Technical Specification
System
Main Processor
Operating System
Video
Input
Input
Signal Type
Output
Audio
Input
Two-way Audio
Output
Alarm
Sensor Input
Output
Motion Detection
Trigger Events
Email Alarm
PTZ
Interface
Protocol
Baud Rate
Address
Display
VGA
HD Output
Display Split
Privacy Masking
OSD
Recording
Video Compression
Audio Compression
Resolution
Video Quality
Record Rate
Record Mode
MC6630
Embedded LINUX
Normal Mode= Analog= 8 x (TVI/AHD= 5M@12fps; AHD/TVI/CVI= 4M@15fps; AHD/TVI= 3M@18fps;
AHD/TVI/CVI= 1080P/720P; Analog= 960H) Analog+Network= 2 x Analog(5MP)+7 x network(MAX 5MP),
4 x Analog(5MP)+5 x network(MAX 5MP), 6 x Analog(5MP)+ 3 x network(MAX 5MP)
Network= 16 x 5MP/4MP/3MP/1080P/960P/720P(Total incoming bandwidth ≤48M)
8CH BNC
Analog/AHD/CVI/TVI 2.0/TVI 3.0/Network
1HD,1 VGA, CVBS
2 Channel, RCA
No
1 Channel, RCA
4 CH
1 CH
8 Channel(max 16 Channel in pure network mode)
Recording, Email, Screen tips, Buzzer, Push notifications(motion detection)
Send Image to The Designated E-mail
RS485
Pelco-D, Pelco-P
110~921600
0~255
Resolution= 1920 × 1080P/60Hz, 1280 × 1024/60Hz, 1280 × 720 60Hz, 1024 × 768/60Hz
Resolution = 1920 × 1080P/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
16 Channel/9 Channel/8 Channel/4 Channel / 1Channel
3 Rectangular Zones (Each camera)
Camera title, Time, Video loss, Alarm, Motion detection, Recording
H.265+/H.265/H.264+/H.264
G.711U/G.711A
5MP_Lite(1296×1952),4MP_Lite(1280×1440),3MP_Lite(1024×1536),1080N(960×1080),720P(1280×720),
960H(P=960×576/N=960×480)
Lowest/Low/Ordinary/Good/Better/Best
Analog= PAL= 5MP_Lite(1296×1952 8 x 6fps),4MP_Lite(1280×1440 8 x 8fps), 3MP_Lite(1024×1536 8 x 10fps),
1080N(960x1080 8 x 15fps),720P(1280×720 8 x 15fps), 960H(960×576 8 x 25fps)
NTSC= 5MP_Lite(1296×1944 8 x 6fps), 4MP_Lite(1280×1440 8 x 8fps),3MP_Lite(1024×1536 8 x 10fps),
1080N(960x1080 8 x 15fps),720P(1280×720 8 x 15fps), 960H(960×576 8 x 30fps)
Pure IP(H.265)= PAL= 5MP@8×25fps,4MP@12x25fps,3MP@12×25fps,1080P@12×25fps,960P@12×25fps,
720P@12×25fps,D1@12×25fps NTSC= 5MP@8×30fps,4MP@12×30fps,3MP@12×30fps,1080P@12×30fps,
960P@12×30fps, 720P@12×30fps, D1@12×30fps
Manual\Timer\Motion Detection\Alarm Input\Motion and Alarm
