Thank You for purchasing your new Logik Bagless Vacuum Cleaner With Pet

Brush.

We recommend that you spend some time reading this instruction manual in order to

fully understand all the operational features it offers.

Read all the safety instructions carefully before use and keep this instruction manual

for future reference.

If items are missing or damaged, please contact Partmaster (UK only).

Tel: 0844 800 3456 for assistance.

GB-5

DSG Retail Ltd • Maylands Avenue • Hemel Hempstead

Herts • HP2 7TG • England

Visit Partmaster.co.uk today for the easiest way to buy

electrical spares and accessories. With over 1 million

spares and accessories available we can deliver direct

to your door the very next day. Visit www.partmaster.co.uk or call 0844 800 3456 (UK

customers only) Calls charged at National Rate.

This symbol on the product or in the instructions means that your

electrical and electronic equipment should be disposed at the end of its

life separately from your household waste. There are separate collection

systems for recycling in the EU. For more information, please contact the

local authority or your retailer where you purchased the product.

(P.N. L16VRP12-001)

GB-4

Bagless Vacuum Cleaner

With Pet Brush

Instruction Manual

L16VRP12

UNPACKING

Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so

according to any local regulations.

The following items are included:

SPECIFICATIONS

Supply voltage: 220-240V

Power input: 1400W (Nominal), 1600W (Maxium)

Dust capacity: 2.5L

We continually strive to improve our products. Specications may change without prior notice.

SAFETY FIRST!

For your continued safety and to reduce the risk of injury or electric shock, please follow all the

safety precautions listed below.

• Read all the instructions carefully before using the appliance and keep them for future

reference.

• Retain the manual. If you pass the appliance onto a third party make sure to include this

manual.

• Check that the voltage marked on the rating label matches your mains voltage.

• Consult your dealer if you are ever in doubt about the installation, operation or safety of your

appliance.

• Do not remove any xed cover as this may expose dangerous voltages.

• Do not allow any electrical appliance to be exposed to dripping or splashing.

• To protect against electrical shock, do not immerse the mains cable, mains plug, or any part of

the appliance in water or other liquids.

• Make sure the dust bin is properly installed before use.

• Never vacuum up water or any other liquids. Never vacuum up ammable substances and do

not vacuum up ashes until they are cold.

• Never use the appliance without the motor protection lter. This damages the motor and

shortens the life of the appliance.

• If a blockage is found in the brushes, hoses or tubes, it should be removed before use.

• Store and use the appliance well away from heat sources such as radiators or gas / electric

res.

• Do not run over the mains cable with the appliance.

• Close supervision is necessary when any appliance is used by or near children.

• This appliance is not intended for use by persons (including children) with reduced physical,

sensory or mental capabilities, or lack of experience and knowledge unless they have been

given supervision or instructions concerning the use of the appliance by a person responsible

for their safety.

• Children should be supervised to ensure that they do not play with the appliance.

• Do not point the hose, tube or any other accessory at the eyes, ears or mouth during

operation.

• Unplug the appliance from the mains socket when it is not in use and before replacing the

lter.

• Allow the appliance to cool completely before cleaning or storing.

• Do not use the appliance for other uses than its intended use.

• The use of accessories not recommended by the appliance manufacturer may cause injuries.

• Do not use the appliance outdoors.

• Do not operate an appliance with a damaged mains cable or mains plug, or in an abnormal

state. If the mains cable is damaged it must be replaced by the manufacturer, its service agent,

or similarly qualied persons in order to avoid a hazard.

• Do not continue to operate the appliance if you are in any doubt about it working normally

(e.g. abnormal noise, smell, smoke), or if it is damaged in any way - switch oﬀ, withdraw the

mains plug and consult your dealer.

• Any maintenance and repair must be handled by a professional technician. Do not try to

repair by yourself.

• The lightning ash with arrowhead symbol, within an equilateral triangle, is

intended to alert the user to the presence of uninsulated “dangerous voltage”

within the unit’s enclosure that may be of suﬃcient magnitude to constitute a risk

of electric shock.

• The exclamation point within an equilateral triangle is intended to alert the user

to the presence of important operating and maintenance (servicing) instructions

in the manual accompanying the unit.

• Main Unit • Hose

(P.N.: L16VRP12-HS)

• Hard Floor Brush

(P.N.: L16VRP12-HF)

• Pet Brush

(P.N.: L16VRP12-PB)

• Instruction Manual

(P.N.: L16VRP12-001)

• Telescopic Tube

(P.N.: L16VRP12-TB)

• Combination Nozzle

(P.N.: L16VRP12-CN)

Bagless Vacuum Cleaner

With Pet Brush

Instruct ion Ma nual

L16VR P12

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

GB-2GB-1 GB-3

Handle

Rear wheels

Hose connection opening

Handgrip of hose

Hose connector

Hose

Telescopic tube

Cover

Lever clasp

Min Max

18 20

Bin

Motor Protection Filter

HEPA lter unit

Bin handle

HEPA lter unit

Bin lid

Mesh guard

Base

ON/OFF button

8 9

Exhaust lter

Cord rewind button

Clip

Grill

Mains plug

Wheel

Combination nozzle

Hard oor brush

Pet brush

PRODUCT OVERVIEW FIRST TIME USE

1. To connect the hose, insert the hose connector into the hose connection opening until you

hear a ‘click’ sound (Fig 1).

2. To connect the telescopic tube to the handgrip of the hose, insert the narrow section into the

wider section while turning a little (Fig 2).

3. Extend the telescopic tube to a length you nd the most comfortable by pressing the button

located on the telescopic tube (Fig 3).

4. Connect a nozzle/brush suitable to the oor type to be cleaned. The hard oor brush can be

used with the brush strips lowered or raised (Fig 4). You may also connect the combination

nozzle to vacuum corners, slots or grooves. It can also be used as a brush nozzle by turning

the strips out.

OPERATION

1. Hold the mains plug and pull the retractable mains cable out of the vacuum cleaner. Connect

it to the mains socket. The YELLOW mark indicates the ideal length to extend the cable. Do not

extend the mains cable beyond the RED mark which indicates the maximum length.

2. Press the button on the top of the vacuum cleaner to turn it on.ON/OFF

3. To move the vacuum cleaner from room to room, you can unplug and carry it by either the

handle or the handgrip. Never use the mains cable to pull the vacuum cleaner.

POWERING OFF AND STORAGE

1. Press the button on the top of the vacuum cleaner to turn it oﬀ and then remove the ON/OFF

mains plug from the mains socket.

2. Press the cord rewind button to rewind the retractable mains cable.

3. Put the vacuum cleaner in a horizontal position and attach the hard oor brush to the clip on

the vacuum cleaner (Fig 5).

EMPTYING THE BIN

Always unplug the vacuum cleaner from the mains socket before emptying the bin.

1. Remove the hose connector from the cleaner. Unclip the lever clasps and open the cover (Fig 6).

2. Use the bin handle to turn the bin anti-clockwise till it stops, then lift the bin up (Fig 7).

3. To prevent the dust dispersing, lower the bin into your dustbin. Take out the lter unit to

empty the bin.

4. If you nd the lter unit is blocked or dirty, follow the steps in “CLEANING THE HEPA FILTER

UNIT”. If not, skip this step.

5. Ret the lter unit back into the bin and then put them back into the vacuum cleaner by

aligning the tabs at the bottom of the bin with the slots on the vacuum cleaner. Turn the bin

clockwise with the bin handle until it locks in place.

6. Close the cover and reclip the lever clasps.

CLEANING THE HEPA FILTER UNIT

1. To take out the lter unit from the bin, tilt it a bit to get the base past the inlet (Fig 8).

2. Hold the base then untighten the top of the lter unit.

3. Lift the HEPA lter from the mesh guard and shake out the dust accumulated on the mesh

guard gently over your dustbin. You may rinse it gently under a running tap.

4. Shake out the dust accumulated on the HEPA lter. You may soak it in warm soapy water for a

few minutes, and then rinse it under a running tap to remove all traces of soap. Do not

reassemble the lter unit until it is completely dry.

5. To reassemble the lter unit, hold the HEPA lter with the arrows pointing up, and lower it into

the mesh guard.

6. Fit the top of the lter unit to the top of the HEPA lter, and turn it clockwise. Do not

over-tighten it.

7. Ret the lter unit back in the bin again, tilt it a bit to get the base past the inlet.

CLEANING THE MOTOR PROTECTION FILTER

The motor protection lter should be cleaned twice a year, or when it appears to be visibly

clogged.

Always unplug the appliance from mains socket before replacing the lter.

1. Take out the motor protection lter (Fig 10).

2. Shake out the dust accumulated on the lter into a dustbin.

3. Relocate the lter back. Close and reclip the cover.

CLEANING THE EXHAUST FILTER

Always unplug the appliance from mains socket before replacing the lter.

1. Unclip the exhaust lter cover then the grill, and take out the exhaust lter (Fig 11 & Fig 12).

2. Shake out the dust accumulated on the lter into a dustbin.

3. Ret the cover, the lter and the grill.

Min Max

Min

Max
