IN THE BOX
1x 1x 1x Powerup charging pad USB-C cable User manual
PRODUCT OVERVIEW
1. Wireless charging surface
2. LED light for wireless charging status
3. USB-C port
PRODUCT OPERATIONS
Important note: Powerup is a wireless charger for Qi-certified devices.
Make sure your mobile device supports wireless charging.
Follow the instructions below to get the most out of your charging pad.
SAFETY PRECAUTIONS
• Only use the voltage specified as correct for the device.
• Do not place the device near heat sources such as heaters or radiators.
• Do not expose the device to water during charging, as this could permanently
damage the speaker or power source.
• Keep away from corrosive liquids.
• Do not put any metal objects on the top of the charging pad.
• Do not open the device or attempt to disassemble the internal parts or modify
them in any way.
PRODUCT SPECIFICATIONS
Material: Synthetic leather/Aluminum/ABS
Dimensions: Ø3.07 x 0.24’’ / Ø7.8 x 0.6 cm
Weight: 0.15 lbs / 70 g
Compatibility: Any Qi-enabled devices
Max. wireless output: 15W
Connector: USB-C
Input port: 9V-2A (18W)
Power supply: use with Quick Charge 3.0 Power Adapter (not included) or a DC
9V/2A power Adapter (not included)
Water resistance: IPX4
Frequency band: 110-205 KHz
Operating temperature: 32°F - 95°F - 0°C- 35°C
International warranty: 1 year
Step 2: Connect the other end of the
cable to a USB wall charger and plug
the charger into an outlet.
(A) To get your Powerup charging pad
properly operating, make sure to use
a power adapter (not included) that
delivers at least 18W.
NOTE: Red blinking LED indicates
either a foreign object detected or a
non-compatible device. Make sure to
perfectly align your device with the
charger to ensure proper charging
operations.
Charging pad plugged in
Wireless charging in progress
Foreign object detected
Green LED flashes twice
Green LED ON
Red LED flashes slowly
2 3
1
Step 1: Connect the supplied USB
cable to Powerup USB-C port.
Step 3: Place your Qi-certified mobile
device on top of the Charging Pad.
When the status light on the Charging
Pad lights up green, it is now
charging.
