant output amplitude of 3Vpp, 4 cadences
centered around 1 kHz
