Side 1/87

P/N: 2900-301204 Rev 2 www.kramerAV.com

USER MANUAL

MODELS:

AFM-20DSP, AFM-20DSP-LE

20-Port Audio Matrix

Kramer Electronics Ltd.

AFM-20DSP – Contents
i

Contents
Introduction  1
Getting Started  1
Overview  2
Typical Applications  4
Defining AFM-20DSP and AFM-20DSP-LE  5
AFM-20DSP and AFM-20DSP-LE Front Panels  5
AFM-20DSP and AFM-20DSP-LE Rear Panels  6
Mounting AFM-20DSP / AFM-20DSP-LE  7
Connecting the 20-Port Audio Matrix  8
Connecting AFM-20DSP  8
Connecting AFM-20DSP-LE  10
Connecting to AFM-20DSP / AFM-20DSP-LE via RS-232  11
Operating and Controlling AFM-20DSP/AFM-20DSP-LE  12
Operating via Ethernet  12
Using Embedded Webpages  15
Browsing the AFM-20DSP Webpages  16
Using the Top Status Bar  18
Viewing the Matrix Area  20
Processing Audio Signals  22
Selecting Output Signals to Route to Amplifier Outputs  22
Linking Analog Inputs and Outputs  23
Processing a Signal  24
Routing Inputs to Outputs  37
Mixing Audio Signals  41
Defining Audio Settings  45
Defining Video Settings  46
Restarting and Resetting the Device  47
Defining Settings  49
Importing/Exporting Global Settings  49
Setting Access Security  49
Defining Communication Settings  52
Performing Firmware Upgrade  54
Setting Date and Time  55
Configuring Device Automation  56
Viewing Device Information  58
Upgrading Firmware  59
Technical Specifications  60
AFM-20DSP Technical Specs  60
AFM-20DSP-LE Technical Specs  61
Default Communication Parameters  63
Default EDID  63
Protocol 3000  65
Understanding Protocol 3000  65
Protocol 3000 Commands  66
Result and Error Codes  83
