Side 1/8

Installer: Manual must remain

with owner/operator.

Record information:

Model:

7000 Apple Tree Avenue

Bergen, NY 14416

ph: 1-800-543-2550

fax: 1-585-494-1839

www.LibertyPumps.com

Keep this manual handy for future reference.

For replacement manual, visit LibertyPumps.com,

or contact Liberty Pumps at 1-800-543-2550.

Retain dated sales receipt for warranty.

Serial:

Mfg Date:

Install Date:

60 Hz

Installation Manual

5488000B

Model 406 Drain Pump

Features

•Appliance-style design

•Compact size

•Bottom inlets accommodate shower plumbing

•Maximum fluid temp 140°F (60°C)

•Integral discharge check valve

•Integral side inlet check valve

•Discharge size options via single adapter

•Serviceable float switch and pump cartridge

Meets UPC

ASME A112.3.4

CSA B45.9

Contents

Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 | EN

Model Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 | EN

General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 | EN

Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 | EN

Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 | EN

Test System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 | EN

Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 | EN

Maintenance and Troubleshooting . . . . . . . . . . . . . . . 6 | EN

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 | EN

Safety Guidelines

Safety Precautions

Accidental contact with electrically live parts, items, fluid, or

water can cause serious injury or death.

Always disconnect the pump from power source before

attempting to service the pump. Fatal electrical shock could

occur.

All installation and maintenance of pumps, controls,

protection devices, and general wiring shall be done by

qualified personnel.

The pump shall be plugged into a properly fused electrical

outlet with a ground fault circuit interrupter (GFCI) that

conforms to current National Electric Code (NEC) and all

applicable local codes. All wiring must be performed by

qualified personnel.

All electrical and safety practices shall be in accordance with

the National Electrical Code

, the Occupational Safety and

Health Administration, or applicable local codes and

ordinances.

Pump shall be properly grounded using its supplied

grounding conductor. Do not bypass grounding wires or

remove ground prong from attachment plugs. Failure to

properly ground the pump system can cause all metal

portions of the pump and its surroundings to become

energized.

Do not handle or unplug the pump with wet hands, when

standing on damp surface, or in water unless wearing

Personal Protective Equipment.

Always wear dielectric rubber boots and other applicable

Personal Protective Equipment (PPE) when water is on the

floor and an energized pump system must be serviced, as

submerged electrical connections can energize the water. Do

not enter the water if the water level is higher than the PPE

protection or if the PPE is not watertight.

Do not lift or carry the pump by its power cord. This will

damage the power cord, and could expose the electrically live

wires inside the power cord.

The electrical power supply shall be located within the length

limitations of the pump power cord, and for below grade

installations it shall be at least 4 ft (1.22 m) above floor level.

Do not use this product in applications where human contact

with the pumped fluid is common (such as swimming pools,

fountains, marine areas, etc.).

Protect the power and control cords from the environment.

Unprotected power and control (switch) cords can allow water

to wick through ends into pump or switch housings, causing

surroundings to become energized.

Do not use an extension cord to power the product. Extension

cords can overload both the product and extension cord

supply wires. Overloaded wires will get very hot and can catch

on fire.

This safety alert symbol is used in the manual

and on the pump to alert of potential risk for

serious injury or death.

This safety alert symbol identifies risk of

electric shock. It is accompanied with an

instruction intended to minimize potential

risk of electric shock.

This safety alert symbol identifies risk of fire.

It is accompanied with an instruction

intended to minimize potential risk of fire.

This safety alert symbol identifies risk of

serious injury or death. It is accompanied

with an instruction intended to minimize

potential risk of injury or death.

Warns of hazards which if not avoided will

result in serious injury or death.

Warns of hazards which if not avoided could

result in serious injury or death.

Warns of hazards which if not avoided could

result in minor or moderate injury.

Signals an important instruction related to

the pump. Failure to follow these instructions

could result in pump failure or property

damage.

Read every supplied manual before using

pump system. Follow all the safety

instructions in manual(s) and on the pump.

Failure to do so could result in serious injury

or death.

RISK OF ELECTRIC SHOCK

RISK OF FIRE
