3 IN 1 CAR AUDIO SYSTEM

WITH DVD.VCD.CD.MP4.MP3.WMA

DISC AND USB PLAYER AND

AM/FM-RDS DIGITAL TUNING RADIO

Instruction Manual

Fully Compatible to These

Types of Discs: DVD, VCD,

S-VCD,MP4,MP3,WMA,CD.

Remark: Any information subject to change without further notice

MCR-1280

2626

U.S. Patent Nos. 4,631,603;4,577,216;4,819,098;4,907,093;5,315,448 and 6,516,132.

THIS PRODUCT INCORPORATES COPYRIGHT PROTECTION

TECHNOLOGY THAT IS PROTECTED BY U.S. PATENTS AND

OTHER INTELLECTUAL PROPERTY RIGHTS. USE OF THIS

AUTHORIZED BY MACROVISION, AND IS INTENDED FOR

HOME AND OTHER LIMITED VIEWING USES ONLY UNLESS

OTHERWISE AUTHORIZED BY MACROVISION. REVERSE

ENGINEERING OR DISASSEMBLY IS PROHIBITED.

Manufactured under license from Dolby Laboratories.

Dolby and the double-D symbol are trademarks of Dolby Laboratories.

7. Specification

General Specification

Power Requirement.............................................................DC 12V

Maximun Power output.......................4 x 40W(mesured at DC 14.4 V)

Dimensions(w x h x d)............................................178 x 50 x 165mm

DVD Deck Specification

Format..............................................DVD/VCD/CD/MP4/MP3/WMA

Video System.......................................................PAL/AUTO/NTSC

Audio System..............................................................24 bit/96KHz

Loading System.......................................................... Auto Loading

Mounting Angle.................................................................0 to +/-30

Video Specification

Video Type...................................................................16:9 and 4:3

Video Output level......................................Composite:1.0¡À 0.2Vp-p

Load impedance: 75 ohms

Horizontal Resolution................................................................500

Audio Specification

Audio Output(Analog audio)..........................................2.0 -1.0Vrms

Frequency Response.............................20Hz ~ 20KHz(at 1KHz 0 dB)

S/N Ratio(Audio).............................................¡Ý90dB(at 1KHz 0 dB)

Separation..............................................................................50dB

Radio Specification

FM Section

Frequency range..............................................87.5MHz - 108.0MHz

Usable sensitivity......................................................................3uV

I.F Frequency....................................................................10.7MHz

AM Section

Frequency..........................................................522KHz - 1620KHz

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE

COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER

SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightening flash with arrowhead symbol, within an equilateral triangle, is

intended the alert the user to the presence of uninsulated dangerous voltage

within the products enclosure that may be of sufficient magnitude to constitute

a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert user to

the presence of important operating and maintenance (servicing) instructions

in the literature accompanying the appliance.

CLASS 1 LASER PRODUCT

Laser product symbol: located on the rear panel of the unit, indicate this player is a class

laser product, only use weak laser and no hazardous radiation outside of the unit.

1.Read through this instruction manual before installation and use.

2.Do not touch the power plug with wet hand.

3.Switch off the main power when the unit is not in use. (Disconnect the power plug from

the power outlet when you do not intend to use the unit for a prolonged period of time.)

Before moving the unit, remove the disc from the unit/ tray first.

4.Do not open the cover or touch any of the components exposed out of the unit, only for

qualified technicians.

5.Do not expose the unit under direct sunlight or nearby objects that radiate heat to avoid

damage the unit.

6.Do not place the unit in moist and humid conditions, which effect the pick-up of the unit

lead to out of work.

7.Place the unit on a flat surface and ventilative condition. Please ensure the ventilation

holes are not covered to avoid overheating and malfunction.

8.Clear the panel and case with soft dry cloth only, do not apply any kind of thinner,

alcohol or sprays.

9.The apparatus shall not be exposed to dripping or splashing and that no objects filled

with liquids, such as vases, shall be placed on the apparatus

10.unplug the apparatus when not using for a long time oriented to disconnect from the

Mains power

WARNING: TO REDUCE THE

RISK OF FIRE OR ELECTRIC

SHOCK, DO NOT EXPOSE

THIS APPLIANCE TO RAIN OR

MOISTURE.

PRECAUTION
