KT- -INWL 107 Quick Start

P/N:

2 9 0 0 - 3 0 1 1 5 1 QS

Rev:

Scan for full manual

KT- -INWL Quick Start Guide 107

This guide helps you install and use your KT-107-INWL for the rst time.

Go to www.kramerav.com/downloads/KT- -INWL107 to download the latest manual and check for updates.

Step 1: Check what’s in the box

KT- -INWL 107 enclosure

4 4x1/2” screws for wood (packed separately)

Outer frame

1 utCardboard c -out template

4 Inner frame M3x8 screws (packed separately

Inner frame

1 Quick start guide

Step 2: Get to know your - -INWL KT 107

The -Wall Kit secures , and Touch Panels safely into a wall (drywall, wood, or KT- -INWL107 In KT-107 -107RB KT -107SKT

concrete).

Step 3: Prepare the surface for installation

For drywall and wooden surfaces:

1. Place the cut-out template (included, use

for drywall and wood installations) over the

surface exactly where you want to install

KT- -INWL107 .

2. Mark the edge inside

(W, H: 19.5cm x 15cm) of the template and

cut an opening in the surface according to

the given dimensions.

Kramer is not responsible for any

damage caused to the surface.

For concrete or block wall surfaces:

Use the Kramer -wall box KT-107-INWB in

(purchased separately) for concrete

installations.

1. Make sure that the prepared opening in

the concrete ts the dimensions of the in-

wall junction box.

2. Insert the into the opening. KT- -INWB107

Make sure to place the ush KT-107-INWB

with the plaster surface.

Step 4: Mount the - -INWL enclosure KT 107

For each surface type you need to use dierent screws to mount the enclosure. KT-107-INWL

For drywall surfaces:

1. Insert the enclosure into the KT- -INWL107

opening.

2. Slightly release the 4 drywall screws until you

notice (via the openings next to the drywall

screws) that the drywall anchor turns

outwards.

3. Tighten the screws to x the enclosure in

place.

Rear view of drywall screw anchor in the vertical position and tightened,

in the horizontal position:

For wooden surfaces:

▪ Insert the 4 wood screws 4x1/2”

(supplied) through the wood screw-

openings and tighten to the wooden

surface.

For concrete surfaces:

1. Place the enclosure inside the KT- -INWL107

junction box opening.

2. Insert the 4 concrete screws (supplied with

KT KT- -INWB107 ) through the - -INWL107

enclosure concrete screw-openings and the

screw openings of the junction box, and

tighten.
