Side 1/2

This alarm system monitors liquid levels in lift pump chambers, sump pump basins, holding tanks, sewage, agricultural, and other

water applications.

The ALM-2 and ALM-2-1 alarm systems can serve as a high or low level alarm depending on the ﬂ oat switch model used. The alarm

horn sounds when a potentially threatening liquid level condition occurs. The horn can be turned off, but the alarm light remains on

until the condition is remedied. Once the condition is cleared the alarm will automatically reset. A green "power on" light indicates

120 VAC primary power to the alarm. Low battery chirp feature indicates when battery should be replaced.

ALM-2 and ALM-2-1 Alarm System Installation Instructions

FEATURES



120 VAC Model Voltage - (circuits not supervised) Primary: 120 VAC, 60 Hz, 2.4 watts maximum

(alarm condition) Operating Voltage: 9 VDC Double insulation.



NEMA 1 enclosure rated for indoor use.



Automatic alarm reset.



Red "alarm" light and green "power on" light, alarm "test" switch, and horn "silence" switch.



6 foot (1.8 meter) power cord.



Alarm horn sounds at 87 decibels at 10 feet (3 meters).



Can be used with any UL Listed switching mechanism rated to include 1 amp, 9 VDC load.



Maximum line impedance for initiating device: 5 ohms.



If primary power fails, the alarm system continues to work due to battery backup feature.

Battery Backup Power - (circuit not supervised) 9 VDC.



Complete package includes standard SJE SignalMaster

control switch with 10 (ALM-2-1) or

20 (ALM-2) feet of cable, mounting clamp, and cord bung.



Switching mechanism operates on low voltage and is isolated from the power line to reduce the

possibility of shock.



Low battery chirp.



External terminal block for easy ﬂ oat switch installation.



Three-year limited warranty.

PREVENTATIVE MAINTENANCE

• Periodically inspect the product. Check that the cable has not become worn or that the housing has not been damaged so as to impair the protection of the

product. Replace the product immediately if any damage is found or suspected.

• Periodically check to see that the ﬂ oat is free to move and operate the switch.

• Use only SJE-Rhombus

replacement parts.

Liberty Pumps, Inc. warrants that products of its manufacture

are free from all factory defects in material and workmanship for a

period of 3 years from the date of purchase. The date of purchase

shall be determined by a dated sales receipt noting the model

and serial number. The dated sales receipt must accompany the

returned product if the date of return is more than 3 years from

the date of manufacture noted on the product.

The manufacturer’s obligation under this Warranty shall be

limited to the repair or replacement of any parts found by the

manufacturer to be defective, provided the part or assembly is

returned freight prepaid to the manufacturer or its authorized

service center, and provided that none of the following warranty-

voiding characteristics are evident:

The manufacturer shall not be liable under this Warranty if

the product has not been properly installed; if it has been

disassembled, modiﬁ ed, abused or tampered with; if the electrical

cord has been damaged or improperly spliced; if the pump

discharge has been reduced in size; if the pump has been used

in hot water or water containing sand, lime, cement, gravel, or

LIBERTY PUMPS

THREE-YEAR LIMITED WARRANTY

other abrasives; if the product has been used to pump chemicals

or hydrocarbons; if a non-submersible motor has be subject to

excessive moisture; or if the label bearing the serial and code

number has been removed.

Liberty Pumps, Inc. shall not be liable for any loss, damage or

expenses resulting from installation or use of its products, or for

consequential damages, including costs of removal, reinstallation

or transportation.

There is no other express warranty. All implied warranties,

including those of merchantability and ﬁ tness for a particular

purpose, are limited to three years from date of purchase.

The Warranty contains the exclusive remedy of the purchaser,

and, where permitted, liability for consequential or incidental

damages under any and all warranties are excluded.

Produkt Specifikationer

Mærke:	Liberty Pumps
Kategori:	Ikke kategoriseret
Model:	ALM-2-1
