P/N: 2900-301419 Rev 1 www.kramerAV.com

USER MANUAL

MODEL:

VS-88H2, VS-66H2, VS-84H2, VS-48H2

Matrix Switcher

Kramer Electronics Ltd.

VS-88H2 – Contents
i

Contents
Introduction  1
Getting Started  1
Overview  2
Typical Applications  3
Controlling your VS-88H2  4
Defining the Matrix Switcher  5
Mounting VS-88H2  8
Connecting VS-88H2  9
Connecting to VS-88H2 via RS-232  10
Connecting VS-88H2 via the ETHERNET Port  10
Operating VS-88H2 via Front Panel Buttons  13
Routing Signals  14
Storing and Recalling a Setup  22
Setting Switching Mode  23
Setting Switching Speed  23
Setting HDCP  24
Copying the EDID  25
Firmware Upgrade  26
Using Embedded Web Pages  27
Switching and Setting Ports  29
Changing Device Settings and Upgrading Firmware  40
Managing Web Page Security  42
Managing Timeout Settings  46
Setting Switching Modes  48
Setting Step-in Devices  51
Managing the EDID  53
Viewing About Page  57
Technical Specifications  58
Default Communication Parameters  59
Default EDID  60
Default Parameters  62
Input or Output Resolutions  63
Protocol 3000 Commands  64
Understanding Protocol 3000  64
Protocol 3000 Commands  65
Result and Error Codes  79
