Please read this manual carefully before operating your set and retain it

for future reference.

E-View

Multi Air Conditioner

A5UW36GFH0 [LMU360HHV]

A6UW42GFH0 [LMU420HHV]

P/NO : MFL67452452

SERVICE MANUAL

AIR

CONDITIONER

- 2 -

Only for training and service purposes LGE Internal Use Only

1. Specification

Note:

1. All data are based on the following conditions:

- Cooling Temperature : Indoor 26.7°C(80°F) DB / 19.4°C(66.9°F) WB

Outdoor 35°C(95°F) DB / 23.9°C(75°F) WB

- Heating Temperature : Indoor 21.1°C(70°F) DB / 15.6°C(60.1°F) WB

Outdoor 8.3°C(46.9°F) DB / 6.1°C(43°F) WB

- Piping Length : Interconnected Pipe Length = 5 m (16.4 ft)

- Difference Limit of Elevation (Outdoor ~ Indoor Unit) is Zero.

Wiring cable size must comply with the applicable local and national code.

3. Due to our policy of innovation some specifications may be changed without

notification.

4. Sound Level Values are measured at Anechoic chamber.

Therefore, these values can be increased(maximum 3dB(A)) owing to ambi-

ent conditions during opration.

** : The unit could be operated on the followig temperature range only when Low

Ambient Kit installed.

- Cooling : Outdoor Temperature -20°C(-4°F) ~ -10°C(14°F) DB

Model Name A5UW36GFH0

[LMU360HHV]

A6UW42GFH0

[LMU420HHV]

Capacity

Nominal Btu/h Class 36,000 42,000

Cooling Min~Rated~Max Btu/h 15,600~36,000~47,400 15,600~42,000~54,500

Heating Min~Rated~Max Btu/h 17,940~41,000~51,600 17,940~45,000~55,800

Power Input Cooling Min~Rated~Max kW 0.98~2.40~3.80 0.98~3.00~4.34

Heating Min~Rated~Max kW 1.28~2.93~4.05 1.28~3.29~4.53

EER / COP Non Ducted - 15.0 / 4.1 14.0 / 4.0

SEER / HSPF

Non Ducted - 21.0 / 11.5 20.5 / 11.0

Mixed - 19.3 / 11.0 19.8 / 10.8

Ducted - 17.5 / 10.5 19.0 / 10.5

Power Supply V, Φ, Hz 208/230, 1, 60 208/230, 1, 60

Running Current Cooling Min~Rated~Max A 5.3~13.0~20.7 5.3~16.3~23.6

Heating Min~Rated~Max A 7.0~15.9~22.0 7.0~17.9~24.6

Starting Current Cooling Max A - -

Heating Max A - -

Wiring Connections Power Supply Cable (Included Earth) No. x AWG 3C x 8 3C x 8

Power and Communication Cable(Included Earth)

Outdoor ~ BD Unit No. x AWG 4C x 16 4C x 16

Combination

Sum of Indoor Units Capacity Max kBth/h 48 56

Number of Indoor Units Max EA 5 6

Number of BD Units Max EA 2 2

Casing Color - Warm Gray Warm Gray

Dimensions W x H x D mm 950 x 1,380 x 330 950 x 1,380 x 330

W x H x D inch 37-13/32 x 54-11/32 x 13 37-13/32 x 54-11/32 x 13

New Weight kg(lbs) 101.0 (222.7) 101.0 (222.7)

Compressor

Type - Twin Rotary Twin Rotary

Model Model x No. GPT442MBA x 1 GPT442MBA x 1

Motor Type - BLDC BLDC

Motor Output W x No. 4,000 (at 60Hz) x 1 4,000 (at 60Hz) x 1

Refrigerant

Type - R410A R410A

Precharged Amount g (oz) 5,600 (197.5) 5,600 (197.5)

Chargeless-Pipe Length Main Pipe m (ft) 5 (16.4) 5 (16.4)

Branch Pipe m (ft) 40 (131.2) 40 (131.2)

Additional Charging Volume Main Pipe g/m (oz/ft) 50 (0.54) 50 (0.54)

Branch Pipe g/m (oz/ft) 20 (0.22) 20 (0.22)

Control - Eclectric Expansion Valve Eclectric Expansion Valve

Refrigerant Oil Type - FVC68D FVC68D

Charged volume cc x No. 1,300 x 1 1,300 x 1

Heat Exchanger (Row x Column x Fins per inch) x No. - (2 x 32 x 14) x 2

(1 x 32 x 14) x 2

(2 x 32 x 14) x 2

(1 x 32 x 14) x 2

Fan Type - Propeller Propeller

Air Flow Rate m3/min(ft3/min) x No. 60 (2,119) x 2 60 (2,119) x 2

Fan Motor Type - BLDC BLDC

Output W x No. 124.2 x 2 124.2 x 2

Sound Pressure Level Cooling Rated dB(A) 54 54

Heating Rated dB(A) 57 57

Sound Power Level Cooling Rated dB(A) - -

Piping Connections Liquid Outer Dia. mm(inch) Φ Φ9.52 (3/8) 9.52 (3/8)

Gas Outer Dia. mm(inch) Φ Φ19.05 (3/4) 19.05 (3/4)

Piping Length

Total Piping Max. m (ft) 145 (475.7) 145 (475.7)

Main Piping Max. m (ft) 55 (180.4) 55 (180.4)

Total Branch Piping Max. m (ft) 90 (295.3) 90 (295.3)

Each Branch Piping Max. m (ft) 15 (49.2) 15 (49.2)

Maximum Height

Difference

Outdoor Unit ~ Indoor Unit Max. m (ft) 30 (98.4) 30 (98.4)

Indoor Unit ~ Indoor Unit Max. m (ft) 15 (49.2) 15 (49.2)

BD Unit ~ Indoor Unit Max. m (ft) 10 (32.8) 10 (32.8)

Operation Range

(Outdoor Temperature)

Cooling Min. ~ Max. ℃ DB(℉ DB) -20(-4)** ~ 48(118) -20(-4)** ~ 48(118)

Heating Min. ~ Max. ℃ DB(℉ DB) -25(-13) ~ 24(75) -25(-13) ~ 24(75)
