KBVVC4527
EN
Dear client,
Thank you for purchasing this product.
The quality of this appliance has been certified by several
laboratory tests. This instructions manual is provided to simplify
the use of the appliance as well as to guarantee a safe use.
Please read carefully the instructions and safety measures
described in this manual.
We sincerely hope you will be satisfied when using your new
appliance.
ROBOT VACUUM CLEANER
KBVVC4527 EN
3
INDEX
1. SAFETY INSTRUCTIONS 4
1.1. Power Supply 5
1.2. Power Cord and Other Cables 6
1.3. Humidity and Water 6
1.4. Cleaning 6
1.5. General Precautions 6
2. OPERATING INSTRUCTIONS 8
2.1. Product Description 8
2.2. Product usage 9
2.3. Maintenance 27
2.4. Troubleshooting 33
3. TECHNICAL SPECIFICATIONS 36
4. POST-SALE SERVICE 37
5. ENVIRONMENTAL PROTECTION 37
EN
4
1. SAFETY INSTRUCTIONS
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Warning: to avoid the risk of electric shock,
do not remove the cover. The interior does
not contain any parts that can be repaired
by the user. Ask for assistance from the
Customer Support Service.
Important Warnings
Before using your appliance read these
instructions manual carefully and keep it in a safe
place as you may need to consult it in the future.
Before turning on your appliance, and to ensure a
safe and correct operation, do not use if:
• It has fallen to the ground;
• You notice any evidence of damage;
• Any anomaly occurs during its operation.
To avoid hazards or deterioration of your
appliance through incorrect use it is advisable to
read these instructions thoroughly.
Your appliance should not be used for other
purposes than the ones intended and solely for
household use. Any damage resulting from using
the appliance outside this scope, any incorrect
use, as well as any manual modifications to the
ROBOT VACUUM CLEANER
KBVVC4527 EN
5
product will not be covered and automatically
voids the warranty.
Assistance
In case of malfunction, take your appliance to
the Customer Support Service for assistance.
This appliance can be used by children aged
from 8 years and above if they have been
given supervision or instruction concerning
use of the appliance in a safe way and if they
understand the hazards involved. Cleaning and
user maintenance shall not be made by children
unless they are older than 8 and supervised.
Keep the appliance and its cord out of reach of
children aged less than 8 years.
Appliances can be used by persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been
given supervision or instruction concerning use of
the appliance in a safe way and understand the
hazards involved.
Children shall not play with the appliance.
These instructions are also available at www.
suporteworten.pt
1.1. Power Supply
Make sure the main voltage is compatible with
the appliance’s. If this is not the case, please
consult the Customer Support Service.
EN
6
1.2. Power Cord and Other Cables
Do not tangle the cord or pull it to disconnect the
appliance. Also, keep the cord away from warm
surfaces.
Never use the appliance if it has a damaged
cable or socket.
Take it to the Customer Support Service for
replacement.
1.3. Humidity and Water
Do not use your appliance in humid places. Do
not allow the appliance to become wet under
any circumstances as this may be dangerous. To
avoid fire hazard or electric shock do not expose
your appliance to humidity or water. Furthermore,
do not place your appliance under water (e.g.
for cleaning).
1.4. Cleaning
Before cleaning, be sure to switch off the
appliance and remove the plug from the main
power supply. Always allow the unit to cool down
before cleaning.
To clean the exterior of the product, use a dry soft
cloth only.
For more instructions on cleaning the item, see
section “2.3. Maintenance”.
1.5. General Precautions
• Please follow the instructions in the user manual
which will help you to properly install and
ROBOT VACUUM CLEANER
KBVVC4527 EN
7
operate this product and enjoy its advanced
features. Please keep the instructions for future
reference.
• Read all instructions before using the product.
• Maintenance and service operations are only
to be carried out by authorized professionals.
• Any damage caused by manual modifications
to the product is not covered by the warranty.
• If this product is used for other purposes
than the ones originally intended, or if it is
not correctly connected, the product may
become damaged and the warranty will be
voided.
• Instructions for use shall be provided with the
appliance so the appliance can be used
safely.
• The plug must be removed from the outlet
before cleaning or performing maintenance
jobs on the appliance.
• Only to be used with the power supply unit
provided with the appliance.
• This appliance is intended for household use
only.
EN
8
2. OPERATING INSTRUCTIONS
2.1. Product Description
Main Body
*1 pc
Instruction
*1 pc
Charging
Station
*1 pc
Filter
*1 pc
Side Brush
*2 pcs
Adaptor
*1 pc
Clean Brush
*1 pc
Tips:
* There is one battery, two side brushes and one filter assembled
in main body and there are two side brushes and one filter
inside.
Accessories
Top cover Dust box button
Front shell
FRONT VIEW
Control buttons
Signal window
ROBOT VACUUM CLEANER
KBVVC4527 EN
9
BOTTOM VIEW
Front wheel
Battery
Left wheel
Middle brush
Side brush
Right wheel
Rubber brush
2.2. Product usage
Safety Instruction
Before using the product, please observe the following safety
precautions:
• Keep the instructions in a safe place where it can be found
for future reference.
• When giving the product to others, please include the
instructions.
• Improper operation will lead to serious personal injury and
damage the product.
EN
10
Caution
Only use the original adaptor, battery and
charging station to avoid damaging the
appliance and cause a fire due to electric
shock and high voltage.
If you find that the main body and
accessories are damaged, please do
not use the appliance and contact the
Customer Support Service. No one is allowed
to disassemble, perform maintenance or
reassemble the machine.
Unplug the appliance before any
maintenance job.
Do not touch the battery socket and the
appliance when your hands are wet,
otherwise it will cause electric shock.
If the cord is damaged, to avoid danger,
please contact the Customer Support Service
and wait for professional personal to replace
it.
Don’t use this product on stairs, hallways, etc
without guardrail to prevent the vacuum
cleaner from falling accidentally and causing
personal injury.
Do not place the machine near fire,
inflammable, explosive and corrosive
materials.
Do not put your clothes or any part of your
body (hair, finger, etc) into the main brush or
the wheels, or it will cause personal injury.
ROBOT VACUUM CLEANER
KBVVC4527 EN
11
Attention
The appliance is for indoor use only.
Keep water, oil and other liquids away from
the machine.
Clean the floor of wires to avoid them
becoming tangled into wheels and brushes.
Remove all fragile objects.
The charging station and space isolator
should be placed against the wall and a flat
place, otherwise it may not work properly.
Turn off the appliance when taking out the
battery.
EN
12
When not being used for a long time,
disconnect the power.
If the charging station is removed while
working, the appliance may not be able to
be recharged.
Check for shard objects such as glass, nails,
etc prior to using the appliance to avoid
damaging it.
Don’t use this appliance in humid or
flammable, explosive and corrosive
environments.
Child Safety
• The appliance shall not be used by children.
• Children shall not play with the bag to avoid suffocation.
Battery
1. Only the original battery should be used with the appliance.
2. Please turn off the power switch before taking out the
battery.
3. The battery must be taken out before discarding it.
4. If you want to replace the battery, please contact our
Customer Support Service. Using the wrong battery can
cause accidents.
ROBOT VACUUM CLEANER
KBVVC4527 EN
13
5. If the battery leaks, please do not touch the liquid. Wipe the
liquid with a dry cloth and put the battery into the recycling
bin or bring it to a recycling centre. Do not throw it away.
6. The battery includes hazardous substances, so please discard
of it into the adequate recycling site according to local
environmental protection rules and regulations.
Suitable Surfaces
The cleaner is suitable to the following surfaces:
Wooden Tile Carpet
Exception Clause
The following product circumstances are not covered by the
warranty:
A. The damage to the product is a result of the user’s operation
and storage against our Manual;
B. The whole machine and its components have been out of
warranty period;
C. The damage to the product is a result of repairs not or
authorized by our company;
D. Proof of purchase can’t be provided;
E. The model in the warranty card is inconsistent with that of the
product for repair or it has been altered;
F. The damage to the product is a result of elements beyond
control such as natural disasters;
G. Failure or damage to the product is a result of accidental
or human factors (including but not limited to, liquid
feeding, improper insertion and pulling, scratch, bumping,
inappropriate voltage input, etc).
EN
14
Product Installation
Please install the battery before using the cleaner.
Adapter
socket
Charging terminal
Aim at the terminal and
insert it during wiring
Unplug it in the reverse
direction during unwiring
Black Red
1. Connect the battery pack terminal to the appliance; then,
press the battery pack into the battery box.
2. Place the charging station on a flat ground surface against the
wall. Clean up dust and other debris and stick the charging
station on the floor. Then, insert the adapter into the socket.
Tips:
The charging station can’t be placed on carpet. It is
recommended to place it at a fixed position for a long time.
Please don’t move the charging station during cleaning.
Danger! Electric shock
1. Place the charging station on a flat ground surface against
the wall. Make sure no obstacles are within 3 meters and
within 1 meter of it.
2. Connect the adapter and charging station.
ROBOT VACUUM CLEANER
KBVVC4527 EN
15
Control Button
Control Button
Shortly press Turn On/off button
In standby
Double click Recharge button
Work Mode:
Manual Mode
Auto Cleaning
Shortly-press the button, the red indicator
will light (standby mode). Then, click the
button and the indicator will turn green and it
will start cleaning automatically.
Auto Recharge
When the vacuum cleaner is in standby
mode, double click the button. The
indicator will turn green and blink at the
same time, meaning it has entered the auto-
recharging mode.
Operation guideline of indicators
No. State Display Operation
1 Turn-off Light-off After 5 mins in standby mode,
the appliance will enter deep
sleep mode. In deep sleep
mode, if it has low battery or if it
remains in that mode for more
than 8 hours, the appliance will
power off.
2 Turn-on Red
Light-on
Short-press and enter the
Standby mode.
EN
16
No. State Display Operation
3 Cleaning Green
Light-on
Short-press and enter the Auto
Cleaning mode.
4 Recharge Flash
Green
Double click and it will enter
the Recharge mode.
5 Charging Flash
Red
6 Error Flash red
and beep
7 Fully
Charged
Light off
8 Pairing
mode
Flash
Orange
In standby, long-press for 6
sec. until it blinks orange.
Charging Methods
Manual Charging:
Charging with the charging station:
Connect the adapter to the charging station
and then insert it into the outlet. Place the
appliance on the charging station to charge.
(The green indicator will flash when looking
for a charging station, the green indicator on
charging station will be off when charging is
completed successfully; the red indicator
will flash during charging and remain on after
fully charged).
Click “DOCK” on the APP and the appliance
will search for the dock station automatically
Danger! Electric shock .
ROBOT VACUUM CLEANER
KBVVC4527 EN
17
Auto Charging:
Automatic Charging:
When it appliance’s battery is low, the green
indicator will flash and enter the Recharge
mode.
App Operation Guide
ATTENTION
Due to software upgrades or other reasons, this guide’s
operation will not update regularly. This document is for
reference only, unless otherwise prescribed. All statements,
information and recommendations in this document do not
constitute any express or implied warranties.
SUMMARY
The Tuya Smart app is an intelligent home application
developed for Android and IOS platforms. This document
intends to guide initial user’s operation steps and inform on
software precautions. The software publisher of this app will
provide technical support to users, which may cooperate with
our company. For specific service content and rules, refer to
the app’s user agreement.
ENVIRONMENT OF TEST AND USE
On an Android 4.0/IOS 7.0 or higher, search “Tuya smart” and
download it by scanning the QR code (as shown below).
Android user can use the App store.
EN
18
PREPARATION
1. Long press until you hear a buzz sound and it starts blinking
to enter pairing mode.
2. Open your phone’s “Setting” interface and enter to set your
WLAN (Wireless LAN).
3. Find this app on your app list and click to open it.
Registration
When you open the app, will
enter the interface below. Press
“Login” and enter a registered
account number, phone
number or email address and
then enter a password to
register. You can also click the
“Register” button below.
Since there is no current
registered user, you need to
start by making your register.
Enter the phone number or
email address in the interface
shown below and then click
“Next”.
ROBOT VACUUM CLEANER
KBVVC4527 EN
19
Enter the verification code
and password you want to
set to complete registration.
Click “Confirm” enter the login
page.
If you are using an already
existing account, just click
“Login” to enter. If you log into
an account and the password
is wrong, you can click
“Forgot Password” to reset
your password.
EN
20
Forgot your password
If you forget your, click “Forgot
Password” to reset it. Press
“Request Password”, add
your mobile number or email
address and click “Next” to
verify your identity.
Shown as follows, enter into
safety verification, Enter the
verification code and the
new password and press
“Confirm”. If it fails, do it
again.
ROBOT VACUUM CLEANER
KBVVC4527 EN
21
Add Device
Click “Add Device” Select the device you want to
connect as “Robot vacuum”.
EN
22
Long press the on/off button
CLEAN for 5 seconds until the
Wi-Fi indicator light flashes.
Click “Confirm” and the
indicator will blink rapidly.
Input your home Wi-Fi
password and click “Confirm”.
ROBOT VACUUM CLEANER
KBVVC4527 EN
23
Wait for your mobile to
connect to the Internet (as
shown below)
The device has been added
successfully. Click “Done” to
access the interface below.
Produkt Specifikationer
| Mærke: | Kubo |
| Kategori: | Støvsuger |
| Model: | KBVVC4527 |
Har du brug for hjælp?
Hvis du har brug for hjælp til Kubo KBVVC4527 stil et spørgsmål nedenfor, og andre brugere vil svare dig
Støvsuger Kubo Manualer
9 September 2024
21 Juli 2024
Støvsuger Manualer
- Point
- Klarstein
- Draper
- Westfalia
- Teesa
- Caso
- Hyundai
- Columbia Vac
- HammerSmith
- Malmbergs
- BEEM
- Eureka
- Kensington
- Amica
- MyGenie
Nyeste Støvsuger Manualer
8 August 2025
8 August 2025
8 August 2025
8 August 2025
8 August 2025
8 August 2025
8 August 2025
7 August 2025
7 August 2025
7 August 2025
