Kramer Electronics, Ltd.

USER MANUAL

Model:

VS-44HC

4x4 Home Entertainment Matrix Switcher

Contents

Introduction 1

Getting Started 1

Overview 2

3.1

Terminology Used in this User Manual 3

Your VS-44HC 4x4 Home Entertainment Matrix Switcher 3

Installing the VS-44HC on a Rack 7

Connecting the VS-44HC 8

6.1

Connecting the VS-44HC Rear Panel 8

6.2

Connecting the Audio Signals 10

6.3

Setting the Dipswitches 11

6.3.1

Setting the Machine # 11

6.3.2

Setting the IN 2 Audio Signal 12

Controlling the VS-44HC 13

7.1

Controlling via RS-232 (for example, using a PC) 13

7.2

Controlling via RS-485 14

7.2.1

Set the Dipswitches 14

7.3

Controlling the VS-44HC via the ETHERNET Port 16

7.3.1

Connecting the ETHERNET Port directly to a PC (Crossover Cable) 16

7.3.2

Connecting the ETHERNET Port via a Network Hub (Straight-Through Cable) 18

7.4

Configuring the Ethernet Port 18

7.4.1

Setting a Virtual Port 20

7.4.2

Setting an Ethernet Connection 21

Operating the VS-44HC 22

8.1

Displaying Unit Characteristics 22

8.2

Choosing the Audio-Follow-Video or Breakaway Option 23

8.2.1

Setting the Audio-Follow-Video Option 23

8.2.2

Setting the Breakaway Option 23

8.3

Switching OUT-IN Combinations 23

8.4

Confirming Settings 24

8.4.1

Toggling between the At Once and Confirm Modes 24

8.4.2

Confirming a Switching Action 24

8.5

Storing/Recalling Input/Output Configurations 25

8.5.1

Storing an Input/Output Configuration 25

8.5.2

Recalling an Input/Output Configuration 25

8.6

Setting and Adjusting the Audio Delay Time 26

8.7

Locking the Front Panel 27

Flash Memory Upgrade 28

9.1

Switcher Flash Memory Upgrade 28

9.1.1

Downloading from the Internet 28
