Kramer Electronics, Ltd.
USER MANUAL
Model:
VS-44HD
4x4 SD/HD-SDI Matrix Switcher
Contents
i
Contents
1
Introduction 1
2
Getting Started 1
2.1
Quick Start 1
3
Overview 3
4
Your VS-44HD 4x4 SD/HD-SDI Matrix Switcher 3
5
Installing on a Rack 6
6
Connecting Your VS-44HD 7
6.1
Connecting Your VS-44HD 4x4 SD/HD-SDI Matrix Switcher 7
6.2
Connecting the VS-44HD as a Dual-Link 2x2 SD/HD-SDI Matrix Switcher 9
6.3
Setting the VS-44HD to work in the Dual-Link Mode 10
6.4
Dipswitch Settings 11
6.4.1
Setting the Machine # Dipswitches 11
6.5
Controlling via RS-232 (for example, using a PC) 12
6.6
Controlling via the RS-485 Port 13
6.7
Factory Reset 14
6.8
Switching Genlocked Video Signals 14
6.9
Controlling via ETHERNET 14
6.9.1
Connecting the ETHERNET Port directly to a PC (Crossover Cable) 14
6.9.2
Connecting the ETHERNET Port via a Network Hub (Straight-Through Cable) 16
6.9.3
Configuring the Ethernet Port 16
6.10
Controlling via the REMOTE Connector 16
7
Operating the VS-44HD 17
7.1
Switching OUT-IN Combinations 17
7.2
Switching OUT-IN Combinations in the Dual-Link Mode 17
7.3
Confirming Settings 18
7.3.1
Toggling between the AT ONCE and CONFIRM Modes 18
7.3.2
Confirming a Switching Action 18
7.4
Storing/Recalling Input/Output Configurations 19
7.4.1
Storing an Input/Output Configuration 19
7.4.2
Recalling an Input/Output Configuration 19
7.5
Locking the Front Panel 20
8
Technical Specifications 20
9
Table of Hex Codes for Serial Communication 20
10
Kramer Protocol 2000 21
