PCM 81 Quick Reference Guide

Basic Operation

The PCM 81 has 5 basic modes of operation, selected by pressing: Program Banks, Register Banks, Edit, Control or Tempo

Program Banks

and Register Banks

Press toProgram Banks

cycle through 6 banks of 50

presets. Press Register

Banks to access an internal

bank of 50 registers (or

PCMCIA card banks) where

you can store modied ver-

sions of the factory-loaded

presets.

Each set of PCM 81 controls

is organized into a matrix of

as many as 10 rows and 10

columns.

Simultaneously press Up

and to return to 0.0.Down ←

XXXXXXX XXXXXXXXX✱

3.6 XXXXXXXXXXXXXXXXX

→

↑

↓

SELECT moves you

horizontally across

the matrix.

Your current matrix location is shown in the

lower left of the display. A , an or a P R C

preceding the number indicates you are in a

P R Crogram, egister or ard Bank. If there is no

number shown here, you are in mode.Go

(See .)Edit

Up Down and

move you

vertically

through the

rows of the

matrix.

In , or Edit Control Tempo mode, a ✱

indicates the presence of multiple param-

eters within a single matrix location. Press

Load/✱ to cycle through all of the param-

eters; simultaneously press withLoad/✱

either or to backstep.Up Down

Edit

Press to access allEdit

available parameters for the

currently running eect. Turn

ADJUST to alter the value of

any displayed parameter.

Control

Press Control to access sys-

tem parameters, MIDI con-

trols, and global control of

parameters such as Mix,

Tempo, and Bypass type.

Tempo

Press Tempo to set tempo-

related values that aect the

delay time and LFO rate pa-

rameters of the currently

running eect.

In , or Edit Control Tempo mode, ADJUST scrolls

through the range of available settings for the displayed

control . In Program Banks and Register Banks mode,

ADJUST is patched to one or more eect parameters.

To set PCM 81 tempo rate,

press Tempo. Use SELECT

and Up and Down to locate

matrix position 0.0. Turn AD-

JUST to select any Tempo

Rate from 40-400 BPM.

Any PCM 81 delay param-

eter (as many as 10 in some

eects) and any time-based

modulator can be individu-

ally assigned an absolute

time or tempo value.

You can set delay times in

milliseconds, or in a ratio of

echoes/beats which are

linked to tempo. When you

change tempo, the delay

times will change to main-

tain the same rhythm at the

new tempo.

Note: You can set and display delay values in units of time, or

with tempo values. Whenever a delay value is displayed in Edit

mode, press Up and Tempo simultaneously to toggle these two

options.

The PCM 81 oers an exten-

sive set of informative dis-

play messages which can be

activated from the front

panel. If you want to know

more about the function of a

particular button —without

actually executing any ac-

tion — press and hold the

button down. While you are

holding down the button, an

explanatory message will

appear on the display.

Or, press twice inTap

rhythm to establish the

tempo rate you want. Tap is

always active, allowing you

to change tempo on the y.

Tempo

Info

Simultaneously press the

Banks button with either Up

or to backstepDown

through the banks.

Turn SELECT to view all of

the eects in the selected

bank. A ✱ in front of an eect

name indicates that the ef-

fect is not loaded. Hold down

either Banks button to see

the name of the currently

running eect.

Press to load anyLoad/✱

displayed eect.

ADJUST acts as a soft knob

for adjustment of one or more

patched eect parameters.

Lexicon Part No. 070-12615

3 Oak Park • Bedford MA 01730-1441 • Tel: (781) 280-0300 • Fax: (781)280-0490

Press . The currentStore

program name will appear

with a ashing cursor over

the first letter of the name.

Press Load/✱ to display the

name currently assigned to

the ADJUST knob patch.

Use the same procedure for

entering a new name.

Press twice toLoad/✱

move the ✱ to the Register

ID number in the lower left

corner of the display. Use

ADJUST or SELECT to

choose the register where

you want the eect saved.

When the display shows the

press Store. Press Store in

response to the "Are you

sure?" message to save your

new eect to the displayed

Note: The PCM 81 will not perform a store instruction if the

Memory Protection option is on. To turn Memory Protection o,

press Control. Use Up and Down and SELECT to locate matrix

position . Turn ADJUST to display .1.5 O

In addition to these easy plug and play techniques, the PCM 81 provides extensive

system control via front panel patching or MIDI. For complete details on these and other

features, read the PCM 81 Owner's Manual.

PCM 81 Quick Reference Guide

Turn ADJUST to select a new

character. Press Up or Down

to select a new type of char-

acter (upper or lower case,

numeric, symbolic, or blank).

Turn SELECT to move the

cursor to a new character.

Store

Audition the Programs

The PCM 81 offers two levels of editing control: Go mode and Pro mode.

Turn SELECT to view the

available parameters.

Go mode gives you access to a specic set of as many as 10

parameters for each of the 300 presets. We have designed

each set of parameters to allow you to make changes to the

eect without losing the character of the sound.

In mode, press toGo Edit

access the most useful pre-

set parameters for the cur-

rently running eect.

Pro mode gives you access to the full eect edit matrix

whenever you press . The edit matrix contains all eectEdit

parameters, as well as Patching and Modulation controls.

Turn ADJUST to change the

value of any displayed pa-

rameter.

The PCM 81 is shipped in Go mode. To change the Edit mode,

press Control, use SELECT and and Up Down to locate

matrix position 1.0. Turn ADJUST to select Go Pro or .

Edit

Press Bypass to mute the

input signal. A Bypass Mode

parameter at Control mode

1.3 allows you to select input

muting, output muting, input

and output muting, or bypass

as alternatives. You can also

assign the bypass function to

an external controller.

When you turn ADJUST, or

perform any other param-

eter edits, the front panel

Compare light will go on to

indicate that the program

has been modied since it

was last stored. Press Com-

pare to hear the unedited

version. Press again to re-

turn to your edited program.

Bypass

Compare

Each preset has one or more

parameters patched to the

ADJUST knob.

Turn ADJUST to display the

name and the current value

of the patch.

Continue turning ADJUST to

change the value of the patch

along its entire range. The

screen will return to its nor-

mal display when you stop

turning ADJUST.

0.0-1.9 Multi Eects

2.0-3.5 Modulation

Eects

3.6-4.9 Special Eects

Press Program Banks to cycle through six banks of 50 presets.

Turn SELECT to view all of the presets in numerical order.

Press Load/✱ to load any displayed eect.

0.0-0.9 Sci-Fi FX

1.0-1.9 Pitch & Delay

2.0-2.9 Pitch

Sequences

3.0-3.7 Pads & Drones

3.8-3.9 Utility Programs

4.0-4.9 Pitch Correct

0.0-0.9 Vocal Shift

1.0-1.9 Vocal Harmony

2.0-2.9 Guitar Magic

3.0-3.9 Instrument Shift

& Harmony

4.0-4.9 Percussion &

Tempo

0.0-2.8 Reverb Eects

2.9-3.9 Processed

Reverb

Eects

4.0-4.9 Remix Eects

0.0-1.0 EQ Eects

1.1-2..4 Spatial Effects

2.5-4.0 Gain Eects

4.1-4.9 Resonant Chord

Eects

0.0-3.6 Rhythmic Echo

and Delay

Eects

3.7-4.9 Ambience

Eects
