Side 1/20

Installation Guide

Quality, Design and Innovation

home.liebherr.com/fridge-manuals

Contents

1 General safety instructions................................... 2

2 Installation conditions........................................... 2

2.1 Location.................................................................... 2

2.2 Installing multiple appliances.................................... 2

2.3 Mains connection..................................................... 3

3 Appliance dimensions........................................... 3

4 Recess dimensions............................................... 4

4.1 Internal dimensions.................................................. 4

5 Ventilation requirements....................................... 4

6 Transporting the appliance................................... 5

7 Unpacking the appliance...................................... 5

8 Setting up the appliance....................................... 5

8.1 After installation........................................................ 5

9 Disposing of packaging........................................ 5

10 What the symbols mean........................................ 5

11 Reversing the door................................................ 6

12 Water connection*.................................................. 8

13 Connecting the water supply................................ 9

14 Installing the appliance in the recess.................. 9

15 Cabinet fronts......................................................... 16

15.1 Dimensions.............................................................. 16

15.2 Mounting the cabinet front(s).................................... 17

15.3 Setting the clearance to avoid collision..................... 17

16 Connecting the appliance..................................... 18

The manufacturer works constantly on the further development

of all the types and models. Therefore please understand that

we have to reserve the right to make design, equipment and

technical modifications.

To get to know all the benefits of your new appliance, please

read the information contained in these instructions carefully.

The instructions apply to several models. Differences may

occur. Text relating only to specific appliances is marked with

an asterisk (*).

Instructions for action are marked with a , the results of

action are marked with a .

1 General safety instructions

-Only install, connect and dispose of the appli-

ance according to the instructions.

-The socket must be easily accessible so that

the appliance can be quickly disconnected

from the supply in an emergency. It must be

outside the area of the rear of the appliance.

DANGER identifies a situation involving direct

danger which, if not obviated, may

result in death or severe bodily

injury.

WARNING identifies a dangerous situation

which, if not obviated, may result in

death or severe bodily injury.

CAUTION identifies a dangerous situation

which, if not obviated, may result in

minor or medium bodily injury.

NOTICE identifies a dangerous situation

which, if not obviated, may result in

damage to property.

Note identifies useful information and tips.

2 Installation conditions

WARNING

Fire hazard due to dampness!

If live parts or the mains lead become damp this may cause

short circuits.

u The appliance is designed for use in enclosed areas. Do

not operate the appliance outdoors or in areas where it is

exposed to splash water or damp conditions.

Intended use

-Install and use the appliance in indoor spaces only.

-Use the appliance only once installed.

2.1 Location

WARNING

Fire hazard due to refrigerant!

The coolant used is eco-friendly but also flammable. Any

leaking coolant may ignite.

uDo not damage the piping of the refrigeration circuit.

- If the appliance is installed in a very humid environment,

condensation can build up on the outside of the unit.

Always make sure the installation location is well ventilated .

- The more coolant there is in the appliance, the larger the

room in which the appliance is installed must be. If the room

is too small, any leak may create a flammable mixture of gas

and air. For each 8 g of coolant the installation space must

be at least 1 m3. Information on the coolant is on the model

plate inside the appliance.

2.1.1 Supporting floor

-The floor of the installation site must be horizontal and even.

- If the floor is not entirely even, the kitchen cabinet housing

the appliance must be levelled with support blocks.

2.1.2 Positioning

- Do not install the appliance in direct sunlight, next to an

oven, radiator or similar.

-Only fit the appliance into solid kitchen units.

2.2 Installing multiple appliances

NOTICE

Risk of damage due to condensate!

u Do not install the appliance directly alongside a further

refrigerator/freezer.

NOTICE

Risk of damage due to condensation!

u Do not install the appliance directly above another refriger-

ator or freezer.

These appliances are designed for a variety of installation

options. Combine appliances only if the appliance is suitable.

The following table shows the installation options by model:

General safety instructions

2 * Depending on model and options

Produkt Specifikationer

Mærke:	Liebherr
Kategori:	Køleskab
Model:	IRe 4520
Vekselstrømsindgangsspænding:	220-240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	559 mm
Dybde:	546 mm
Højde:	1395 mm
Vægt:	47800 g
Produktfarve:	Hvid
Lampe type:	LED
Indbygget skærm:	Ja
Skærmtype:	LCD
Strøm:	1.2 A
Pakkevægt:	51800 g
Pakkedybde:	622 mm
Pakkebredde:	572 mm
Pakkehøjde:	1454 mm
Årligt energiforbrug:	106 kWh
Placering af apparat:	Indbygget
Dørhængsel:	Højre
Installationsrum bredde:	570 mm
Installationsrum dybde:	550 mm
Installationsrum højde:	1413 mm
Tilsluttet belastning:	136 W
Støjniveau:	35 dB
Døråbningsvinkel:	115 °
Energieffektivitetsskala:	A til G
Strømkilde type:	Vekselstrøm
Støjemissionsklasse:	B
Energieffektivitetsklasse:	E
Vendbare døre:	Ja
Klimaklasse:	SN-T
Energieffektivitetsindeks (EEI):	100
Køleskab antal hylder/kurve:	7
Antal grøntsagsskuffer:	1
Æggebakke:	Ja
Køleskabsdøre:	4
Køleskab, netto rumindhold:	236 L
Køleskab indvendigt lys:	Ja
Skærmplacering:	Indvendig
Hylder, materiale:	Glas
Køleskab, brutto rumindhold:	244 L
Flaskeholder:	Ja
Oprindelsesland:	Tyskland
Super Cool funktion:	Ingen
Frisk zone, aflukke:	Ja
Automatisk afrimning (køleskab):	Ja
Minimal driftstemperatur:	10 °C
Maksimal driftstemperatur:	43 °C
Dørmontering:	Dør-til-dør
Vandbeholder:	Ingen
Toldproduktkode (TARIC):	8418215990
