Side 1/4
Scan for full manual
617T, 617R Installation Instructions
4K HDR HDMI Tx/Rx over Extended-Reach Multi-Mode Fiber Optic Cable
This guide helps you install and use your for the first time.617T, 617R
Go to to download the latest user manual and check if firmware
https://www.kramerav.com/product/617r/t
upgrades are available.
617T, 617R 4K HDR HDMI Tx/Rx over Extended-Reach Multi-Mode Fiber Optic
Cable
Congratulations on purchasing your Kramer 617T and 617R Plug and Play active 4K HDR HDMI Tx/Rx over Extended-Reach Multi-
Mode (MM) Fiber Optic cable. 617T and 617R extend signals of up to 4096x2160 @60Hz (4:4:4), over a distance of up to 200m (656ft)
without signal scaling or data compression, providing a maximum data rate of 18Gbps. 617T and 617R are easily and securely
connected via a 2LC fiber connector and can be powered from the USB connector. Alternatively, 617T only can be powered from the
HDMI interface (pin #18).
Figure 1: 617T Transmitter and 617R Receiver
Safety
Caution: There are no operator serviceable parts inside the unit.
Warning: Disconnect the power and unplug the unit from the wall before installing.
Warning: Avoid direct eye exposure into the optic connectors when powered, although this product is regulated strictly enough to
operate under the Laser Class 3R for eye safety.
See for updated safety information.
www.KramerAV.com
617T, 617R Installation Instructions
P/N: Rev:
Installation
To install 617T and 617R:
1. Unpack the contents of the package with care.
We recommend that you save the original box and packaging materials for possible future shipment.
2. Turn on the power to the HDMI source (for example, a laptop) and acceptor (for example, a display).
3. Power the 617T and 617R:
lConnect the micro USB connector on each device to a USB cable (supplied).
lConnect the USB cable either to the wall-mount power adapter (supplied) and to the mains, or to a USB port.
The POWER LED lights and the STATUS LED flashes three times.
Although 617T can be powered via pin #18 on the HDMI interface, we recommend that you use the USB power adapter.
617R can only be powered via the USB power adapter.
4. Connect the two LC optical fibers between 617T and 617R.
Connect (A) to (A) and (B) to (B). Make sure that the duplex connectors are connected properly.
The STATUS LED flashes.
Do not look directly into the LC connectors on the 617T (the transmitter side) when it’s powered.
This product operates under LASER Class I, classified by CDRH/FDA for eye safety.
We recommend that you avoid using intermediate cables or adapters. Using them may affect the transmission quality.
5. Connect 617T to the HDMI connector on the source side and 617R on the acceptor side.
Make sure that the 617T is always connected to the source side and the 617R is connected to the acceptor side.
Once the system is connected the Status LEDs on both 617T and 617R flash.
