Recommended locations
emplacements recommandés
Empfohlene Anwendung
lugares recomendados
推奨取り付け位置
Trombone
Trombone
Posaune
Tr Trumpet / ompette
Tr Trompete / ompeta
Tr Trumpet / ompette
Tr Trompete / ompeta
Guitar / Guitare / Gitarre
Guitarra
Cello
Violoncelle / Violoncello
Cello /
Alto Saxophone
Saxophone alto / Altosaxophon
Saxofón alto
Clarinet / Clarinette
Klarinette / Clarinete
Bassoon / Basson
Fagott / Fagot
Oboe / Hautbois / Oboe
Oboe /
Euphonium / Basse
Tenorbaßhorn
Euphonium
Tuba / Tuba
Tuba / Tuba
French horn / Cor
Horn / Trompa /
AW-LT100M
AW-LT100T
アフターサービス
修理または商品のお取り扱いについてのご質問、ご相談は、お
客様相談窓口へお問い合わせください。
お客様相談窓口　
PHS等一部の電話ではご利用できません。固定電話または
携帯電話からおかけください。
受付時間　月曜～金曜　10:00 ～ 17:00　（祝祭日、窓口休
業日を除く）
●サービス・センター：
　〒168-0073　東京都杉並区下高井戸1-18-16　2F
■ お願い
1. 保証書に販売年月日等の記入がない場合は無効となりま
す。記入できないときは、お買い上げ年月日を証明できる領
収書と一緒に保管してください。
2. 保証書は再発行致しませんので、紛失しないように大切に
保管してください。
コルグ
AW-LT100M
AW-LT100T
保証書
本保証書は、保証規定により無償修理をお約束するもので
す。
お買い上げ日 年　　　　月　　　　日
販売店名
Thank you for purchasing the Korg AW-LT100M/AW-LT100T Clip-
on Tuner. To help you get the most out of your new instrument,
please read this manual carefully.
Merci d’avoir choisi la Clip-on Tuner AW-LT100M/AW-LT100T de
Korg. An de pouvoir exploiter au mieux toutes les possibilités
oertes par l’instrument, veuillez lire attentivement ce manuel.
Vielen Dank, dass Sie sich für einen AW-LT100M/AW-LT100T Clip-
on Tuner von Korg entschieden haben. Bitte lesen Sie sich diese
Anleitung vollstädig durch, um bei der Bedienung alles richtig zu
machen.
Gracias por comprar el afinador para enchufar AW-LT100M/
AW-LT100T Clip-on Tuner de Korg. Por favor, lea este manual
atentamente y guárdelo para futuras consultas.
このたびは、コルグClip-on Tuner AW-LT100M/AW-LT100T
をお買い上げいただきまして、まことにありがとうございます。
本製品を末永くご愛用いただくためにも、取扱説明書をよくお読
みになって、正しい方法でご使用ください。
Published 017 3/2 Printed in etnamVi
Owner’s Manual
(¬p.2)
Manuel d’utilisation
(¬p.5)
Bedienungsanleitung
(¬s.6)
Manual de usuario
( )¬p.7
取扱説明書
(¬p.8)
- 2 -
Range of motion
Plage de manœuvre de l’accordeur
Bewegungsspielraum
Intervalo de movimiento
可動範囲
AW-LT100M
20°
100°
20°
340° 170°
AW-LT100T
90°
20°
360°
Parts of the AW-LT100M/AW-LT100T
Reference pitch
indicator
Pure major third
Pure
minor third
Note name indicator
Meter
Left shuttle switch Right shuttle switch
Battery compartment (Rear)Battery indicator
Installing the battery
When the battery becomes depleted, a
battery symbol ( ) will appear on the
display. Immediately replace the battery
with a new one.
1.
Open the battery compartment cover on
the rear of the tuner in the direction of the
arrow.
2.
Insert the battery, making sure to observe
the correct polarity, and then close the cover.
Tuning
Tuning procedure
1.
Turn the upward. Each time you turn the shuttle left shuttle switch
switch, the AW-LT100M/AW-LT100T will be turned on or o.
If the power is left on for approximately 20 minutes without any user
input, it will turn o automatically (Auto power-o function).
2.
If necessary, change the reference pitch (calibration).
3.
Play a single note on your instrument.
The note name closest to the detected
pitch appears in the note name indicator.
Che ck t h at t he co rrect note name
appears in the display, and the meter
segments at the center (
) light up.
If you want to tune to a pure major third
or pure minor third above a certain note, adjust the pitch to the pure
major or minor third marks on the meter. For example if you want to tune
to a pure major third above A, make the note name indicator read C#,
and tune so that the meter indicates the left
. Alternatively, if you want
to tune to a pure minor third above A, make the note name indicator
read C, and tune so that the meter indicates the right
.
Even if the pitch is within the range of detection, it may not be possible
to detect the pitch of an instrumental sound that contains large
numbers of overtones or a sound that has a rapid decay.
The meter may respond to vibrations it picks up from the environment.
Reference pitch settings (calibration) (*M)
Each time you turn the upward (or downward), the right shuttle switch
reference pitch (calibration value) increases (or decreases) in 1 Hz steps.
Meter indication speed setting (*M)
Each time you turn the downward, the meter left shuttle switch
indication speed changes. When the setting is changed, “F” (fast) or “S”
(slow) appears in the reference pitch indicator.
Backlight
After turning the upward to turn on the AW-LT100M/left shuttle switch
AW-LT100T, you can change the brightness of the display by keeping
the left shuttle switch turned upward for approximately 2 seconds.
Auto : The backlight will light brightly when sound is inputted or when
a shuttle switch is operated. When there has been no sound input or
shuttle switch operation for approximately three seconds after the
power has been turned on, the backlight will turn o in order to prevent
the battery from being depleted.
Soft : The backlight will light at a lower level of brightness in order to
prevent the battery from being depleted.
Attaching to the instrument and range of motion
The AW-LT100M/AW-LT100T tunes by picking up the vibrations of
the instrument. Therefore, attach the AW-LT100M/AW-LT100T to the
recommended part of your instrument in order to tune it (Refer to the
illustrations on page 1).
Model name Instrument name
Attachment location
(Illustration)
AW-LT100M
Horn (Single, Double) First tube (M1)
Tuba Mouth pipe (M2)
Euphonium Bell (M3)
Oboe Bell body (M4)
Bassoon Wing joint area (M5)
E
♭
Clarinet Upper joint
B
♭
Clarinet Bell (M6)
Bass clarinet Blowing tube
Saxophone (Soprano, Baritone) Bell
Saxophone (Alto, Tener) Neck (M7)
Cello Tailpiece (M8)
Contrabass Tailpiece
Guitar Head (M9)
Trumpet / Cornet Main tube (M10)
AW-LT100T
Trumpet / Cornet Bell (T1)
Trombone Bell (T2)
Additionally, the AW-LT100M/AW-LT100T can be freely moved so that
the display is easy to read (Refer to the illustration on the upper left).
The AW-LT100M/AW-LT100T may be damaged if you apply excessive
force within its range of motion, or attempt to move it beyond its
intended range of motion.
Please carefully attach the AW-LT100M/AW-LT100T to your
instrument. Leaving the AW-LT100M/AW-LT100T attached for a long
time may damage or mark the instrument's surface.
Depending on various factors such as age-related change or the
surface finish, there is a possibility that your instrument may be
damaged by attaching this product.
Specications
Scale: 12-note equal temperament
Range (sine wave): A0 (27.50 Hz)–C8 (4186 Hz)
Precision: +/-1 cent
Reference pitch: A4 = 410–480 Hz (1 Hz steps)
Dimensions (W x D x H):
AW-LT100M 60 mm x 65 mm x 68 mm / 2.36’’ x 2.56’’ x 2.68’’
AW-LT100T 60 mm x 32 mm x 41 mm / 2.36’’ x 1.26’’ x 1.61’’
Weight: AW-LT100M 36 g/1.27 oz. (including battery)
AW-LT100T 27 g/0.95 oz. (including battery)
Power supply: One AAA Battery
Battery life:
approximately 100 hours (backlight:Soft, tuner continuously
operating, A4 input, when using alkaline battery)
Included items: Owner’s manual, One AAA battery
*M Settings are remembered even when the power is o.
• Specications and appearance are subject to change without notice
for improvement.
Illustration AW-LT100T
Meter indications
when correctly tuned
