Side 1/24
This product meets the requirements of OSHA 1910.212(a)(5), the standard which regulates electric
fan blade safety.
Please note the serial number of your fan, and write it on the back of this User’s Manual for future reference. Your serial
number is located on upper rear section of mount bar.
READ AND SAVE THESE INSTRUCTIONS
Model Numbers:
MAC-30D / MAC-36D
IMPORTANT: Read and understand all of the instructions in this manual before assembling,
starting, or servicing the fan. Improper use of this fan can cause serious injury. Keep this manual for
future reference.
For general ventilating use only. Do not use to exhaust hazardous or explosive
materials and vapors. Never use the fan in spaces which contain products such as
gasoline, solvents, paint thinners, dust particles, volatile or airborne combustibles, or any unknown
chemicals.
CAUTION
'
(
7
6
,
/
&0
86&
Sauk Rapids, MN 56379 USA • Toll Free (800) 641-6996
Fax: 320-251-2922 • Web: www.masterindustrialproducts.com • Email: info@pinnacleclimate.com
© 2019 Pinnacle Climate Technologies, Inc. MAFC-412
User’s Manual &
Operating Instructions
HIGH CAPACITY
BARREL FAN
WARNING: This product can expose you to chemicals, including lead, which is known
to the State of California to cause cancer and birth defects or other reproductive harm.
For more information go to www.P65Warnings.ca.gov.
MAC-30D MAC-36D
© 2019, Pinnacle Climate Technologies, Inc. 2 High Capacity Barrel Fan User’s Manual
NEVER LEAVE A FAN UNATTENDED WHILE OPERATING
OR WHILE CONNECTED TO A POWER SOURCE
IMPORTANT: READ ALL INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY, SERVICE OR
USE OF THIS FAN. FAILURE TO COMPLY WITH THESE INSTRUCTIONS COULD RESULT IN
SERIOUS PERSONAL INJURY AND/OR PROPERTY DAMAGE.
Safety Information .............................................. 2
Assembly and Installation ................................ 3
Operation...................................................... 3
Maintenance and Storage .................................. 4
Wiring Diagram .................................................. 4
Troubleshooting .................................................. 5
Exploded View.................................................... 6
Warranty............................................................. 7
Table of Contents
Safety Information
THIS IS A FAN - NOT A TOY!
TO REDUCE THE RISK OF
PERSONAL INJURY AND ELECTRIC SHOCK,
FAN SHOULD NOT BE PLAYED WITH OR
PLACED WHERE SMALL CHILDREN CAN
REACH IT.
WARNING
DO NOT MOVE THE FAN
WHILE OPERATING! MOVING
FAN DURING OPERATION CAN CAUSE
BLADE DAMAGE.
WARNING
Risk of fire, electric shock, or
personal injury when performing
service or maintenance. Unplug or disconnect
the fan from the power supply before servicing.
WARNING
To Reduce The Risk Of Fire Or
Electric Shock, Do Not Use This
Fan With Any Solid-State Speed Control Device.
WARNING
To Reduce The Risk Of Electric
Shock And Injury To Persons, Do
Not Use In A Window.
WARNING
To Reduce The Risk Of Electric
Shock, Do Not Expose To Water
Or Rain. This unit is designed for indoor use
only.
WARNING
Installation work and electrical
wiring must be done by
qualified person(s) in accordance with all
applicable codes and regulations.
WARNING
When servicing or replacing a
component requires the removal
or disconnection of a safety device, the safety
device is to be reinstalled or remounted as
previously installed before operating this fan.
WARNING
Use this fan only in the manner
intended by the manufacturer.
If you have any questions, contact Customer
Service at 800-641-6996.
WARNING
- Before operating always check fan for loose or
damaged parts. Inspect power cord for damage.
Never use fan without safety guards attached.
- Operate only on 120 volt 60 Hz (cycle) current
with a minimum 15 amp circuit.
- When used with an extension cord, use a UL
listed, 14 AWG cord equipped with a receptacle
to accept the three-prong grounded plug on the
fan’s power cord and a 3-prong grounded plug for
the power source. If extension cord is longer than
50 feet, consult with cord manufacturer for proper
cord AWG rating. Always keep power cord and
extension cords away from heat, oil, and sharp
edges. Inspect cords periodically and replace if
damaged.
CAUTION Automatically
Operated Device - To Reduce
The Risk Of Injury Disconnect From Power
Source Before Servicing.
WARNING
To guard against electric shock
while operating, do not allow fan
to come in contact with other grounded objects
such as pipes, radiators, etc.
WARNING
