Side 1/2
SUMP PUMPS
6 SERIES - 1/3 HP
Volts Hz
Amps
Watts
Performance
(GPM @ Height in Feet)
Shut-O
(ft)
FLA Start 10'5' 15'
115 46 29 12.5 1850/60 9.0 14.3 720 7.8
Item No. Model HP Volts
Switch Type/
Operation
On Level O Level WeightCord
506158 6-CIA 115 Integral Diaphragm1/3
7" - 10"
17.8 cm - 25.4 cm
1" - 4"
2.5 cm - 10.2 cm
10'
3 m
18 lbs
8.16 Kg
***506160 6-CIA-ML 115 Integral Diaphragm1/3
4"-7"
10.2 cm - 17.8 cm
1-1/2" - 3-1/2"
3.8 cm - 8.9 cm
3 m
18 lbs
8.16 kg
*506162 6-CIA 115 Integral Diaphragm1/3
10" - 13"
25.4 cm - 33.02 cm
4" - 7"
10.2 cm - 17.8 cm
10'
3 m
18.5 lbs
8.39 Kg
506125 6-CIA 1/3
115
Integral Diaphragm
7" - 10"
17.8 cm - 25.4 cm
1" - 4"
2.5 cm - 10.2 cm
25'
7.6 m
19.5 lbs
8.85 kg
506357 6-CBA 115 Integral Diaphragm1/3
7" - 10"
17.8 cm - 25.4 cm
1" - 4"
2.5 cm - 10.2 cm
10'
3 m
19.25 lbs
8.73 Kg
*506164 6-CIA 115 Integral Diaphragm1/3
10" - 13"
25.4 cm - 33.02 cm
4" - 7"
10.2 cm - 17.8 cm
25'
7.6 m
20 lbs
9.07 Kg
506171
6-CIA-RFS
1/3 115 Piggyback Mechanical Float
9.5" - 11.5"
24.1 cm - 29.2 cm
1" - 4"
2.5 cm - 10.2 cm
10'
3 m
17.75 lbs
8.05 Kg
506267 6-CIA-RS 1/3
115
Piggyback Diaphragm
7" - 10"
17.8 cm - 25.4 cm
3" - 5"
7.6 cm - 12.7 cm
10'
3 m
17.5 lbs
7.94 Kg
**506271 6-CIM-R 1/3
115
Manual – –
10'
3 m
16.5 lbs
7.48 Kg
**506274
6-CIM-R
1/3 115 Manual – –
25'
7.6 m
18 lbs
8.16 Kg
506257 6-CBM 115 Manual - -1/3
10'
3 m
17.75 lbs
8.05 Kg
* Leg kit included
** 1-1/4" FNPT reducer bushing and 3/4" GHT garden hose adapter included
***Not recommended for standard sump systems. Intended for use only with the Drainosaur WRSC system or other small sump basins with an operational depth of less than 10 inches.
Basement sumps, dewatering, water transfer
Shaded pole motor with thermal overload protection
Designed for continuous duty
Oil-filled cast iron or cast bronze motor housing for an increased
corrosion resistance option in brackish water
PVC riser legs (506162 only)
1-1/2" FNPT discharge
1-1/4" FNPT reducer bushing included with select models
3/4" GHT garden hose adapter included with select models
cCSAus listed (115 V models only)
6-CIA
6-CIA-RFS
6-CBA
6-CBM
6-CIA W/ LEGS
FEATURES
SERIES SPECIFICATIONS
APPLICATIONS
APPLICATIONS
Switch repair kit
Item No. Model Volts Housing
599300 SPRK-1 6-CIA and 6-CBA √
599310 SPRK-1-ML 6-CIA-ML (used in WRSC-6) √
599320 SPRK-2 6-CIA and 6-CBA –
599314 SPRK-2-ML 6-CIA-ML (used in WRSC-6) –
SUMP PUMP SWITCH REPAIR KIT
FEATURES
Includes pressure switch bracket assembly,
screw, diaphragm, and O-ring
12
Technical Support: 1.800.701.7894 | www.littlegiant.com
SUMP PUMPS
Spec Sheet 995201
6 SERIES - 1/3 HP
0
2
3
4
5
6
0 25 50 75 100 125 150 175
0
5
10
15
20
0 10 20 30 40 50
1
Total Dynamic Head in Feet
Flow/Capacity in US Gallons Per Minute
Flow/Capacity in Liters Per Minute
Total Dynamic Head in Meters
Motor Housing
Epoxy-coated cast iron or epoxy
impregnated cast bronze
Impeller Material Nylon
Impeller Type Non-clog
Volute Polypropylene
Motor Shaft CRS
Mechanical Shaft Seal
Nitrile with carbon and
ceramic faces
Fasteners Stainless steel
Bearings
Upper: Sintered iron/copper,
flanged sleeve
Lower: Sintered iron/copper,
flanged steel
Power Cord 18-3, SJTW
Model A B C D
6-CIM-R, 6-CIA-RFS,
6-CIA-RF, 6-CIM, and 6-CBM
7.25"
18.42 cm
9.5"
24.13 cm
7.2"
18.29 cm
–
6-CIA and 6-CBA
6"
15.24 cm
9.5"
24.13 cm
8.5"
21.59 cm
8.2"
20.83 cm
6-CIM-R
6-CIA
D
C
B
A
B
C
A
PERFORMANCE DATA CONSTRUCTION
ENGINEERING DATA
13
