US EER GUID
KOGAN QLED 55 MART 4K TV ” S HDR
SER S XT95 IE 9 10 (KAQ 55XT9510STA)LED
2
Safety and warnings 02 ............................
Components 04 ..........................................
Product overview 05 ...................................
Inputs 05 .................................................
Assembly and installation...................06
Stand assembly 06 ..............................
Connect to antenna ....................... 06
Using remote / power button ............. 07
Remote control overview 08 .....................
First time setup ...............................09 - 10
Basic operation 11 .......................................
Channel Selection 11 ............................
Volume / mute 11 ..................................
Input Source 11 .......................................
Navigating menus 11 ............................
Colour buttons 11 ...................................
Settings 12 ....................................................
Overview 12 ............................................
Quick menu 12 .......................................
Global settings 13 - 14 ..........................
PVR mode 15 ...............................................
Instant recording 15 ..............................
Schedule recording 15 ..........................
Timeshi mode 16 ................................
Media playback 16 ......................................
Wall-mount installation.........................17
Specifications 18 ..........................................
Troubleshooting 19 ......................................
CONTENTS
Thank you for buying this Kogan product. Please read all safety instructions before using your TV.
• To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
• The apparatus shall not be exposed to dripping or splashing, and no objects filled with liquids,
(for example, vases), shall be placed on the apparatus.
• When discarding used batteries, always be mindful of the environment. Ensure you follow any
guidelines for recycling and safe disposal of batteries that apply in your local area. Don’t throw
used batteries in rubbish bin.
• When installing your TV, maintain a distance of at least 10 cm between the TV and other
objects (walls, cabinet sides, etc.) to ensure proper ventilation. Failing to maintain proper
ventilation may result in a fire or a problem with the product caused by an increase in its
internal temperature.
• The openings/slots on the back of the apparatus have been provided for necessary ventilation.
Ventilation should not be impeded by blocking these openings in any way (for example,
newspapers, table-cloths, curtains, etc.)
• No naked flame sources, such as lit candles, should be placed on the apparatus. To prevent
the spread of fire, keep candles or other open flames away from this product at all times.
• The device may malfunction when under electrostatic discharge. It can be manually resumed
by switching power o completely (at wall outlet), then switching power on again.
• To avoid any injury caused by overturn of the product when installed with base stands, please
always ensure the whole product is placed horizontally within the supporting surface and that
the television is not overhanging the edge of the supporting furniture.
• If not using with base stands, use only a wall or ceiling mount which has been recommended
by the manufacturer of the television.
THIS USER GUIDE COVERS THE FOLLOWING MODELS
Kogan QLED 55” Smart HDR 4K TV (Series 9 XT9510)
SAFETY AND WARNINGS
WARNING
Never place a television set in an unstable location. A television set may fall, causing serious
personal injury or death. Many injuries, particularly to children, can be avoided by taking
simple precautions such as:
• Using cabinets or stands recommended by the manufacturer of the television set.
• Only using furniture that can safely support the television set.
• Ensuring the television set is not overhanging the edge of the supporting furniture.
• Not placing the television set on tall furniture (for example, cupboards or bookcases) without
anchoring both the furniture and the television set to a suitable support.
• Not placing the television set on cloth or other materials that may be located between the
television set and supporting furniture.
• Educating children about the dangers of climbing on furniture to reach the television set or
its controls.
If your existing television set is being retained and relocated, the same considerations as
above should be applied.
3
• Keep small accessories out of reach of children so they are not mistakenly swallowed.
CAUTION: Connecting the power cord
Most appliances recommend they be placed upon a dedicated circuit; that is, a single outlet
circuit which powers only that appliance and has no additional outlets or branch circuits.
Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension
cords, frayed power cords, or damaged or cracked wire insulation are dangerous. Any of these
conditions could result in electric shock or fire. Periodically examine the cord of your appliance,
and if appearance indicates damage or deterioration, immediately discontinue use of the
appliance until the cord is replaced with an exact replacement part by an authorized servicer.
Protect the power cord from physical or mechanical abuse, such as being twisted, kinked,
pinched, closed in a door, or walked upon. Pay particular attention to plugs, wall outlets, and the
point where the cord exits the appliance.
The MAINS plug is used as the disconnect device, and the disconnect device shall remain
readily operable.
Operating Temperature: 5°C to 45°C
Operating Humidity: ≤80%
Storage Temperature: -15°C to 45°C
Storage Humidity: ≤90%
CAUTION
Do not attempt to modify this product in any way without written authorization from supplier.
Unauthorized modification could void the user’s authority to operate this product.
It is not recommended to keep a certain still image displayed on the screen for a long time as
well as displaying extremely bright images on screen.
Figures and illustrations in this User Manual are provided for reference only and may dier
from actual product appearance. Product design and specifications may be changed without
notice.
SAFETY AND WARNINGS cont’d
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE
COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO
QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of uninsulated “dangerous voltage”
within the products enclosure that may be of sucient magnitude to constitute
a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (servicing) instructions
in the literature accompanying the appliance.
Class II product: This symbol indicates that a safety connection to electrical
earth (ground) is not required. If this symbol is not present on a product with a
mains lead, the product MUST have a reliable connection to protective earth
(ground).
~AC voltage: Rated voltage marked with this symbol is AC voltage.
⎓DC voltage: Rated voltage marked with this symbol is DC voltage.
Caution. Consult instructions for use: This symbol instructs the user to consult
the user manual for further safety related information.
Refer to the table below as a guide to the symbols and warnings which may be on your TV.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
4
COMPONENTS
A Kogan QLED 55”
Smart HDR 4K TV
B Remote control
C Stand (x2)
D M4 x 20mm screw (x4)
E AAA battery (x2)
F Quick-start guide
G Warranty card
B
A
NOT INCLUDED
Phillips head screwdriver, antenna
cable, broadband internet connection.
D
E F G
C
5
3 Inputs/Ports
4 Power button
1 HDR 4K QLED display screen
2 Remote sensor / Standby light
PRODUCT OVERVIEW Inputs
Audio in Stereo (2.0) audio input.
Composite
video in
Usually paired with stereo audio inputs
(red and white cables), the single-wire
composite cable provides video signal.
Component
video in
Three cables (“Y,” “Pb” and “Pr”) provide a
higher quality connection than the single-
wire composite cable (“Y”) commonly
used to hook up earlier AV equipment.
HDMI
Connect an HDMI cable between the
HDMI port on the TV and the HDMI port
on the DVD player/Set-Top Box.
Ports marked ‘ARC’ also support Audio
Return Channel.
USB 2.0
USB storage devices can be inserted to
record and pause live TV in PVR mode, or
to watch media files stored on device in
media mode.
VGA Connect to a desktop or laptop computer.
ANT
For free-to-air TV, use an antenna cable
(not supplied) to connect to a working
antenna, either via an antenna wall
socket, or directly.
LAN
For a wired internet connection via a
broadband modem or router, connect an
Ethernet cable to the LAN port.
Digital
audio out
(optical) Audio out for digital audio devices. Port
and cable may look different depending
on an optical or coaxial input. Please use
the cable appropriate for your device.
Digital
audio out
(coaxial)
3.5mm
audio out
Line audio out port for use with
headphones, amplifier, soundbar or any
other audio device via an AUX cable (not
supplied).
This is a general guide to inputs and ports, your TV may not feature all of the above.
1
2
3
4
8
REMOTE CONTROL OVERVIEW
13
15
11
10
8
6
12
14
9
7
5
3
1
1 Power, press to enter or exit standby
mode
2 Mute to toggle sound on/o
3 II Pause in media/PVR mode;
Timeshi function in DTV mode
4 Stop in media/PVR mode;
teletext page on display, press Hold
again to release
5 Start playback in media mode;
MIX mode in teletext
6 Record in DTV mode;
of teletext screenChange size
7 Reverse playback rapidly in media
mode; Subtitle mode, or Submenu
8 Advance playback rapidly in media
mode; teletext but not exit Cancel
9 Skip to previous in media mode;
Index page
10 Skip to next in media mode;
Reveal hidden information in some
teletext pages
11 Number buttons to select channels or
input passwords
12 info displays the current program
information
13 epg Electronic Program Guide in DTV
mode
14 Device preferences to display sound
and picture options
15 Source displays the list of input
source channels.
4
2
22
25
28
29
24
27
26
21
18
17
16
19
20
23
16 Direction buttons/ / / for
navigating menus and settings
17 ok Enter select the current item
or confirm selection, display Channel
list in DTV mode
18 Quick Menu to display TV options
with optional, adjustable settings
19 Back to the previous menu
20 Google Assistant to launch the
built-in virtual assistant for voice
commands
21 + - Volume to adjust the volume up
or down
22 Program to scroll channels
23 Home to access the home page
24 to open app homepage
25 to open app homepage
26 Colour buttons for navigational use
within apps
27 Audio to select available
languages and audio channels.
28 sub Subtitles to select subtitles
29 Teletext to show/hide Teletext
(Teletext not available in Australia
or New Zealand)
10
FIRST TIME SETUP (cont’d)
1 Google Assistant
Click to launch the built-in virtual
assistant, which will begin listening
for voice commands. Give it a try, ask
“What’s the weather today?”
2 Text search
Enter text manually to search TV apps.
3 System notifications
This option will only appear when
notifications are present.
4 Source
Access free-to-air channels (‘DTV’)
or other input source channels.
5 Internet connection
This will display as a Wi-Fi or LAN icon,
depending on your connection. Select for
connectivity options.
6 Settings
Access the global settings menu.
7 Clock
Time and date settings can be adjusted
in the global settings.
8 Apps
Access the App Centre to display all
installed apps. Free-to-air channels can
be accessed under the ‘Live TV’ option.
9 Favourites list
A customisable list of apps available at a
single click.
10 Play next
Displays the program you are watching
or have queued to play next. You can
add to this list by long pressing the ok
button, then selecting “Add to play next”.
If the play next queue is empty, it will not
be shown on the home page.
11 Pinned channels
Show the program list of pinned
channels. The order of this list can be
adjusted by pressing from the channel
icon and selecting the “<>” icon. Empty
channels will not be shown on the home
page.
12 Customise channels
Add or remove pinned channels from the
home page.
89
11
10
12
1 3 4 52 6 7
Following these options, the Channel
Scan screen will appear. Ensure you have
an antenna cable connected to the ‘ANT’
input port at the back of the TV .(6a)
The auto tuning function will search
for and save all available free-to-air TV
channels. Aer confirming your settings
(the default will be set for Australia), the
process will automatically begin. The number of searched channels will be
displayed on the screen.
When setup is complete, you will be able to access the screen.Home
6a
Produkt Specifikationer
| Mærke: | Kogan |
| Kategori: | televisión |
| Model: | Series 9 XT9510 |
Har du brug for hjælp?
Hvis du har brug for hjælp til Kogan Series 9 XT9510 stil et spørgsmål nedenfor, og andre brugere vil svare dig
televisión Kogan Manualer
8 Januar 2025
5 Januar 2025
23 December 2024
23 December 2024
23 December 2024
23 December 2024
19 December 2024
19 December 2024
19 December 2024
26 September 2024
televisión Manualer
- NEC
- Hyundai
- Dyon
- High One
- Planar
- QBell Technology
- Iiyama
- DirecTV
- Haier
- Rm 2000
- Viewsonic
- Odys
- SYLVOX
- Telesystem
- Nokia
Nyeste televisión Manualer
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
