Side 1/10

Part no.:

| DESCRIPTION

38261

9 Port HDMI Video Wall Scaler

Generate a 3x3 video wall from a 4K HDMI Signal

Scale a single HDMI input across up to 9 displays

Create 13 different video wall layouts with a single unit

Supports input resolutions of up to 3840x2160@30Hz

Compose a video wall without any control software

2 year warranty

The 9 Port HDMI Video Wall Scaler allows a 4K HDMI input source to be arranged on 9 displays in a variety of conﬁgurations. The

4k input is divided up in to nine signals and sent to each display at 1080p creating the perfect digital signage or entertainment

solution.

The unit features a HDMI input connection which allows one unique source to be used as well as HDMI audio extraction via the

3.5mm Stereo audio output.

This unit has been developed for use in installations which require maximum impact, such as retail, advertising and hospitality.

Multiple video wall presets and adjustable picture options means the Scaler can deliver stunning video wall layouts.

Create even bigger Video Walls by combining two units together via HDMI for layouts up to 3x4 or 4x4.

•

Speci cationﬁ

AV Interface: HDMI

Interface Standard: HDMI 1.4

Supported Bandwidth: 10.2Gbps

•

| TECHNICAL DATA SHEET



Maximum Input Resolution: 3840x2160@30Hz 4:4:4 8bit

Maximum Output Resolution: 1920x1080@60Hz 4:4:4 8bit

HDCP Support: 1.4

Supported Audio: Audio Pass Through on HDMI Output 1

Separate Audio Ports: 3.5mm Stereo

Special Features: Daisy Chain of 2 devices video for wall layouts up to 3x4 or 4x4

Connectors

Input: 1 x HDMI Type A (Female)

Output: 9 x HDMI (Female)

Power: 5.5/2.1mm DC socket

Physical Properties

Dimensions (approx.) WxDxH: 305x185x35mm (12.01x7.28x1.38in)

Housing Material: Metal

Net Weight: 1.747kg (3.85lb)

Operating Temperature: -10°C - 45°C (14°F - 113°F)

Storage Temperature: -10°C - 80°C (14°F - 176°F)

Humidity: 10-85% RH (non-condensing)

Power Requirements: 12VDC 2A

Colour: Black

Miscellaneous

Packaging Type: Carton Box

Packaging Dimensions:

Gross Weight:

Warranty (Years): 2

Product Compliance: CE, UKCA, FCC, REACH, California 65 & RoHS

Package Contents

9 Port HDMI Video Wall Scaler

Multi-Country Power Supply (US, UK, EU & AUS)

Remote Control

Lindy Manual

Purchasing Information

No.: 38261

EAN: 4002888382618

•

| TECHNICAL DATA SHEET


