VER.: 2.32

I
User Manual
DECLARATION
SHENZHEN MEGAREVO TECHNOLOGY CO., LTD. (hereinafter
"MEGAREVO") reserves the right to modify the frame dimensions,
functionality, technical data, parameters, standards without prior notice.
The contents of this manual have been checked for accordance with its
described hardware and software. However, the contents of this manual
may be subject to appropriate modification as a result of product upgrade,
specification change and update of the manual, we cannot guarantee full
accordance all the time. But the data in this manual are reviewed regularly
and any necessary corrections are included in subsequent editions.
Suggestions for improvement from readers are appreciated.
No part of this manual may be reproduced in any form, or by any means,
without prior written permission of Megarevo.
All rights © SHENZHEN MEGAREVO TECHNOLOGY CO., LTD.

II
User Manual
and other MEGAREVO trademarks used in this manual are owned
by MEGAREVO.
Using data contained in firmware or software developed by MEGAREVO, in
part or in full, for commercial purposes by any means is prohibited.
Reverse engineering, cracking or any other operation that destroys the
original programming design of software developed by MEGAREVO is
prohibited.
OTHER RIGHTS

III
User Manual
PREFACE
Thank you for choosing REVO Series Hybrid Inverter (hereinafter
"inverter") .
This user manual presents a detailed description of REVO series with
respect to product features, structural characteristics, functions,
installation, parameter settings, troubleshooting, commissioning and daily
maintenance, etc. Be sure to carefully read through the safety precautions
before use and keep it properly at a place for easy access.
• Please assure the intactness of product enclosure and all safety
covers before installation. Operation must conform to the
requirements of this manual and local industrial safety regulations
and/or electrical codes.
• In the event of damage or loss of user manual, users may ask local
distributors, offices or our Technical Service Department for a new
one.
• Contents of this manual may be subject to appropriate modification
as a result of product upgrade, specification change and update of
the manual.
• If any item as stated in this manual is not clear, please contact our
Technical Service Department.
• If any anomaly occurs after power up or during the operation, it is
essential to stop the machine and identify the fault or seek technical
services as soon as possible.
IMPORTANT NOTES

IV
User Manual
This manual is valid for the following model of hybrid inverters:
• R6KH3
• R8KH3
• R10KH3
• R12KH3
• R15KH3
It will be referred to as "inverter" hereinafter unless otherwise specified.
The inverter must only be installed by professional technicians. The
professional technician is required to meet requirements as follows:
• Know electronic, electrical wiring and mechanical expertise, and be
familiar with electrical and mechanical schematics.
• Be familiar with local standards and relevant safety regulations of
electrical systems.
• Have received professional training related to the electrical equipment
installation and commissioning.
• Be able to quickly respond to hazards or emergencies that occur
during installation and commissioning.

V
User Manual
TECHNICAL SUPPORT
Before installation, wiring, operation, and repair to the inverter, please read
carefully and strictly comply with all its Safety Precautions in this manual.
Please ensure all the warning marks on the inverter are clear and distinct.
Replace or add the obscure or missed warning marks.
The information from following sources is all effective.
Scan the QR codefor the latest information and services:
Service time: 24/7
Users may acquire general technical data and information through
MEGAREVO official website: http://www.megarevo.com.cn
If you have any question, or anything that it is not clear for you, or
have some troubles during installation, wiring, and/or operation, you
are suggested to contact MEGAREVO via its recommended contact
information in this manual or contact its sales representatives or service
engineers.

VI
User Manual
Content
1 Safety Precautions 001
1.1 Important Safety Instructions 001
1.2 Important Safety Instructions 008
1.3 CE Directives 009
2 Introduction 011
2.1 Model Description 011
2.2 Basic features 011
2.3 Work Modes 014
2.4 Dimensions 018
2.5 Terminals 019
2.6 Parameters 021
3 Installation 026
3.1 Check for Physical Damage 026
3.2 Packing List 026
3.3 Mounting 027
4 Electrical Connection 031
4.1 PV connection 031
4.2 Grid connection 033
4.3 EPS Connection (apply to I Version and E Version only) 035
4.4 Battery Connection 042
4.5 CT Connection and Phase instruction 045
4.6 DRM Connection (Function temporarily retained) 046
4.7 WiFi Connection (optional) 048
4.8 GPRS Connection (optional) 049
4.9 Inverter Manipulation 050
5 Setting 052

VII
User Manual
5.1 Control Panel 052
5.2 Instructions for LED Indicator 052
5.3 Instructions for the use of three modes 053
6 LCD Operation 056
6.1 LCD Interface 056
6.2 Setting 060
6.3 Inquire 071
6.4 Statistic 072
7 Fault Diagnosis and Solutions 073

VIII
User Manual
Figure
Table
Figure 2-1 Symbols on the Product 011
Figure 2-2 E-Version system diagram 012
Figure 2-3 I-Version system diagram 013
Figure 2-4 Dimensions 018
Figure 2-5 Terminals 019
Figure 3-1 Space Requirement 028
Figure 4-1 E-Version system diagram 037
Figure 4-2 I-Version system diagram 038
Figure 4-3 Battery connection 043
Figure 4-4 BMS PIN definition 043
Figure 4-5 CT connection and phase wiring diagram 045
Figure 4-6 DRM PIN definition 047
Figure 4-7 WIFI connection diagram 048
Figure 4-8 GPRS connection diagram 049
Figure 5-1 Control panel 052
Table 1-1 Symbols on the Product 008
Table 2-1 Terminals 020
Table 2-2 Parameters 021
Table 2-3 Parts list 026
Table 4-1 Max. DC Voltage Limitation 031
Table 4-2 Recommended cables and micro-breakers 033

IX
User Manual
Table 4-3 Recommended cables and micro-breakers 039
Table 4-4 Common feasible loads for reference 041
Table 4-5 Recommended non-polar DC breakers 042
