Installer: Manual must remain

with owner/operator.

Record information:

Model:

7000 Apple Tree Avenue

Bergen, NY 14416

ph: 1-800-543-2550

fax: 1-585-494-1839

www.LibertyPumps.com

Keep this manual handy for future reference.

For replacement manual, visit LibertyPumps.com,

or contact Liberty Pumps at 1-800-543-2550.

Retain dated sales receipt for warranty.

Serial:

Mfg Date:

Install Date:

Installation Manual

1796000B

LCU-Series Condensate Pumps

Models

LCU-15

115 VAC

LCU-15S

115 VAC

Safety Switch

LCU-20S

115 VAC

Safety Switch

LCU220S

230 VAC

Safety Switch

* Models ending with a “T” suffix (not listed) include 20’ of clear discharge tubing

Contents

Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 | EN

General Information . . . . . . . . . . . . . . . . . . . . . . . . . . 3 | EN

Pump Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 | EN

Maintenance and Troubleshooting . . . . . . . . . . . . . . 3 | EN

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 | EN

Safety Guidelines

Safety Precautions

Accidental contact with electrically live parts, items, fluid, or

water can cause serious injury or death.

Always disconnect the pump from power source before

attempting to service the pump. Fatal electrical shock could

occur.

Do not handle or unplug the pump with wet hands, when

standing on damp surface, or in water unless wearing

Personal Protective Equipment.

The pump shall be plugged into a properly fused electrical

outlet with a ground fault circuit interrupter (GFCI) that

conforms to current National Electric Code (NEC) and all

applicable local codes. All wiring must be performed by

qualified personnel.

All electrical and safety practices shall be in accordance with

the National Electrical Code

, the Occupational Safety and

Health Administration, or applicable local codes and

ordinances.

Pump shall be properly grounded using its supplied

grounding conductor. Do not bypass grounding wires or

remove ground prong from attachment plugs. Failure to

properly ground the pump system can cause all metal

portions of the pump and its surroundings to become

energized.

Always wear dielectric rubber boots and other applicable

Personal Protective Equipment (PPE) when water is on the

floor and an energized pump system must be serviced, as

submerged electrical connections can energize the water. Do

not enter the water if the water level is higher than the PPE

protection or if the PPE is not watertight.

Do not handle or unplug pump with wet hands, when

standing on a wet/damp surface, or in water. Fatal electrical

shock could occur.

Do not lift or carry the pump by its power cord. This will

damage the power cord, and could expose the electrically live

wires inside the power cord.

The electrical power supply shall be located within the length

limitations of the pump power cord, and for below grade

installations it shall be at least 4 ft (1.22 m) above floor level.

Do not use this product in applications where human contact

with the pumped fluid is common (such as swimming pools,

fountains, marine areas, etc.).

Protect the power and control cords from the environment.

Unprotected power and control (switch) cords can allow

water to wick through ends into pump or switch housings,

causing surroundings to become energized.

Do not use an extension cord to power the product.

Extension cords can overload both the product and extension

cord supply wires. Overloaded wires will get very hot and can

catch on fire.

For cord replacement: power cord must be of the same

length and type as originally installed on the Liberty Pumps

product. Use of incorrect cord may lead to exceeding the

electrical rating of the cord and could result in death, serious

injury, or other significant failure.

Do not use to pump ammable or explosive uids such as

gasoline, fuel oil, kerosene, etc. Do not use in flammable

and/or explosive atmosphere. Sparks could ignite flammable

liquids.

Do not modify the pump/pump system in any way.

Modifications may affect seals, change the electrical loading

of the pump, or damage the pump and its components.

All pump/pump system installations shall be in compliance

with all applicable Federal, State, and Local codes and

ordinances.

Do not allow children to play with the pump.

This safety alert symbol is used in the manual

and on the pump to alert of potential risk for

serious injury or death.

This safety alert symbol identifies risk of

electric shock. It is accompanied with an

instruction intended to minimize potential risk

of electric shock.

This safety alert symbol identifies risk of fire.

It is accompanied with an instruction intended

to minimize potential risk of fire.

This safety alert symbol identifies risk of

serious injury or death. It is accompanied

with an instruction intended to minimize

potential risk of injury or death.

Warns of hazards which, if not avoided, will

result in serious injury or death.

Warns of hazards which, if not avoided, could

result in serious injury or death.

Warns of hazards which, if not avoided, could

result in minor or moderate injury.

Signals an important instruction related to the

pump. Failure to follow these instructions

could result in pump failure or property

damage.

RISK OF ELECTRIC SHOCK

RISK OF FIRE

RISK OF SERIOUS INJURY OR DEATH
