Side 1/6

The word ‘Megger’ is a registered trademark

MFT1735

User guide addendum

Megger Limited

Archcliffe Road

Dover, Kent CT17 9EN

England

T +44 (0)1 304 502101

F +44 (0)1 304 207342

Megger

4271 Bronze Way,

Dallas, TX 75237-1019

USA

T +1 800 723 2861

T +1 214 333 3201

F +1 214 331 7399

Megger

Z.A. Du Buisson de la Couldre

23 rue Eugène Henaff 78190

Trappes, France

T +33 (0) 1 30.16.08.90

F +33 (0) 1 34.61.23.77

Other technical sales offices

Toronto Canada, Sydney Australia, Mumbai india, Madrid Spain and the Kingdom of Bahrain.

Megger products are distributed in 146 countries worldwide.

This instrument is manufactured in the United Kingdom.

The company reserves the right to change the specification or design without prior notice.

Megger is a registered trademark

Part No. 2005-290

MFT1735_ad_en_V04

www.megger.com

Operation of the MFT1735 is identical to the MFT1730 except for the following

section on Earth Testing.

For Safety Warnings refer to the printed Quick Start Guide.

For all other operating instructions, refer to the MFT1730 sections within the

full User Guide on the included CD.

F.3 Principle of operation (two-clamp stake-less resistance

measurement)

In this example, the electrode under test is connected to a network of other electrodes. It is either

impractical or unsafe to disconnect an individual electrode for testing. Also, there might be insufﬁcient space

to perform a classic three-terminal resistance measurement. The stake-less test method using both VCLAMP

and ICLAMP can be used to obtain a measurement for the electrode under test.

A deﬁned test voltage is injected into the system using the VCLAMP, inducing a current, I, to ﬂow and be

measured by the ICLAMP. The model shown in Figure 7 can be simpliﬁed to the resistance of the electrode

under test, Rx and the resistance of the other electrodes in parallel, i.e. R1 || R2 || … || Rn.

Therefore, the current induced by the test voltage is I=V/[Rx+(R1 || R2 || … || Rn)]. It follows that as the resist-

ance of the other electrodes in parallel approaches zero, then the resistance measured, approaches the value

of the electrode under test.

Schematic for two-clamp stake-less resistance measurement
