Side 1/52

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Product Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Back Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Quick Guide to Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Hardware Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Driver Software Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

MIDI Interface Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Stand-Alone Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

MIDISPORT Mode Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

USB Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

PC Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Mac Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Cable Test Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Thru Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Patchbay Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

SMPTE Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

SMPTE Writer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

SMPTE Reader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

SMPTE "Write" Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

SMPTE "Format" Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Setting Up Your MIDI Studio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Typical MIDI System Set-up: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Using the MIDISPORT in your Application Software . . . . . . . . . . . . . . . . .27

MIDISPORT Remote Control Software . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Remote Control Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Windows Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Macintosh Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

Remote Control Patchbay Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

Diagnostics Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Test Results for Mac or PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

SMPTE/MIDI Time Code Tutorial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40

Before Calling Tech Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49

Limited Lifetime Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50

Midisport 8x8

™ MANUAL

version: MS8-09092000

Introduction

Thank you for purchasing the MIDISPORT™ 8x8/s multi-port MIDI interface

for USB equipped PC and Macintosh computers. The MIDISPORT’s high speed

Universal Serial Bus connection to the computer assures reliable and speedy

transfer of MIDI data. The MIDISPORT 8x8/s can also be connected to the serial

port of PCs and “legacy” Macintosh computers.

The MIDISPORT performs SMPTE read/write functions using either the front

panel control switches or the included remote control software, which will also

control patchbay settings for your new MIDISPORT 8x8/s.

Follow the installation instructions in this manual and you will be up and

running in no time. The MIDISPORT installs externally to your computer,

requiring no computer disassembly. Expansion is easy too — just plug in

additional MIDISPORT units for more MIDI ports (USB only).

Features

The MIDISPORT 8x8/s USB MIDI Interface has the following features:

• 8 independent in / 8 independent out MIDI Interface (128x128 MIDI

channels) in professional 19" single height rack mount chassis.

• High-speed connection to USB-equipped PC or Mac computers.

• Alternate "legacy" serial connection to non-USB PC or Mac computers.

• MIDI in and out activity indicators for each port.

• Includes 6 ft. USB cable.

• When disconnected from the PC, unit operates as a stand-alone MIDI

patchbay, as well as a SMPTE to MTC synchronizer.

• Built-in "MIDI cable tester" mode.

• Windows 98 compatible -- true Plug-and-Play installation requires no IRQ,

I/O Address or DMA channel setup

• Mac OMS Compatible. Works with Mac OS 8.6 and above.

• Includes Windows and Mac Control Panel software.

SMPTE Time Code Writer/Reader

• Reads and writes 24, 25, 29.97, 30 drop or 30 non-drop frame LTC SMPTE

formats.

• Any SMPTE time write offset may be set-up via included control panel

software

• Converts LTC SMPTE to MIDI Time Code (MTC) for syncing any MTC

capable software.

• Selectable "flywheel" that can be set to any value from 1 frame to 255 frames,

or infinite flywheel.
