For more information please contact tech support at: 1-800-824-3005 or visit: www.leviton.com

NOTE: 900um boots are sold separately.

4999K-*LC

SKLC (Secure Keyed LC) Connector Field Termination

ASSEMBLY INSTRUCTIONS

5. Using the brush attached to the lid on the bottle of primer, apply the primer to the

area of ber as indicated. See (FIGURE 2).

6. Insert the ber into the back of the connector. To prevent premature bonding, use

a continuous motion, until the ber is fully seated in the connector. The primer will

activate the adhesive and begin the bonding process.

NOTE: The ber should be inserted within 45 seconds of placing the primer on the ber.

7. Hold the ber in place for 10-20 seconds, and allow up to 3 minutes for the

adhesive to fully bond.

8. Slide the boot back up over the back of the connector.

CLEAVE AND POLISH

1. When the adhesive is cured (no longer wet), scribe the ber where it meets the

bead of adhesive at the end of the ferrule. (FIGURE 3)

2. Pull the ber away from the connector, properly dispose of the debris.

NOTE: Loose ber debris can be dangerous. Be sure to properly dispose of ber

debris.

3. Begin by “air polishing” the connector with 12μm polishing film. Leviton’s 12 μm

lm is a dark pink in color. Hold the edge of the lm, with thumb and fore nger,

dull side down. Hold the connector ferrule pointing up. Gently touch the connector

to the lm. While holding the polishing lm in contact with the connector, move the

polishing lm in approximately a 1 inch circle to remove the ber stub. The

scraping sound of the ber on the lm will cease when the air polish process is

complete.

PREPARE

1. Slide boot onto the ber, with the small end inserted rst, away from the

connector. (FIGURE 1)

NOTE: 900um boots are sold separately.

2. Remove 4 inches of the outer cable sheath for jacketed cable.

3. Strip the 900μm buffer as indicated in the measurements provided in the chart

below (FIGURE 2)*, strip the fiber in increments of ¼”.

4. Clean exposed ber with a lint-free wipe damped with 99% isopropyl alcohol to

remove any contaminants.

NOTE: Images are not to scale.

ASSEMBLE

1. Remove the dust cap from the connector.

2. Dry t the ber by inserting the ber into the connector. This will assure that

all coating has been removed and the ber can be inserted into the connector

ferrule.

3. Shake the adhesive bottle before using. Remove the cap from the adhesive

bottle, and attach the needle by pressing it gently onto the top of the bottle

until you feel it set into place.

NOTE: Syringes are also available for inserting adhesive. See parts list for part

number.

4. Insert the needle into the back of the connector, holding it rmly in place while

lling. Being careful not to over ll the connector, squeeze the bottle gently,

injecting the adhesive into the connector. Continue squeezing until a dot of

adhesive is visible at the ferrule end of the connector, and then remove the

needle. Wipe away any excess adhesive from the end of the ferrule.

4. Hold a lint-free wipe across the nger tips, and then gently press the ferrule

end-face against the wipe. Twist the connector in place to remove any debris.

Do not drag the connector across the lint-free wipe.

5. Wipe the bottom surface of the LC 1.25mm polishing puck and the surface of

the polishing pad with a lint-free wipe damped with 99% isopropyl alcohol to

remove any contaminants.

6. Place the 3μm film on the polishing pad, dull side up. Leviton’s 3μm film is

yellow in color. Place the polishing puck on the lm. Gently insert the

connector ferrule into the polishing puck and using very light pressure, trace 15-

20 figure 8’s on the lm. Inspect to ensure the ber is polished ush by rst

gently dragging the connector across a lint-free wipe. Fiber should not snag. If

the ber snags, continue polishing until it does not snag. Remove debris with a

lint-free wipe dampened with 99% isopropyl alcohol.

7. Repeat steps 5 and 6 with 0.3μm polishing film. Leviton’s 0.3μm film is a light

blue in color.

8. Using a Leviton 200x inspection scope, inspect the ber core to assure the core

is not scratched, cracked, broken and is clean. (FIGURE 4)

9. Replace the dust cap on the connector to maintain cleanliness.

INSPECTING THE BACKLIT FIBER:

SCRIBE AND PULL FIBER AWAY

Multimode 62.5/125 Singlemode 9/125

White area must be free

of all obstruction. Grey

area should be free of

scratches and dark

spots.

ALL BUFFERED CABLE

PK-93775- - -10 02 0A

For more information please contact tech support at: 1-800-824-3005 or visit: www.leviton.com

IMPORTANT INSTRUCTIONS

1. Read and understand all instructions. Follow all warnings and instructions marked on the product.

2. Do not use this product near water-e.g., near a tub, wash basin, kitchen sink or laundry tub, in a

wet basement, or near a swimming pool.

3. Never push objects of any kind into this product through openings, as they may touch dangerous

voltage s.

4. SAVE THESE INSTRUCTIONS.

SAFETY INFORMATION

1. Never install communications wiring or components during a lightning storm.

2. Never install communications components in wet locations unless the components are designed

specically for use in wet locations.

3. Never touch uninsulated wires or terminals unless the wiring has been disconnected at the network

interface.

4. Use caution when installing or modifying communications wiring or components.

5. To prevent electrical shock, each opening must be lled with a module.

INSTALLING THE SECURED KEYED LC HOUSING

NOTE: Assure correct connector polarity prior to nal assembly of the housing; refer

to (FIGURE 5). Failure to do so may result in the need to disassemble the

Secured LC housing, which will result in damage to the housing.

1. Place the upper housing with the top of the housing down on the work surface

(FIGURE 6).

2. Insert the rst ber connector, with the LC latch facing down, into the correct

connector slot in the upper housing, making sure the retention slots on the

connector are aligned with the capture feature in the housing (FIGURE 7).

3. Now insert the second fiber connector, with the LC latch facing down, into the correct

connector slot in the upper housing, making sure the retention slots on the

connector are aligned with the capture feature in the housing (FIGURE 8).

4. Insert the Assembly Alignment Guide into the lower housing, from the bottom

(FIGURE 9).

5. Place the lower housing over the upper housing with the Assembly Alignment Guide

positioned so it will t into the alignment slot into the upper housing (FIGURE 10).

6. Place the housing assembly between your thumb and ngers, gently squeeze the

upper and lower housing assemblies together until the retention snaps lock the

upper and lower housing together.

7. Remove the Assembly Alignment Guide from the connector housing.

NOTE: Always inspect the ber connector before inserting into an adapter. Leviton

200x scope with duplex adapter is specically designed to allow inspection

of duplex connector pairs.

NOTE: Once a connector is engaged into an adapter, an extraction tool of the

same keyed color is required to disengage from the adapter

FIBER STRAND POLARITY

Proper polarity of the ber strands is required to assure transmit and receive

functionality. See gure 5.

The numbered strands (i.e. 1, 3, 5,) of the fiber cable typically are placed in odd

the A polarity position. The numbered strands (i.e. 2, 4, 6,) of the ber cable even

typically are placed in the B polarity position. This should result in proper A-B

polarity alignment.

Secure Keyed LC Kits & Accessories

Part No.

Secure Keyed LC Connector Kit, 900um, MM/SM - black

4999K

ELC

Secure Keyed LC Connector Kit, 900um, MM/SM - green

4999K

VLC

Secure Keyed LC Connector Kit, 900um, MM/SM - blue

4999K

LLC

Secure Keyed LC Connector Kit, 900um, MM/SM - orange

4999K

OLC

Secure Keyed LC Connector Kit, 900um, MM/SM - red

4999K

RLC

Secure Keyed LC Connector Kit, 900um, MM/SM - slate

4999K

GLC

Secure Keyed LC Connector Kit, 900um, MM/SM - white

4999K

WLC

Secure Keyed LC Connector Kit, 900um, MM/SM - yellow

4999K

YLC

900μm Boot, Blue (bag of 50)

4999K

BLU

900μm Boot, Beige (bag of 50)

4999K

BGE

900μm Boot, Black (bag of 50)

4999K

BLK

900μm Boot, Aqua (bag of 50)

4999K

AQU

Extraction Tool with Dust Cap

ETRTN

*TL

* = W (white), Y (yellow), O (orange), R (red), L (blue), V (green), G (slate), E (black)

Fiber Installation Tools

Part No.

Fast Cure Tool Kit

49800

FTK

Adhesive Primer Kit

49800

680

Fast Cure Consumables Kit

49800

FAC

200x Fiber Inspection Scope

49886

FSP

Duplex LC Scope Adapter (for use with Leviton 200x Scope)

49886

LCD

LC Polishing Puck

49886

LCP

Fast Cure Carrying Case

49886

FCC

Replacement Needles

49886

FCN

Syringes (bag of 25)

49886

SYR

INSIDE

OF TOP

HOUSING

PK-93775- - -10 02 0A
