INSTRUCTION MANUAL
DIGITAL MULTIMETER
KEW 1061
／
1062
60
Thank you for purchasing our Model KEW1061, KEW1062 Digital Multimeter.
This user’s manual describes the specifications and handling precaution for this Digital
Multimeter.
Before using this Digital Multimeter, thoroughly read this manual to get a clear understanding
on proper use.
Always observe the following instructions.
Failure to do so may impair the protection provided by the instrument and probes, and may
result in electrical shock or other dangers that may lead to serious injury or the loss of life.
KYORITSU is in no way liable for any damage resulting from the user’s mishandling of the
product.
For safe use of this product, the following safety symbols are used on the product:
n About This Manual
• Everyefforthasbeenmadetoensureaccuracyinthepreparationofthismanual.
However, should any errors or omissions come to the attention of the user, please contact
KYORITSU.
• The contents of thismanual are subject to change without prior notice becauseof
improvement in performance or function.
• All rights reserved. No part of this manual may be reproduced in any from without
KYORITSU'S written permission.
62
W ARNIN G
n Always observe the following instructions. Failure to do so may result in
electrical shock or other dangers that may lead to serious injury or the loss of
life.
Test leads / Test leads with crocodile clip (optional accessory)
• UsetheprobessuppliedbyKYORITSUwiththisinstrument.
• Donotusetestleads/testleadswithcrocodileclipthathavedeterioratedoraredefective.
Check test leads/test leads with crocodile clip continuity.
• Disconnecttestleads/testleadswithcrocodileclipfromthecircuitundertestbeforeopening
the casing to replace the batteries or for any other reason.
• Disconnecttest leads/test leads with crocodile clip from the circuit under test before
attaching/detaching the test leads/test leads with crocodile clip to/from the instrument.
• Disconnecttestleads/test leads withcrocodileclipfromtheinstrumentbefore openingthe
casing to replace the batteries or for any other reason.
• Acapisprovidedonthetipofatest lead.
Use a test lead with the cap on for safety (safety standards: IEC 61010-031).
• Do not use the crocodile clip of test leads being loosen or removed conditions.
• Stop using the test lead if the outer jacket is damaged and the inner metal or color jacket is
exposed.
Casing
• Do not use the instrument if there is any damage to the casing or when the casing is
removed.
Fuses
• Usefusesofthespeciedratingwhenthefuseisreplaced.
Operating Environment
• Do not operatetheinstrument inan atmospherewhereany ammable orexplosivegas is
present.
• Avoid using theinstrument if ithasbeenexposed to rainor moistureorif yourhands are
wet.
Disassembly
• Noperson,exceptpersonnelfromKYORITSU,isauthorizedtodisassemblethisinstrument.
65
1. Overview
l Fast and more accurate measurement
The KEW1061 and KEW1062 digital multimeters use Σ modulation for A/D conversion,
which enable fast and more accurate measurement.
l Display
5-digit (LCD)
Maximum Reading: 50000
Bar graph indicator
l Supports a variety of measurement function
Measurement function
DC Voltage, AC Voltage, DC Current, AC Current, Resistance, Frequency, Temperature,
Capacitor, Duty cycle ratio, Decibel (dBV, dBm), Continuity Check, Diode Test,
LowPower-Ω*
Other functions
DataHold(D•H),AutoHold(A•H),PeakHold*(P•H),RangeHold(R•H),
Maximum value (MAX), Minimum value (MIN), Average value (AVG),
Zero Adjustment (Capacitor, Resistance), Relative values, Save to Memory,
LCD backlight.
LowPower-Ω:Measuresresistanceunderlowmeasurementcurrent.
*:FormodelKEW1062only
l Switching detection modes
Effective value (root mean square value) detection (RMS) and mean value detection (MEAN)
can be switched during AC voltage or AC current measurement (KEW1062 only).
l Low-passlter
The low-passltercanbeswitched on/offduringACvoltageorACcurrent measurement
(KEW1062 only).
l Communication: optional communication package is required
• MeasurementdatacanbetransferredtoaPCusinganoptionalUSBcommunicationset.
The data can be read by certain applications to make trend graphs or can be converted
intoExcelles.
• The data can also be output from an optional printer via an optional printer communication
set.
l Safety design
Complied standards: CE standards
Usesacurrent-inputterminalshutterforpreventingwronginput.
Useshigh-performanceUL-standardfuses.
68
Battery life: Approximately 120 hours
(Operating hours of alkaline batteries when in DC voltage-mode.)
Note: The battery life varies depending on the operating conditions.
Insulationresistance:1000VDC,100MΩormore
Withstandvoltage: 6.88kVrmsACforveseconds
(across input terminals and casing)
Externaldimensions: Approximately192(L)×90(W)×49(D)mm
Weight: Approximately 560g (including batteries)
Complied standards: Safety standards
IEC61010-1,IEC61010-2-033,IEC61010-031
CAT III (Max. input voltage: AC/DC1000V)
CAT IV (Max. input voltage: AC/DC600V)
Pollution degree 2, indoor use,
2000m max. above sea level
Utilisationinterne2000mmax.au-dessusduniveaudelamer.
EMC standards
IEC61326-1ClassB
Eect of radiation immunity:
Intheradio-frequencyelectromagneticeldof3V/m,accuracyis
withinvetimestheratedaccuracy.
Environmental standard:
EN50581 Monitoring and control instruments
69
Standard accessories: Batteries : 4
Test leads: 1set (M-7220A)
Fuse (included): 440mA/1000V (M-8926), 10A/1000V (M-8927)
Instruction manual: 1
Optional accessories: Carrying case M-9154
(for the main unit with test leads
and communication cable)
Test leads (1set) M-7220A
Test leads with crocodile clip (1set)
M-7234
Fuse
440mA/1000V M-8926
10A/1000V M-8927
Temperature probes M-8405, 8406, 8407, 8408
USBCommunicationset M-8241(Software,USBadapterand
cable)
PrinterAdapterandCable M-8243
Printer M-8246
AC adapter (for printer, Europe)
M-8248A
Thermal paper for printer (10 rolls)
M-8247
70
3.2 Accuracy
Test conditions:
Temperatureandhumidity:23±5ºCat80%RHorless
Accuracy:±(%ofreading+digits)
Note: Each response time is a value to rated accuracy within selected range.
DC Voltage Measurement V
Range Resolution Accuracy Input Resistance Maximum
Input Voltage
KEW1061, KEW1062
50mV 0.001mV 0.05+10
Approx.100MΩ 1000V DC500mV 0.01mV 0.02+2
2400mV 0.1mV
5V 0.0001V 0.025+5
10MΩ 1000V rms AC
50V 0.001V
0.03+2500V 0.01V
1000V 0.1V
NMRR: 80dBormore50/60Hz±0.1%
(70dBormore50/60Hz±0.1%when50mVRange)
CMRR: 100dBormore50/60Hz(Rs=1kΩ)
Responsetime:0.3secmax.
AC Voltage Measurement [RMS] V
KEW1061
ACCoupling,Rms-valuedetection,Crestfactor*:<3
Range Resolution
Accuracy Input
Impe-
dance
Maximum
Input
Voltage
10 to 20Hz 20Hz to
1kHz
1k to
10kHz
10k to
20kHz
500mV 0.01mV
1.5+30*1 0.7+30*1 2+50*2
11MΩ
<50pF 1000V
rms AC
1000V DC
5V 0.0001V
50V 0.001V 10MΩ
<50pF
500V 0.01V
1000V* *2 *2 3+30*20.1V -
*: Crestfactor<1.5at1000Vrange
Accuracy*1:At5to100%ofrange,*2:At10to100%ofrange
CMRR:80dBormoreDCto60Hz(Rs=1kΩ)
Response time: 1 sec max.
