Leisure LN950XS Manual

Leisure Køkkenvask LN950XS

Læs gratis den danske manual til Leisure LN950XS (2 sider) i kategorien Køkkenvask. Denne vejledning er vurderet som hjælpsom af 11 personer og har en gennemsnitlig bedømmelse på 4.9 stjerner ud af 6 anmeldelser. Har du et spørgsmål om Leisure LN950XS, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/2

05/04 1820

1. It is recommended that the inset sink is ﬁ tted to the

worktop before being permanently ﬁ xed to the cabi-

net.

2. Place the sink upside down on worktop. Position the

sink relative to the worktop as required, ensuring

that the cabinet framework will be clear of all parts of

the sink, or alternatively where provided use cut-out

template found on sink wrapper.

With sharp soft pencil

draw round sink as ac-

curately as possible.

3. Remove the sink and draw another line 10mm inside

the outline of the sink top.

This is the cutting line for the aperture.

4. Drill as large a hole as possible inside the cutting

line. Using a pad saw, jig saw or similar, cut out the

aperture to the cutting line.

5. Remove the paper backing from the quadrant section

and apply to all 4 corners of the sink.

Remove the protective back from the main seal and

stick to the underside of sink.

6. Attach the ﬁ xing clips to the sink rail ensuring that

the two ‘prongs’ of the clip face inwards. Open the

hinge on the clip.

Stainless Steel Inset Sinks with Fixed Position Clips

7. Turn the sink upside down and lay the worktop over

the sink. Swing the clip into position. (This is the most

effective method although if the worktop has been

ﬁ xed to the cabinet, the sink can be placed in the

aperture and the ﬁ xing effected from underneath).

8. Loosely tighten the corner ﬁ xing clips to centralise

the sink in the cut-out.

9. Tighten the ﬁ xing screws.

Do not overtighten the ﬁ xing clamps once the sink is

fully bedded in the sealing tape. Do not tighten fully

at the ﬁ rst attempt.

10. In certain circumstances it may not be possible to ﬁ t

a clip to all the ﬁ xed positions; provided a good seal

is achieved it is not detrimental to omit clips where

difﬁ culty arises.

Recommended tightening sequence for sink

ﬁ xing clips

05/04 1820

After Care Stainless Sinks

Day to Day Care

Routine cleaning of your stainless steel sink is

easy if the following simple procedure is followed

After use wipe the bowl and drainer with a soft

damp soapy cloth, rinse with clean water. In hard-

water areas, an application of Jif will avoid any

build-up of dull ﬁ lm of waterborne deposits.

Although stainless steel is an extremely durable

material and will withstand a great deal of hard

use, it can be scratched by hard or sharp objects.

If the surfaces are to be kept in a blemish free

condition reasonable care should be taken when

handling such items.

Discolouration and Heavy Staining

Staining of stainless steel in most cases is due

to something being deposited on the steel rather

than an attack on the material itself. The most

common cause of staining is the build up of a thin

ﬁ lm of water borne deposits on the sink surface,

often ﬁ rst seen as a rainbow effect. The build up of

such a ﬁ lm can be avoided by drying the surface

of the sink after use as described above. How-

ever, should such a ﬁ lm appear, it can be readily

removed with a soft damp cloth and Jif. To remove

the ﬁ lm, apply the Jif neat and rub vigorously with

a damp cloth along the length of the sink surface.

After cleaning rinse thoroughly with clean water

and dry. Wire wool products and ferrous water

supply pipes can leave minute ferrous particles

adhered to the sink surface. Since stainless steel

under normal conditions does not rust, these par-

ticles can cause the appearance of small brown

rust stains. These stains can be removed using

the procedure described above.

CAUTION :

Certain household products contain substances

which will attack the stainless steel surface, they

are :

1. Bleaches :

Most common domestic bleaches contain Chlorine

in the form of a hypochlorite. Chlorine attacks the

microscopic Chromium Oxide ﬁ lm on the surface

and can cause pitting of the surface. Bleaches

should always be used in the prescribed strength

speciﬁ ed by the manufacturers. Undiluted bleach-

es can cause pitting and staining of the surface

and should be immediately rinsed off with plenty

of clean water. All cleaning agents containing

hypochlorites are unsuitable for use with stainless

steel and, even highly diluted, can cause pit-

ting under certain conditions. For this reason it is

strongly recommended that the sink is not used for

soaking clothes or cleaning clothes in hypochlorite

solutions for long periods.

2. Silver Dip Cleaners :

These are particularly harmful since they contain

strong acids which can cause discolouration and

pitting. The ﬁ rst sign of this is an iridescent rain-

bow stain which turns an etched dull grey colour.

Should any Silver Dip Cleaner come into contact

with the surface of the sink it should be immedi-

ately rinsed off with plenty of clean water.

3. Corrosive Foodstuffs :

Fruit juices, damp salt, vinegar, readymade mus-

tards, pickle and mayonnaise can cause pitting

and corrosion if left in contact with the stainless

steel surface for long periods.

4. Acids :

Sulphuric, Hydrochloric and other strong acids will

cause pitting corrosion, as will photographic devel-

oping liquids. All should be immediately washed

off with plenty of clean water if contact occurs.

Cleaning :

Always use a soft cloth. The use of coarse grit

scouring powders or soap ﬁ lled wire wool cleaning

pads is not recommended, since both will mark the

surface of the sink. Wire wool pads can leave tiny

fragments of wire embedded in the surface and

these can rust and leave small brown rust stains.

Vigorous rubbing with a soft cloth, JIF, neat deter-

gent, cleaning cream or liquid will remove these

stains. Always remove wet cleaning aids (cloths,

containers, etc.) from the sink surface after use in

order to avoid the formation of water marks and

rust stains.

Produkt Specifikationer

Mærke:	Leisure
Kategori:	Køkkenvask
Model:	LN950XS
Bredde:	950 mm
Dybde:	508 mm
Produktfarve:	Rustfrit stål
Første skål, dybde:	180 mm
Første skål, dimensioner (BxL):	420 x 400 mm
Antal vaskeskåle:	1 skåle
Vask, type:	Top-monteret vask
Vask form:	Rektangulær
Vask materiale:	Rustfrit stål
Facon på første vask:	Rektangulær
Vandhane, hul:	Ja
Drænebræt:	Ja
Antal huller til haner:	1
Størrelse på vandhane:	35 mm
