©Copyright LOTRONIC 2017 MAD-RETROCASE 2
Safety instructions
Read, follow and keep these Instructions for future reference.
Do not use this apparatus near water.
Clean only with a damp cloth.
Do not block any of the ventilation openings. Install in accordance with the manufacturer’s instructions.
Do not install near nay heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
Protect the power cord from being walked on or pinched particularly at plug, convenience receptacles, and point
where they exit from the apparatus.
Only use attachments/accessories specified by the manufacturer.
Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus.
Unplug this apparatus during lighting storms or when unused for long periods of time.
Refer all servicing to qualified service personnel. Serving is required when the apparatus has been damaged in
any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been
dropped.
This mains plug is used as the disconnect device, the disconnect device shall be readily operable.
CONTROL ELEMENTS
1. Case Cover
2. 45 rpm adapter
3. USB/SD control
4. Tone arm control
5. Auto stop control
6. Speed selection
7. Power & Volume
8. Headphone jack
9. Cartridge
10. Speaker
11. Carry handle
12. 3.5mm audio in
13. RCA audio out
14. Power socket
Turntable Operation
1. Plug the small end of the power plug into your turntable.
2. Connect the big end of the power plug into the wall outlet.
3. Place the vinyl record on your turntable.
4. Set the correct speed (rpm) of your vinyl record (33/45/78 RPM).
For 45 RPM vinyl record, using the RPM adaptor.
5. Turn on the power of the turntable.
6. Move the tonearm to the desired starting point on the record. Then turntable is playing now.
7. Adjust speaker volume to the preferred level.
8. Slide the Auto Stop Control switch to choose the out stop.
9. At the end of the record, the TONEARM will stop automatically. You must return the TONEARM to the
Tonearm Rest manually.
